Permobil Total Control Head Array User manual
Total Control Head Array
User manual |American English
Welcome to the Permobil family
We congratulate you on your choice of alternative drive for
your power wheelchair. Our goal is for you to continue to feel
satisfied with your choice of both vendor and product.
Before you begin using your Total Control Head Array, it is
important that you read and understand the content of these
operating instructions, and in particular the safety instructions
and warning texts.
How to contact Permobil
ermobil Inc.
300 Duke Drive
Lebanon, TN 37090
USA
+1 800 736 0925
+1 800 231 3256
www.permobil.com
roduction units. See page 19.
Head office of the Permobil group
ermobil AB
er Uddéns väg 20
861 36 Timrå
Sweden
+46 60 59 59 00
www.permobil.com
Produced and published by Permobil
Edition: 2
Date: 2022-04-13
Order no: 338998 eng-US
1 Introduction
The Total Control Head Array is intended to be installed on
ermobil power wheelchairs equipped with R-net electronics.
ermobil power wheelchairs are intended for people limited to
a seated position. For additional information regarding your
wheelchair, refer to any other documentation received with
your wheelchair or contact your ermobil dealer.
All information, pictures, illustrations and specifications are
based upon the product information available at the time these
operating instructions were printed. ictures and illustrations
used in these operating instructions are representative examples
and not intended to be exact depictions of the various parts of
the Total Control Head Array. ermobil reserves the right to
make changes to the product without prior notice.
4- Introduction
2 Safety
Important safety instructions. Save these instructions.
ermobil is not responsible for personal injuries or property
damage resulting from any person’s failure to follow the
warnings and instructions in this manual, or from failure to
exercise good judgment.
2.1 Types of warning signs
The following types of warning signs are used in this manual:
WARNING!
Indicates a hazardous situation which, if not avoided, could
result in serious injury or death as well as damage to the
product or other property.
CAUTION!
Indicates a hazardous situation which, if not avoided, could
result in damage to the product or other property.
IMPORTANT!
Indicates important information.
2.2 Warnings
WARNING! Vehicle seating requirements
The Total Control Head Array is not a headrest. If you use the
wheelchair as a seat in a motor vehicle, you must replace the
head array with a headrest approved by the wheelchair
manufacturer. If you do not, it can lead to bodily injury.
WARNING! Difficulty of use increases
when tilted
If the seat or backrest is tilted, you will require more strength
to move your head outside the activation zones to stop the
wheelchair from moving. Be sure that you can always lift your
head away from the activation zones. If you are unable to do
so, the wheelchair can injure you.
WARNING! Drive extra carefully when
lifted or tilted
If the seat or backrest is lifted or tilted while the wheelchair is
on flat ground, drive at a low speed. If the seat or backrest is
lifted or tilted, do not drive the wheelchair on slopes or over
obstacles. If you do, the wheelchair can become less stable
and injure you.
Safety - 5
WARNING! Do not remove the covers
The electronic sensors are sensitive to water and moisture.
Make sure that the electronic sensors are protected by their
covers. Do not remove the covers. If you do, moisture can
cause the sensors to inadvertently activate the wheelchair and
you can be injured.
WARNING! Risk of water build-up
The electronic sensors are sensitive to water and moisture.
Avoid getting the covers wet. If they do get wet, for example
from wet hair or rain, the covers may retain moisture that can
cause an inadvertent delayed activation of the wheelchair and
you can be injured.
WARNING! Covers must be completely dry
before use
The electronic sensors are sensitive to water and moisture.
Make sure that the covers are completely dry, both inside and
outside, before replacing them on the sensor pads. Make sure
that the covers are fitted correctly on the sensors and are not
inside out. If any moisture remains in the covers, it can cause
the sensors to inadvertently activate the wheelchair and you
can be injured.
WARNING! Replace damaged or torn
covers
The electronic sensors are sensitive to water and moisture.
Make sure that the covers are whole. Damaged or torn covers
must be replaced with Permobil parts. If the covers get
damaged or torn, moisture can cause the sensors to
inadvertently activate the wheelchair and you can be injured.
CAUTION! Cleaning requirements
For minor spot cleaning, the covers can be cleaned with a
damp cloth and mild detergent. Turn off the power before
cleaning. If more thorough cleaning is needed, follow the
washing instructions on the cover. Make sure that the cover is
dry before replacing it.
IMPORTANT! Scrapping and recycling
Electronics should be disposed of responsibly in accordance
with local recycling regulations. Contact Permobil for informa-
tion about scrapping agreements in force.
6- Safety
IMPORTANT! Electromagnetic fields
The electronics in a power wheelchair can be affected by
external electromagnetic fields (for example mobile phones).
Similarly, the electronics in the wheelchair itself also emit
electromagnetic fields that can affect the immediate sur-
roundings (for example certain alarm systems in businesses).
Safety - 7
3 Overview
The Total Control Head Array is not a headrest.
It is a device that makes it possible to operate the
wheelchair with something other than a standard
joystick. It can operate all the modes and
functions of your power wheelchair. Your
healthcare provider will tailor the operation of
your head array system to meet your individual
needs and then they will train you to use your
Total Control Head Array.
Before you start using the Total Control Head
Array in public places, we recommend that you
try it out several times in an area with familiar
surroundings, so that you become comfortable
with operating your power wheelchair using the
Total Control Head Array.
8- Overview
3.1 Activation zones
Occipital pad has two proximity sensors. Control arms and can have
either proximity sensors or egg switches.
Activation zones for proximity sensors , , and , are shown as a gradient
shading. The lesser amount of shading indicates where the sensors can begin
to activate the control arms.
If your head array is configured with egg switches, pushing against egg
switches and will activate the control arms.
For instructions on how the activation zones correspond to the default
driving modes, see chapter 4.2
Driving modes
, page 14.
If the configuration of your head array needs to be adjusted, contact your
healthcare provider for assistance.
Overview - 9
3.2 The on/off switch and cable ports
On/off switch is located on the back of the occipital control module.
Additional cable ports can be found on the connection panel, which is
located on the underside of the occipital control module.
The functionality of the cable ports are as follows:
mode
left
forward/rearward
rearward only
right
on/off
