Philips AQ6345 User manual

Headphone stereo

Memo recorder

• Voice-activated recording

Activates the unit’s recording mechanism only when there’s an

audible sound source, and pauses the tape recorder when there is

silence.

• Background noise suppression

Suppresses all background noise so that only your voice is picked

up by the microphone.

• Cue/Review, Fast Forward, Rewind

Provides audible scanning through the tape to find a specific

passage.

• 3-Digit tape counter

Enables you to manually index the recorded information on a

cassette very precisely.

• Built-in Flat Mic

• Built-in speaker

• Recording with LED indication

• Headphone socket

• Pause switch

6345

Headphone stereo

Standard product information

http://www.philips.com

1999-12-10

Printed in Hong Kong

Subject to modification without notice

Product highlights

• Reocrding with LED indication

LED that lights up to indicate that recording is in progress.

• Built-in Flat Mic

High-quality built-in condenser microphone for excellent quality sound

recording

• Built-in speaker

High-quality speaker that enables you to listen directly to the recorded

information.

• Headphone socket

Enables headphones to be used for private listening pleasure, without

disturbing others.

• Pause switch

Switch that stops tape movement in playback or record mode.

Cassette deck

• 5-key cassette memo recorder

• 3-digit tape speed counter

• Recording with LED indication

• Flat mic recording

• Voice activated switch

• Normal (type 1) cassette tape

• Frequency response : 150 Hz - 8 kHz

Amplifier

• Max. output power : 150mW RMS

• Background noise suppression

Sound system

• Loudspeaker : 36 mm, 4 ohms

Power supply

• Batteries : 2 x 1.5V, type AA/R6P cell

• External supply : 3 V DC

• Optional : Philips AC adaptor - SBC 6650

Connections

• Headphone socket : 3.5mm

• External mic socket : 3.5mm

General

• Material : polystyrene, metal speaker grill

• Weight : 0.24g excluding batteries

• Dimensions : 91 mm W x 112 mm H x 34 mm D

• Quantity/ mastercarton : 12

6345
