Philips SDW5162O User manual

For preview purpose only

The best connectors

for satellite and digital TV

These high grade coaxial cable connectors ensure minimum signal loss for a better,

brighter picture. Includes four.

Easy installation

• For use with compression tool

Enjoy a better, brighter picture

• Minimum signal loss

• Secure cable connection

Philips

Connectors

Quad Shield

SDW5162O

For preview purpose only

SDW5162O/17

Technical specifications Product highlights

Connectors

Quad Shield

Date of issue 2006-10-21

Version: 3.0

12 NC: 9082 100 09856

UPC: 6 09585 11992 5

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

Packaging

•EAN/UPC/GTIN: 6 09585 11992 5

•Quantity: 1

•Gross Weight: 0.40 kg

•Tare Weight: 0.10 kg

•Net Weight: 0.30 kg

•Length: 14.6 cm

•Width: 9.5 cm

•Height: 3.2 cm

Inner Carton

•EAN/UPC/GTIN: 1 06 09585 11992 2

•Quantity: 6

•Gross Weight: 3.40 kg

•Tare Weight: 0.50 kg

•Net Weight: 2.90 kg

•Length (cm): 16.7 cm

•Width (cm): 9.2 cm

•Height (cm): 10.9 cm

Outer Carton

•EAN/UPC/GTIN: 2 06 09585 11992 9

•Quantity: 72

•Gross Weight: 16.4 kg

•Tare Weight: 3.40 kg

•Net Weight: 13.0 kg

•Length (cm): 35.3 cm

•Width (cm): 28.5 cm

•Height (cm): 29.0 cm

•

For use with compression tool

A compression tool offers a more secure way of affixing

the connectors to the cable and TV. Compression tool not

included.

Minimum signal loss

Signal information is inevitably lost going from any digital

source to any TV. Minimum signal loss means you only

lose the least amount of that signal information.

Secure cable connection

Connectors are crimped on for the most secure

connection, minimizing signal loss and ensuring long

lasting durability.
