Permobil F3 Corpus User manual

F3 Corpus

User manual |British English

Welcome to the Permobil family

We hope that you enjoy your new powered wheelchair.

Permobil's founder, Dr. Per Uddén, believed that every person

has the right to have his or her disability compensated as far as

possible using the same technology that we all use in our

everyday life. Your new wheelchair is a state of the art

medical device designed to achieve this goal by providing

unparalleled convenience, comfort, and technology.

How to contact Permobil

Permobil Ltd. (+44) (0)1484

722 888

Regus 6th floor (+44) (0)1484

723 013

2 Kingdom

Street

info@permobil.

Paddington www.permobil.

com

W2 6BD

London

United

Kingdom

Production units. See page 72.

Local offices. See page 73.

Head office of the Permobil group

Permobil AB

Per Uddéns väg 20

SE 861 36 Timrå

Sweden

+46 60 59 59 00

Produced and published by Permobil

Edition: 4

Date: 2019-12-14

Order no: 335303 eng-UK

Welcome to the Permobil family

We hope that you enjoy your new powered wheelchair.

Permobil's founder, Dr. Per Uddén, believed that every person

has the right to have his or her disability compensated as far as

possible using the same technology that we all use in our

everyday life. Your new wheelchair is a state of the art

medical device designed to achieve this goal by providing

unparalleled convenience, comfort, and technology.

[email protected]

www.permobil.com

Produced and published by Permobil

Edition: 4

Date: 2019-12-14

Order no: 335303 eng-UK

Welcome to the Permobil family

We hope that you enjoy your new powered wheelchair.

Permobil's founder, Dr. Per Uddén, believed that every person

has the right to have his or her disability compensated as far as

possible using the same technology that we all use in our

everyday life. Your new wheelchair is a state of the art

medical device designed to achieve this goal by providing

unparalleled convenience, comfort, and technology.

Produced and published by Permobil

Edition: 4

Date: 2019-12-14

Order no: 335303 eng-UK

1 Introduction 6

2 Overview 7

2.1 Wheelchair specification 8

2.2 Tool bag 9

2.3 General control panel 10

2.4 Omni2 11

2.5 Connected wheelchair 12

2.6 Lights and reflectors 13

2.7 Wheels 14

2.8 Tie-down points 15

2.9 Serial number label 16

2.10 Accessories 17

2.11 Spare parts 18

2.12 User manual 19

3 Safety 20

3.1 Types of warning signs 20

3.2 Warning signs 20

3.3 Labels 24

4 Wheelchair usage 26

4.1 Driving the wheelchair 26

4.2 Support wheels 29

4.3 Seat functions 30

4.4 Charging the batteries 34

4.5 Freewheel mode 34

4.6 Vehicle transportation 35

4.7 Air transportation 38

4.8 Rail transportation 40

4.9 Main circuit breaker 40

4.10 Wheelchair storage 40

4.11 Manual adjustments 41

4.11.1 Headrest 41

4.11.2 Headrest with link hardware 43

4.11.3 Backrest tilt 45

4.11.4 Removing the backrest 46

4.11.5 Armrest 46

4.11.6 Leg rest tilt 51

4.11.7 Footplates 51

4.11.8 Lumbar support 53

4.11.9 Trunk support 54

4.11.10 Knee support 55

4.11.11 Rotational panel holder 56

4.11.12 Parallel panel holder 58

4.11.13 Positioning belt 60

5 Maintenance 61

5.1 Maintenance and inspection schedule 62

5.2 Cleaning 64

5.3 Inflating the drive wheel tyres 65

5.4 Inflating the castor wheel tyres 66

5.5 Positioning belt 66

6 Restrictions and limitations 67

7 Troubleshooting 68

8 General information 70

8.1 Guarantee 70

8.2 Product approval 70

8.3 Reporting incidents 70

8.4 Disposal and recycling 70

8.5 Technical specifications 71

1 Introduction

Before you use your wheelchair for the first time, you must

read and understand the contents of this user manual. It

instructs you on how to properly and safely use and care for

your wheelchair. This user manual and additional information

concerning our products are available at www.permobil.com or

by telephone.

Your powered wheelchair is a complex medical device

prescribed to you by your healthcare provider and configured

to meet your needs. Permobil is not responsible for

inappropriate prescription or selection of models or features, or

for improper use of or modifications to the wheelchair.

6- Introduction

2 Overview

This chapter gives you an overview of your

wheelchair. The parts on the overview

illustration are described in more detail

throughout the manual.

The F3 Corpus is a front wheel drive powered

wheelchair for outdoor and indoor driving. It is

intended for people limited to a seated position.

The expected service life of this product is five

years.

A. Armrest

B. Control panel

C. Seat

D. Light

E. Leg support

F. Support wheel

G. Footplate

H. Headrest

I. Backrest

J. Chassis

K. Castor wheel

L. Drive wheel

M. Serial number label

Overview - 7

2.1 Wheelchair specification

Product name: F3 Corpus

Wheelchair class: B

Height, width, and length

Height: 960–1170 mm (38"–46")

Width: 650–790 mm (25.5"–31")

Length: 1120 mm (44")

Smallest transportation size

Height: 850 mm (33.5")

Width: 650–790 mm (25.5"–31")

Length: 920 mm (36")

Weight specification

Wheelchair with batteries: 172 kg (379 lb.)

Maximum user weight: 150 kg (330 lb.)

8- Overview

2.2 Tool bag

The wheelchair comes with a tool bag for

maintenance and adjustments. It contains the

following tools:

Spanner

General maintenance.

11 mm

13 mm

Allen keys

General maintenance and seat adjustment.

3 6 mm

Socket spanner

General maintenance.

15 mm

Valve adapter

Inflating the castor wheels

Overview - 9

2.3 General control panel

Joystick

Example of button functions

A. On/off

B. Horn

C. Decrease maximum speed

D. Increase maximum speed

For more information, see the user manual of

your control panel:

https://documentation.permobil.com/

manuals/control_panels/

10 - Overview
