PEUGEOT ION User manual

Handbook

Please note the following point:

The fitting of electrical equipment or accessories which are not recommended by PEUGEOT may result in a failure of your vehicle's

electronic system. Please note this specific warning. It is advisable to contact a PEUGEOT dealer to be shown the recommended

equipment and accessories.

PEUGEOT's SERVICE BOX Internet site permits easy and free

consultation of your vehicle documentation on line.

Your vehicle lives on the Internet!

Access the latest information available.

Connect to http://public.servicebox.peugeot.com:

Simple and user friendly, SERVICE BOX allows you access:

●to your Handbook,

●to previous Vehicle documentation.

select your language,

click on the link in the "Private customer access" zone to

consult the Vehicle documentation,

A window opens giving access to all of the handbooks...

select your vehicle,

choose its body type then the date of publication of the handbook,

finally, click on the item which is of interest to you.

WELCOME

Key

Warning:

this symbol marks warnings which it

is essential to observe for your own

safety, for the safety of others or to

avoid any risk of damaging your vehicle.

Information:

this symbol draws your attention to

additional information for better use of

your vehicle.

Protection of

the environment:

this symbol accompanies advice

relating to protection of the environment.

Page reference:

this symbol invites you to refer to

the pages which provide details of

the function.

Thank you for choosing an ION, a symbol of

confidence, passion and inspiration.

ION is the first 100% electric vehicle for

PEUGEOT, 0% pollutant emissions when

driving and particularly quiet.

This handbook has been designed to enable

you to make the most of your ION in all

circumstances.

On the first few pages, you will find a detailed

summary, followed by a quick reference guide

intended to make it easier for you to become

familiar with your electric vehicle.

All of the details specific to your ION, comfort,

safety, driving, are then presented in this

handbook to increase your appreciation of the

vehicle and allow you to make full use of its

abilities.

Your vehicle is fitted with only some of the

equipment described in this document,

depending on its trim level, version and the

specification for the country in which it was sold.

Find out more from the PEUGEOT dealer network.

Contents

Instrument panel 18

Indicator and warning lamps 19

Main battery state of charge indicator 26

Energy consumption/generation indicator 27

Distance recorder 28

Trip distance recorder 28

Lighting dimmer 29

Service indicator 29

Range indicator 30

Instruments and controls

Familiarisation

Remote control key 31

Electric windows 34

Doors 35

Boot 36

Charging ﬂaps 37

Access

Front seats 38

Rear seats 40

Mirrors 42

Interior ﬁttings 44

Heating and Ventilation 47

Air conditioning 49

Rear screen demist - defrost 51

Comfort

Starting - stopping the vehicle 52

Manual parking brake 53

Drive selector 54

Driving

Lighting stalk 56

Automatic illumination of headlamps 58

Headlamp adjustment 58

Wiper controls 59

Courtesy lamp 60

Visibility

Contents

Child seats 61

ISOFIX child seats 65

Child lock 68

Child safety

Direction indicators 69

Hazard warning lamps 69

Horn 69

Emergency or assistance call 70

Braking assistance systems 70

Trajectory control systems 72

Front seat belts 73

Airbags 76

Safety

Charging the main battery 80

Ancillaries battery 86

Temporary puncture repair kit 90

Changing a wheel 94

Changing a bulb 97

Changing a fuse 105

Changing a wiper blade 110

Towing the vehicle 110

Precautions for washing 111

Accessories 111

Practical information

Bonnet 114

Front compartment 115

Rear compartment 116

Checking levels 117

Checks 119

Checks

Electric motor 120

Weights 121

Dimensions 122

Identiﬁcation markings 123

Technical data

Emergency or assistance 125

Audio system 127

Audio equipment and telematics

Visual search

Alphabetical index

Familiarisation

Normal charging ﬂap

This flap should be used to recharge your

vehicle from a domestic power point.

Fast charging ﬂap

This flap should be used to recharge your

vehicle from a special fast charging station.

Temporary puncture repair kit

This kit is a complete system consisting of a

compressor and a sealant cartridge, to allow

the temporary repair of a tyre.

Exterior

ASR and ESP systems

These are associated systems that assure

the directional stability of the vehicle, within

the limits of the laws of physics.

.Familiarisation

Access

A. Unfolding/Folding the key.

B. Locking the vehicle.

C. Unlocking the vehicle.

Remote control key Bonnet

114

Electric windows

A. Release lever.

B. Safety catch.

C. Bonnet stay.

A. Driver's electric window switch.

B. Passenger's electric window switch.

C. Right hand rear electric window switch.

D. Left hand rear electric window switch.

E. Deactivating the passenger and rear

electric window switches.

Familiarisation

Interior

Drive selector

Four-position drive selector: P, R, Nand D.

Charging ﬂap interior opening

controls

Air conditioning

After setting the desired level of comfort,

the system controls this level according

to the exterior climatic conditions.

Audio system

This system benefits from the latest

technology: MP3 compatible audio system,

USB player, Bluetooth hands-free system, ...

127

Normal charging flap.

Fast charging flap.

.Familiarisation

Instruments and controls

1. Lighting and direction indicator stalk

2. Instrument panel.

3. Driver's airbag.

Horn.

4. USB port.

5. Opening control for the fast charging flap

(vehicle left hand side).

6. Electric window switches and switch

for deactivating the the front and rear

passenger electric window controls.

7. Fusebox.

8. Opening control for the normal charging

flap (vehicle right hand side).

9. Headlamp height adjustment.

ASR/ESP deactivation switch.

10. Door mirror controls.

11. Cup holder.

12. Side vents.

13. Window demisting vent.

Familiarisation

Instruments and controls

1. Steering lock and ignition switch.

2. Wiper stalk.

3. Windscreen demisting vents.

4. Glove box.

Passenger's airbag deactivation.

5. Bonnet release lever.

6. Parking brake.

7. Drive selector.

8. 12 V accessory socket.

9. Heating/air conditioning controls.

10. Emergency or assistance call.

11. Hazard warning switch.

12. Centre vents.

13. Audio system.
