Philips HC7460 User manual

www.philips.com/welcome

Always here to help you

HC7460

ENGLISH 4

INDONESIA 11

한국어 19

BAHASA MELAYU 27

ภาษาไทย 35

TIẾNG VIỆT 42

繁體中文 49

简体中文 57

Introduction

Congratulations on your purchase and welcome to Philips!

To fully benet from the support that Philips offers, register your product

at www.philips.com/welcome.

General description (Fig. 1)

1 Cutting unit

2 Up button

3 Down button

4 On/off button

5 Length setting lock

6 Charging light

7 Display

8 Trimming comb 1-7mm

9 Trimming comb 7-24mm

10 Trimming comb 24-42mm

11 Adapter

12 Small plug

13 Cleaning brush

Important

Read this user manual carefully before you use the appliance and save it for

future reference.

Danger

- Keep the appliance and the adapter dry.

Warning

- The adapter contains a transformer. Do not cut off the adapter to

replace it with another plug, as this causes a hazardous situation.

- This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for

their safety.

- Children should be supervised to ensure that they do not play with

the appliance.

Caution

- This appliance is not washable. Never immerse the appliance in water,

nor rinse it under the tap.

- Always check the appliance before you use it. Do not use the

appliance, adapter or any other part if it is damaged, as this may cause

injury.

- Always replace a damaged adapter or part with one of the

original type.

- Only use this appliance for its intended purpose as shown in the user

manual.

- Never use compressed air, scouring pads, abrasive cleaning agents or

aggressive liquids such as petrol or acetone to clean the appliance.

ENGLISH

Electromagnetic elds (EMF)

This Philips appliance complies with all applicable standards and regulations

regarding exposure to electromagnetic elds.

General

- The appliance is equipped with an automatic voltage selector and is

suitable for mains voltages from 100 to 240 volts.

- The adapter transforms 100-240 volts to a safe low voltage of less

than 24 volts.

Charging

Charge the appliance fully before you use it for the rst time or after a long

period of disuse.

When it is charged for 1 hour, the appliance has a cordless operating time

of up to 120 minutes.

Note: After charging the appliance fully for the rst time, you can also use the

appliance directly from the mains. Simply connect the appliance to the mains.

Charging indications

Battery low indication

- When the battery is almost empty, the charging light starts to ash

orange.

Charging

- When the appliance is charging, the charging light ashes red.

Battery fully charged

- When the battery is fully charged, the charging light lights up red

continuously.

Note: After 30 minutes, the charging light switches off automatically.

Charging the appliance

1 Make sure the appliance is switched off.

2 Insert the small plug into the appliance.

3 Put the adapter in the wall socket.

4 After charging, remove the adapter from the wall socket and pull the

small plug out of the appliance.

ENGLISH 5

Optimising the lifetime of the rechargeable battery

When you have charged the appliance for the rst time, we advise you to

use it until the battery is completely empty. Continue to use the appliance

until the motor almost stops operating during a session.Then recharge the

battery. Follow this procedure at least twice a year.

Using the appliance

The hair length settings are indicated in millimeters.

The settings correspond to the remaining hair length after trimming.

Be careful when you trim for the rst time. Do not move the trimmer

too fast. Make smooth and gentle movements.

Tip: Start trimming at a high length setting and reduce the length setting

gradually until you have reached the desired hair length.

Trimming with comb

There are 3 different combs:

- 1-7mm

- 7-24mm

- 24-42mm

1 Attach one of the combs to the appliance.

2 Press up button or down button to select the desired length setting.

Note: When you trim for the rst time, start at the highest length setting to

familiarise yourself with the appliance.

3 Switch on the appliance.

ENGLISH6

4 To trim most effectively, move the trimmer against the hair growth

direction. Make sure that the surface of the comb always stays in

contact with the skin.

Trimming without comb

Use the trimmer without the trimming comb to trim hair close to the skin

(0.5mm) or to contour the neckline and sideburns.

Be careful when you trim without comb because the cutting

element removes every hair it touches.

1 Push the comb off the appliance.

2 Switch on the appliance.

3 Touch the hair lightly with the trimmer.

Make well-controlled movements.

Features

Length setting lock

This feature prevents accidental changing of the length setting during

trimming. Every time you switch on the appliance, the length setting lock

is activated.You can only change the length setting if you switch off the

appliance.

1 Press the up button or down button to select the length setting.

ENGLISH 7

2 Switch on the appliance.

,The lock symbol starts to ash. You cannot change the length

setting anymore.

Note: If you want to select a different length setting, switch off the appliance.

Press the up button or down button to select the desired length setting and

switch on the appliance again.

Cleaning

Never use scouring pads, abrasive cleaning agents or aggressive liquids

such as alcohol, petrol or acetone to clean the appliance.

Never immerse the appliance in water or rinse it under the tap.

Note: Only the cutting element and the comb can be cleaned with water.

1 Make sure the appliance is switched off and disconnected from

the mains.

2 Wipe the housing of the appliance with a dry cloth.

3 Remove the comb and clean it with the brush or rinse it under

the tap.

Caution: Make sure that the comb is dry before you reattach it to

the appliance.

4 P

ress the release button (1).The cutting unit comes off the appliance (2).

5 Clean the cutting unit with the brush or rinse it under the tap.

Shake off excess water and leave to dry.

Do not dry the cutting unit with a towel, as this may damage the cutting

element.

Caution: Make sure that the cutting unit is dry before you reattach it to

the appliance.

6 Clean the inside of the appliance with the cleaning brush.

Never immerse the appliance in water or rinse it under the tap.

ENGLISH8

7 Insert the lug of the cutting unit into the guiding slot (1) and push

the cutting unit back onto the appliance (2).

Note: If the message ‘CL’ is shown on the display, too much hair has collected

between the comb and the cutting unit. Remove the comb and cutting unit and

clean them with the cleaning brush supplied. Also clean the top edge of the

handle with the cleaning brush supplied.

Replacement

Only replace a worn or damaged cutting unit with an original Philips cutting

unit, available from authorised Philips service centre.

Press the release button (1).The cutting unit comes off the appliance (2).

2 Insert the lug of the new cutting unit into the guiding slot (1)

and push the cutting unit onto the appliance (2).

Ordering accessories

To buy accessories or spare parts, visit www.shop.philips.com/service

or go to your Philips dealer.You can also contact the Philips Consumer

Care Centre in your country (see the worldwide guarantee leaet for

contact details).

Recycling

Do not throw away the appliance with the normal household waste at

the end of its life, but hand it in at an ofcial collection point for recycling.

By doing this, you help to preserve the environment.

Removing the rechargeable battery

Note: We strongly advise you to have a professional remove the

rechargeable battery.

Only remove the rechargeable battery if it is completely empty.

1 Disconnect the appliance from the mains and let the appliance

operate until the motor stops.

ENGLISH 9

2 Press the release button (1) and remove the cutting unit (2).

3 Insert the screwdriver between the motor unit and the back panel

of the appliance. Press down the screwdriver as far as it will go

4 Tilt the handle of the screwdriver downwards (1) and separate

the back panel from the appliance (2).

5 Remove the side panels. Pull the bottom part of the printed circuit

board with the rechargeable battery attached from the appliance.

6 Cut the wires to separate the rechargeable battery from the

appliance.

Do not connect the appliance to the mains again after you have opened it.

Guarantee and support

If you need information or support, please visit www.philips.com/

support or read the separate worldwide guarantee leaet.

ENGLISH10
