Important
Read these instructions for use carefully before
using the appliance and save them for future
reference.
◗Only use the mains cord supplied.
◗Do not use a damaged mains cord.
◗If the mains cord is damaged, always have it
replaced by one of the original type in order
to avoid a hazard.
◗The appliance is equipped with an automatic
voltage selector and is suitable for mains
voltages ranging from 100 to 240 volts.
◗Charge, store and use the appliance at a
temperature between 5cC and 35cC.
◗Do not recharge the shaver in a closed pouch.
C◗Make sure the appliance and the mains cord
do not get wet.
Charging
Make sure the appliance is switched off before
you start charging it.
When charging for the first time or after a long
period of disuse: leave the shaver to charge
continuously for 12 hours.
Charging normally takes approx. 8 hours.
Do not leave the appliance connected to the
mains for more than 24 hours.
You can also shave without charging by
connecting the shaver to the mains.
ENGLISH4
Charging the appliance
Charge the appliance when the motor stops or
starts running slower.
Do not recharge the shaver in a closed pouch.
C1Put the appliance plug in the shaver.
2Put the mains plug in the wall socket.
C◗As soon as you start charging the empty
shaver, the green pilot light goes on.
To extend the lifetime of the battery, remove the
mains plug from the wall socket and pull the
appliance plug out of the shaver when the battery
has been fully charged.
Cordless shaving time
A fully charged shaver has a cordless shaving time
of up to 30 minutes.
Using the appliance
Shaving
1Switch the shaver on by pushing the on/off
slide upwards.
ENGLISH 5
CHARGE
C2Move the shaving heads quickly over your
skin, making both straight and circular
movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips system.
3Switch the shaver off by pushing the on/off
slide downwards.
C4Put the protection cap on the shaver every
time you have used it, to prevent damage.
Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.
Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
C◗For easy and optimal cleaning, the Philips
Action Clean (shaving head cleaner, type
HQ100) is available.Ask your Philips dealer
for information.
BThe Philips Action Clean may not be available in
all countries. Contact the Customer Care Centre
ENGLISH6
in your country about the availability of this
accessory.
You can also clean the shaver in the following way:
Every week: shaving unit
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Clean the top of the appliance first, using
the brush supplied.
C3Press the release button and remove the
shaving unit.
C4Clean the inside of the shaving unit and the
hair chamber with the brush.
C5Put the shaving unit back onto the shaver.
ENGLISH 7
2
1
Every two months: shaving heads
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Press the release button and remove the
shaving unit.
C3Turn the wheel anticlockwise and remove
the retaining frame.
C4Remove and clean the shaving heads
(cutters and guards) one by one.
Do not mix up the cutters and the guards.
This is essential since each cutter has been
ground with its corresponding guard for optimal
performance. If you accidentally mix the sets up, it
could take several weeks before optimal shaving
performance is restored.
C5Clean the cutter with the short-bristled
side of the brush.
Brush carefully in the direction of the arrow.
C6Brush the guard.
ENGLISH8
2
1
1
2
C7Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit, press the wheel and turn it
clockwise.
8Put the shaving unit back onto the shaver.
BYou can also clean the shaving heads with a
degreasing liquid (e.g. alcohol). If you do, lubricate
the central point of the guards with a drop of
sewing machine oil after cleaning.This prevents
wear of the shaving heads.
Trimmer
Clean the trimmer every time you have used it.
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Clean the trimmer with the brush
supplied.
C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
ENGLISH 9
1
2
Storage
C◗Put the protection cap on the shaver to
prevent damage.
◗The appliance can be stored in the pouch
supplied.
Replacement
Replace the shaving heads every 2 years for
optimal shaving results.
Replace damaged or worn shaving heads with
HQ4«Philips shaving heads only.
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Press the release button and remove the
shaving unit.
C3Turn the wheel anticlockwise and remove
the retaining frame.
C4Remove the shaving heads and place new
ones in the shaving unit.
ENGLISH10
2
1
1
2
C5Put the retaining frame back into the
shaving unit, press the wheel and turn it
clockwise.
Accessories
The following accessories are available:
- HQ100 Philips Action Clean (shaving head
cleaner).
- HQ101 Philips Action Clean refill
(shaving head cleaning liquid).
- HQ110 Philips shaving head cleaner
(shaving head cleaning spray).
- HQ4«Philips shaving heads.
Environment
The built-in rechargeable battery contains
substances that may pollute the environment.
Disposal of the battery
Remove the battery when you discard the
appliance. Do not throw the battery away with
the normal household waste, but hand it in at an
official collection point.You can also take the
appliance to a Philips service centre, which will
remove the battery for you and will dispose of it
in an environmentally safe way.
Only remove the battery if it is completely empty.
ENGLISH 11
1
2
1Remove the mains plug from the wall socket
and pull the appliance plug out of the shaver.
C2Let the shaver run until it stops, undo the
two screws and open the shaver.
3Remove the battery.
Do not connect the shaver to the mains again
after the battery has been removed.
Guarantee & service
If you need information or if you have a problem,
please visit the Philips Web site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet). If there is no Customer Care Centre in
your country, turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
Troubleshooting
1Reduced shaving performance
BCause 1: the shaving heads are dirty.
BThe shaver has not been cleaned well enough or
has not been cleaned for a long time.
◗Clean the shaver thoroughly before you
continue shaving (see chapter 'Cleaning and
maintenance').
ENGLISH12
