Philips XL390 User manual
XL390
XL395
Register your product and get support at
www.philips.com/welcome
Quick start guide
1Connect
2Get started
3Enjoy
What is in the box
Base station
(XL395)
Base station
(XL390)
Charger*
Power adapter* Line cord**
Handset*
User manual, quick start guide, guarantee
Note
* In multi-handset packs, there are additional handsets,
chargers and power adapters.
**
In some countries, you have to connect the line adapter
to the line cord, then plug the line cord to the telephone
socket.
Caution
•Use only the supplied batteries and power adapter.
1Connect
Connect the base station
1 Connect each end of the power
adapter to:
•the DC input jack at the back
of the base station;
•the power socket on the wall.
2 Connect each end of the line
cord to:
•the telephone socket at the
back of the base station;
•the telephone socket on the
wall.
For multi-handset version only:
3 Connect each end of the power
adapter to:
•the DC input jack at the back
of the base station;
•the power socket on the wall.
2Get started
Congure your phone Charge your phone
Charge 8 hours
1 The batteries are pre-installed in the handset. Pull the
battery tape off from the battery door before charging.
2 Whenusingyourphoneforthersttime,youseea
welcome message (country dependent).
3 Set the country and language if prompted.
4 Set the date and time.
•If the time is in 12-hour format, press key to select
[am] or [pm].
Place the handset on the base station to charge the handset.
When the handset is placed correctly on the base station, you
hear a docking sound.
» The handset starts charging.
Note
•Chargethebatteriesfor8hoursbeforerstuse.
Check the battery level
Icon Status
When the handset is off the base station/charger,
the bars indicate the battery level (full to low).
When the handset is on the base station/charger,
thebarsashuntilchargingiscomplete.
Theemptybatteryiconashesandyouhearan
alert tone.
The battery is low and needs recharging.
3Enjoy
Call
•To make a call, press and dial the phone number.
•To answer a call, press when the phone rings.
•To end a call, press .
Adjust the earpiece volume
Press or to adjust the volume during a call.
Set the direct keys
1 Enter the number, then press and hold M1, M2 or M3.
2 Enter the name then press [OK]toconrm.
3 Enter the number, then press [Save]toconrm.
4 To make a quick call from the record pre-saved in the direct
key, press or , then press M1, M2 or M3.
Add a contact in the phonebook
1 Select [Menu] > [Phonebook] > [Add new], then
press [OK]toconrm.
2 Enter the name, then press [OK]toconrm.
3 Enter the number, then press [Save]toconrm.
Record an announcement
(for XL395 only)
1 Select [Menu] > [Answ. Machine] >
[Announcement], then press [OK]toconrm.
2 Select [Record also] or [Answer only], then press
[OK]toconrm.
3 Select [Record], then press [OK]toconrm.
4 Recording starts after the beep.
5 Press [OK] to stop recording or the recording stops after
3 minutes.
» You can listen to the newly recorded announcement on
the handset.
Listen to messages recorded on the
answering machine (for XL395 only)
cd
eb
af
a
To turn the answering machine on or off in standby mode,
press .
b
To start/stop listening, press .
c
To adjust the volume, press / .
d
To play the previous message/replay the current message,
press .
e
To play the next message, press .
f
To delete the current message, press .
Note
•For more information, see the Telephone answering
machine section in the user manual.
When this crossed-out wheeled
bin symbol is attached to a
product it means that the
product is covered by the European
Directive 2002/96/EC.
2013 © WOOX Innovations Limited.
All rights reserved.
Philips and the Philips’ Shield Emblem are
registered trademarks of Koninklijke Philips
N.V. and are used by WOOX Innovations
Limited under license from Koninklijke
Philips N.V.
QSG_XL390-395
05_EN_V2.0
WK14043
Welcome to Philips
Register your product at www.philips.com/welcome
Need help?
User manual
Refer to the user manual that came with your new phone.
Online help
www.philips.com/support
0168
