Peavey PXD Tragic II User manual

Model: PXD Tragic II

Available Finishes:

FEATURES

24 frets•

24.75” scale•

15 degree headstock pitch•

Set-neck with mahogany neck and rosewood fretboard with aluminum inlay•

Mahogany body•

Two EMG® active ceramic pickups•

Two Volume controls and one EMG Afterburner control with 3-way toggle switch•

Precision tuning machines•

String-thru-body bridge•

Black hardware•

SpeciallydesignedCofnCase®caseincluded•

Matte Black Blood Red White Gloss Black

A

C

D

B

RADIUS

NECK DIMENSIONS

Scale/Length: 24.75”, 24 frets

a. Width at Nut: 43mm (1.69”)

b. Width at Last Fret: 57.5 mm (2.25”)

c. Thickness at 1st Fret: 19.5mm (.760”)

d. Thickness at 12th Fret: 21.5mm (.840”)

Radius: 15”

SPECIFICATIONS

Neck Material: Mahogany

Neck Type: Set Neck, ultra slim, shallow oval

Hardware Color: Black

Body Wood: Mahogany

Fingerboard: Rosewood

Inlays: Aluminum “sharkstooth”

Frets: 24-frets, 18% nickel silver, .107 w” x .046”

Bridge: Fixed Tune matic style, heavy duty die-cast

Neck Pickup: EMG 60 Active*

Bridge Pickup: EMG 81 Active*

Special electronics: EMG Afterburner boost circuit*

*For full specs and information about the EMG pickups and Afterburner circuit refer to www.emginc.com

PICKUP SWITCHING

Th a n k y o u f o r p u r c h a s i n g g e n u i n e pe a v e y p r o d u c T s !

NECK

BRIDGE

SELECTOR POSITION

B NM B NM B NM

AFTERBURNER CONTROL

SET BOOST LEVEL (up to 20 dB) PULL POT TO ACTIVATE BOOST
