Pentair MagicStream Deck Jet II User manual
MAGICSTREAM®
DECK JET II WATER FEATURE
WARNING — FOR YOUR SAFETY: This product must be installed and serviced by
a pool service professional. The procedures in this manual must be followed exactly.
Improper installation and/or operation will void the warranty. This document gives
instructions for installing the MagicStream®Deck Jet II water feature. Read through the
instructions completely before starting the procedure.
INSTALLATION INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Kit Contents (P/N 580003)
sDeck Jet Body — (Qty. 4)
sNozzle Kit (P/N 590041) — (Qty. 4)
sDeck Jet Cover (P/N 990042) — (Qty. 4)
Note: Each kit contains parts for four (4) MagicStream®
Deck Jet II units.
Rainbow Pool Products
PO Box 2388, Mansfield Qld 4122
Telephone STD 61-7-3849 5385
Facsimile STD 61-7-3849 5384
Email: [email protected]
Web: www.rainbowpoolproducts.com.au
MAGICSTREAM® Deck Jet II Water feature Installation Guide
Figure 1
Overview
The MagicStream®Deck Jet II water feature is designed to be installed in the deck or landscaping
surrounding the pool, spa, fountain, or pond. The swivel nozzle (Figure 1) produces a 5/16” stream
of water. The body is equipped with two, 3/16” drain holes to allow water to drain from the cup
surrounding the nozzle into the drain cavity at the base of the body (Figure 1). Be sure to keep the
drain holes clear of debris. To aid in draining, it is recommends placing a gravel layer beneath the
MagicStream®Deck Jet II water feature.
It is recommends that each'HFN-HW,,ZDWHUIHDWXUHEH¿WWHGZLWKDô´EDOOYDOYHWRDOORZÀRZ
control for each nozzle. For installations involving multiple nozzles, we recommend installing a
3-way valve on the main line near the pump for overall adjustment.
The MagicStream®'HFN-HW,,ZDWHUIHDWXUHLVGHVLJQHGIRUDPD[LPXPÀRZUDWHRI*30DWIW
of head (See table below).
Cup
Swivel nozzle
Drain holes
Drain cavity
cover (P/N 590042)
Swivel base
These 2 parts are
contained in the
nozzle kit (P/N 590041
Gravel layer
Water/Pressure Specifications
Gallons (US GPM) 3.0 4.0 5.0
Feet of head 3.9 7.9 11.0
Height of jet 3.0 6.6 10.0
MAGICSTREAM® Deck Jet II Water feature Installation Guide
3
Installation
The MagicStream®'HFN-HW,,ZDWHUIHDWXUHERG\LVGHVLJQHGWREHFRQQHFWHGWRD´6FK39&
pipe (Figure 2). After the pipe is pressure tested, solvent weld the body to the 3/4” supply pipe.
NOTE: Use PVC/ABS glue only. Anchor the MagicStream®Deck Jet II body, with the cover attached,
VRWKHFRYHULVOHYHOZLWKWKH¿QLVKHGGHFNVXUIDFH
2QFHWKHGHFNLV¿QLVKHGÀXVKDQ\GHEULVIURPWKHVXSSO\SLSHXVLQJWKHSXPSDQG¿OWHUV\VWHP
that supplies the MagicStream®Deck Jet II water feature. Apply threaded seal tape to the threads of
the swivel base. Remove any debris from the cup and screw the swivel base into the Deck Jet body
(Figure 2).
By hand, push the swivel nozzle until it snaps onto the swivel base (Figure 3).
Operation
Start the pump and adjust the appropriate valves as necessary to create the desired water effect.
,IWKHVWUHDPRIZDWHULVGLVUXSWHGUHPRYHWKH&RYHU-HWDQG-HW6ZLYHO%DVH&KHFNWRVHHLIWKHUH
is any debris blocking the jet.
Swivel nozzle
Swivel base
¾” Sch40 pipe slip
connection
Figure 2
¾” supply pipe
Figure 3
Solvent weld ¾” supply
pipe to ¾” Sch40 pipe
slip connection
Swivel base
Attach thread seal tape to the
swivel base and screw the
swivel base into the Deck Jet
By hand, push the swivel
nozzle on to the swivel base
until it snaps into place
