Philips AJ6000/05 User manual

www.philips.com/welcome

Always there to help you

AJ6000/05

User manual

Question?

Contact

Philips

Contents

1 Important 3

2 Your clock radio 3

What's in the box 3

Overview of the main unit 4

3 Get started 5

Connect power 5

Set time 6

Turn on 6

4 Listen to FM radio 7

Tune to FM radio stations 7

Store FM radio stations manually 7

Store FM radio stations automatically 7

Select a preset radio station 7

5 Other features 8

Set alarm timer 8

Set sleep timer 9

Play audio from an external device 9

Adjust display brightness 9

6 Product information 10

Specications 10

7 Troubleshooting 10

8 Notice 11

3EN

1 Important

Warning

•Never remove the casing of this clock radio.

•Never lubricate any part of this clock radio.

•Never place this clock radio on other electrical

equipment.

•Keep this clock radio away from direct sunlight, naked

amesorheat.

•Make sure that you always have easy access to the

power cord, plug or adaptor to disconnect the clock

radio from the power.

• Make sure that there is enough free space

around the product for ventilation.

• The clock radio shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on the

clockradio(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

• Only use power supplies listed in the user

manual.

• Battery usage CAUTION – To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove batteries when the unit is not

used for a long time.

• The batteries should not be exposed

toexcessiveheatsuchassunshinere

or the like.

2 Your clock radio

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

What's in the box

AJ6000

User Manual

www.philips.com/welcome

Always there to help you

Registeryour product and get support at

Question?

Contact

Philips

4EN

Overview of the main unit

a SOURCE

• Select a source.(FM/AUDIO IN)

• Press and hold for 3 seconds to switch

to standby mode.

b SLEEP

• Set sleep timer.

c SNOOZE/BRIGHTNESS

• Snooze alarm.

• Adjust display brightness.

d Display panel

• Show current information.

e AL1/AL2

• View alarm settings.

• Activate or deactivate alarm timer.

NIOIDUA

f VOLUME +/-

• Adjust volume.

g First Knob (HOUR/PRESET)

• Adjust hour.

• Select a preset radio station.

h Second Knob (MINUTE/TUNING)

• Adjust minute.

• Tune to an FM radio station.

• Skip to the previous or next track.

i Third Knob (SET TIME/SET RADIO/

CLOCK/SET AL1/SET AL2)

• Set clock.

• Scan/store FM radio stations.

• Set alarm.

5EN

j BUZZ/FM/SOUND 1/SOUND 2

• Select an alarm source for Alarm 1 and

Alarm 2.

k (5.0 V 1 A)

• Charge your iPod/iPhone through USB

cable (not included).

l AUDIO IN

• Connect an external audio device.

m FM ANT

• Improve FM reception.

3 Get started

Always follow the instructions in this chapter in

sequence.

Connect power

The unit can only be powered by supplied AC

power. Batteries are only used for alarm backup

if not connected with AC power.

Option 1:AC power

Warning

•Risk of product damage! Make sure that the power

supply voltage corresponds to the voltage printed on

the back or the underside of the unit.

•Risk of electric shock! When you disconnect the AC

power, always pull the plug from the socket. Never pull

the cord.

Connect the AC power cord to the wall socket.

Tip

•To save energy, turn the unit off after use.

6EN

Option 2: Battery power

Caution

•Batteries contain chemical substances, so they should

be disposed of properly.

Note

•Batteries are not supplied with the accessories.

•bAt shows on the display when the battery level is low.

1 Open the battery compartment.

2 Insert 2 batteries (type: 1.5V LR6/AA) with

correct polarity (+/-) as indicated.

3 Close the battery compartment.

Set time

1 Rotate the Third Knob to "SET TIME" to

activate clock setting mode.

» Hour and minute digits blinks.

2 Rotate the First Knob to adjust the hour.

3 Rotate the Second Knob to adjust the

minute.

4 Press OK on the First Knobtoconrm.

» The setting time is displayed.

5 Rotate the Third Knob to CLOCK after

setting.

» The hour and minute digits stops

blinking.

Turn on

The clock radio turns on automatically once

your plugged in.

Switch to standby mode

Press SOURCE for 3 seconds to switch to

standby mode.

» The source indicator on the display

panel turns off.

7EN

4 Listen to FM

radio

Tune to FM radio stations

Tip

•Position the antenna as far as possible from TV,VCR, or

other radiation source.

•For better reception, fully extend and adjust the

position of the antenna.

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

1 Press SOURCE repeatedly to select FM

tuner source.

» FM on the display panel lights up.

2 Rotate and hold the Second Knob for two

seconds.

» The clock radio tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune in to more radio

stations.

To tune to a station manually:

Rotate the Second Knob repeatedly until you

ndoptimalreception.

Store FM radio stations

manually

1 In FM mode,rotate the Third Knob to

"SET RADIO".

» FM begins to blink.

2 Rotate and hold the Second Knob for 2

seconds.

» The last selected channel show on the display.

3 Rotate the First Knob again to select the

target preset position.

4 Press OK on the First Knobtoconrm.

5 Repeat steps 2-4 to store other stations.

Note

•To remove a pre-stored station, store another station

in its place.

Store FM radio stations

automatically

Note

•You can store a maximum of 20 FM radio stations.

1 In FM mode, rotate the Third Knob to

"SET RADIO".

» FM begins to blink.

2 Press an hold OK on the First Knob for 3

seconds.

» The clock radio stores all the available

FM radio stations, and broadcasts the

rstavailablestationautomatically.

Select a preset radio station

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

1 Press SOURCE repeatedly to select FM

tuner source.

» FM on the display lights up.

2 Rotate the First Knob repeatedly to select

a preset radio station.

8EN

5 Other features

Set alarm timer

In standby mode, you can set two alarms to ring

at different time.

Note

•Make sure that you have set the clock correctly.

1 Rotate the Third Knob to SET AL1 or SET

AL2 to activate alarm setting mode.

» The / and time digits blink.

2 Rotate the First Knob to adjust the hour.

3 Rotate the Second Knob to adjust the

minute.

4 Press OK on First Knobtoconrm.

5 Rotate the Third Knob to CLOCK after

setting.

Select alarm source

For alarm sound, you can select buzzer, or your

last listened radio chanel.

Tip

•If FM is selected as the alarm source and the unit is

playing under FM mode, buzzer will sound when alarm

time comes.

Activate/deactivate alarm timer

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

1 Press AL1/AL2 to view alarm settings.

» The / lights up.

2 Press AL1/AL2 again to activate or

deactivate the alarm timer.

» The / appears if alarm timer is

on and disappears if it is off.

• To stop the ringing alarm, press the

corresponding AL1/AL2.

» The alarm repeats ringing for the next

day.

Snooze the alarm

When alarm sounds, press SNOOZE.

» The alarm snoozes and repeats ringing

nine minutes later.

ALARM

BUZZ 12

9EN

Set sleep timer

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

This clock radio can switch to standby mode

automatically after a preset period.

• Press SLEEP repeatedly to select the sleep

timer period (in minutes).

» When the sleep timer is activated,

appears.

To deactivate the sleep timer:

• Press SLEEP repeatedly until [OFF] (off)

appears.

Play audio from an external

device

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

You can listen to audio from an external device

through this clock radio.

1 Connect an audio cable to:

• the AUDIO IN socket on the clock

radio.

• the headphone socket on an external

device.

2 Press SOURCE repeatedly to select the

Audio-in source.

» The on the display panel lights up.

3 Play the external device (refer to its user

manual).

15 30 60 90 120

OFF

Adjust display brightness

SNOOZE

BRIGHTNESS

10EN

6 Product

information

Note

•Product information is subject to change without prior

notice.

Specications

Amplier

Rated Output Power 1W RMS

Tuner

Tuning Range FM: 87.5 - 108

MHz

Sensitivity

- Mono, 26dB S/N Ratio

FM: <22 dBf

Search Selectivity FM: <30 dBf

Total Harmonic Distortion FM: <3%

Signal to Noise Ratio FM: >50 dBA

General information

Power supply

- AC Power

- Battery

Model:

ASSA36B-050250;

Input: 100-240 V ~,

50/60Hz, 0.6A;

Output: 5.0V 2500 mA

2 x AA batteries

Operation Power

Consumption

<15 W

Standby Power

Consumption

<1 W

Dimensions - Main

Unit (W x H x D)

195 x 99 x 123 mm

Weight - Main Unit 0.65 kg

7 Troubleshooting

Warning

•Never remove the casing of this device.

To keep the warranty valid, never try to repair

the system yourself.

If you encounter problems when using this

device, check the following points before

requesting service. If the problem remains

unsolved, go to the Philips Web page (www.

philips.com/support).When you contact Philips,

make sure that the device is nearby and the

model number and serial number are available.

No power

•Ensure that the power cord is connected

securely.

•Ensure that there is power at the power

supply socket.

•Ensure that the batteries are installed

correctly.

No response from the clock radio

•Disconnect and reconnect the AC power

plug, then turn on the clock radio again.

Poor radio reception

•Keep the clock radio away from other

electronic devices to avoid radio

interference.

•Fully extend and adjust the position of the

FM antenna.

Alarm does not work

•Set the clock/alarm correctly.

Clock/alarm setting erased

•Power has been interrupted or the power

plug has been disconnected.

•Reset the clock/alarm.

Other manuals for AJ6000/05

Table of contents

Other Philips Clock Radio manuals

Popular Clock Radio manuals by other brands

Denver

Denver CRQ-105 quick start guide

Audiovox

Audiovox CE90 Operation instructions

Sony

Sony Dream Machine ICF-C763L operating instructions

Sanyo

Sanyo DMP-P6 instruction manual

RCA

RCA RPC100 user manual

Yamaha

Yamaha ISX-80 owner's manual

Pyle

Pyle PLMR20W user manual

Blaupunkt

Blaupunkt CR7BK user manual

HoMedics

HoMedics SS-5500-2EU instruction manual

RCA

RCA RC66i user manual

Versaudio

Versaudio Vers user manual

SOUNDMASTER

SOUNDMASTER UR8100 instruction manual

Audiovox

Audiovox CE90 operating instructions

Jensen Audio

Jensen Audio JCR-222 - AM/FM Projection Alarm Clock Radio instruction manual

Roberts

Roberts ChronoDAB user manual

AEG

AEG MRC 4132 BT instruction manual

Tokai

Tokai TC-155 user manual

Timex

Timex T300 manual
