Philips SDW5225GN User manual

For preview purpose only

Enjoy the best connection

for satellite and digital TV

Enjoy premium picture quality with virtually no signal loss. Connects satellite, antenna

and digital cable sources to components.

Enjoy the best reception quality

• 3X faster than standard RG6 coax

• 24 carat gold-plated connectors optimize signal

• 18 AWG copper-coated steel center conductor

Enjoy extended durability

• Heavy-duty pliable jacket

• Corrosion-resistant connectors

Protects against signal loss

• Dielectric insulation

• Aluminum braided shield

• Aluminum foil shield

Easy installation

• Non-slip ergonomic grip for easy use

Philips

Quad Shield Cable

250 ft

RG6 Spool

SDW5225GN

For preview purpose only

SDW5225GN/17

Technical specifications Product highlights

Quad Shield Cable

250 ft RG6 Spool

Date of issue 2006-10-21

Version: 2.0

12 NC: 9082 100 09621

UPC: 6 09585 11895 9

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

Packaging Data

•EAN/UPC/GTIN: 6 09585 11895 9

•Gross weight: 5kg

•Height: 152 mm

•Length: 267 mm

•Net weight: 4.27 kg

•Tare weight: 0.73 kg

•Width: 260 mm

•

3X faster than RG6 coax

Transferring the signal at a far greater speed than

standard coaxial cable minimizes signal loss, so you enjoy

optimum picture quality and data transfer.

24Carat Gold Plated Connectors

24 carat gold-plated connectors ensure the best signal

quality for your components.

18 AWG copper-coated conductor

The highly conductive composition of this signal conduit

maximizes signal transfer for optimum picture quality

and data transfer.

Heavy-duty pliable jacket

Pliable PVC sheathing surrounds the cable, protecting it

from wear and tear and ensuring lond-term durability.

Corrosion-resistant connectors

Compressed brass with 24K gold-electroplated

connectors creates a secure and extremely durable

connection that optimizes signal quality and delivers the

best picture and data transfer.

Dielectric insulation

Superior insulation material separates the center

conductor from the braided shield. By isolating the

conductors, it maintains signal integrity, ensuring the best

picture quality and optimum data transfer.

Aluminum braided shield

In concert with the aluminum foil shield, this shield works

as a barrier to keep the signal inside the conductors and

keep interference out.

Aluminum foil shield

In concert with the aluminum braided shield, this shield

works as a barrier to keep the signal inside the conductors

and keep interference out.

Easy grip

This non-slip grip makes connecting your components

easy and ergonomically comfortable.
