Philips CD4801B/TR User manual
Quick start guide
CD480/CD485
Note
*In multi-handset packs, there
are additional handsets,
chargers and power adapters.
** In some countries, you have
to connect the line adapter to
the line cord, then plug the line
cord to the telephone socket.
Caution
Use only the supplied batteries•
and power adapter.
What’s in the box
Handset*
Base station (CD485) Base station (CD480)
Charger*Power adapter*Line cord**
User manual
Quick start guide
Guarantee
Connect the base station
Telephone
socket
Power
socket
Power
adapter
Power
socket
Extra handset
charger
Telephone
base station
2
1 3
Connect each end of the power adapter to:
1
the DC input jack at the bottom of the base station;•
the power socket on the wall.•
Connect each end of the line cord to:
2
the telephone socket at the bottom of the base station;•
the telephone socket on the wall.•
For multi-handset version only:
Connect each end of the power adapter to:
3
the DC input jack at the bottom of the extra handset charger.•
the power socket on the wall.•
1Connect
2Get started
Congure your phone
The batteries are pre-installed in the handset. Pull the battery
1
tape off from the battery door before charging.
Whenusingyourphoneforthersttime,youseeawelcome
2
message (country dependent).
Please set the country and language if prompted.
3
Set the date and time.
4
If the time is in 12-hour format, press• / key to select
[AM]
or
[PM]
.
Charge your phone
Charge
8 hours
Place the handset on the base station to charge the handset.
When the handset is placed correctly on the base station, you
hear a docking sound.
The handset starts charging.»
NoteChargethebatteriesfor8hoursbeforerstuse.
Check the battery level
When the handset is off the base station/charger, the
bars indicate the battery level (full, medium and low).
When the handset is on the base station/charger, the
barsashuntilchargingcompletes.
Theemptybatteryiconashesandyouhearanalert
tone.
The battery is low and needs recharging.
Please set your language if
1
prompted. [cd68x]
3Enjoy
Call
To make a call, press• and dial the phone number.
To answer a call, press• when the phone rings.
To end a call, press• .
Adjust the earpiece volume
Press or to adjust the volume during a call.
Add a contact in the phonebook
Press
1
.
Select
2 [Option]
>
[Add new]
, then press
[OK]
to
conrm.
Enter the name then press
3 [OK]
toconrm.
Enter the number, then press
4 [Save]
toconrm.
Record an announcement
(for CD485 only)
Press
1 [Menu]
.
Select
2
>
[Announcement]
, then press
[OK]
to
conrm.
Select
3 [Answer only]
or
[Record also]
, then press
[OK]
toconrm.
Select
4 [Record new]
, then press
[OK]
toconrm.
Start recording close to the microphone after the beep.
5
Press
6 [OK]
to stop recording.
You can listen to the newly recorded»
announcement on the handset.
Listen to messages recorded on the answering machine (for CD485 only)
c
d
f
a
b
e
Switch on/off the answering machine: Pressa .
Start/Stop listening to the recorded messages: Press
b .
Adjust the volume: Press
c / .
Skip backward:d
When you listen to the messages, press to listen to the
message from the beginning.
Duringtherstsecondofthecurrentmessage,press to listen
to the previous message.
Skip forward: Presse to skip to the next message.
Delete the current message: Pressf .
Note For more information, see the Telephone answering machine
section in the user manual.
Need help?
User manual
Refer to the user manual that came with your new phone.
Online help
www.philips.com/support
Welcome to Philips
Register your product at www.philips.com/welcome
Reproduction in whole or in part is prohibited
without the written consent of the copyright owner.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2011 Koninklijke Philips Electronics N.V.
All rights reserved. QSG_CD480-485_05_EN_V2.1
WK11304
0979
