PARRY UGC8 Instruction sheet

Instruction Manual
Gas Chargrill
UGC8/UGC8P


Contents
Parry-British Built for Purpose
IN164-6
1
Contents ........................................................................................................................................... 1
Product Overview ............................................................................................................................ 2
Safety Instructions............................................................................................................................ 3
Installation Instructions ................................................................................................................ 4-5
Operating Instructions...................................................................................................................... 6
Cleaning Instructions ....................................................................................................................... 7
Maintenance Instructions................................................................................................................. 8
Fault Finding .................................................................................................................................... 9
Conversion Instructions .................................................................................................................. 10
Technical Data ........................................................................................................................... 11-12
Service Information ....................................................................................................................... 13
Exploded View................................................................................................................................ 14
Parts List ........................................................................................................................................ 15
Replacement Parts.......................................................................................................................... 16
Warranty Information..................................................................................................................... 17
Disposal & Recycling ...................................................................................................................... 18
Parry Catering Equipment (Midlands) Ltd, Town End Road, Draycott, Derby, DE72 3PT.
Sales Tel: 01332 875544 Fax: 01332 874455

Parry-British Built for Purpose
IN164-6
2
Product Overview
Designed for the demands of constant commercial use, the Parry UGC8/UGC8P gas chargrill
is the perfect choice for takeaways, restaurants and canteens. Packed with useful features,
the chargrill is incredibly heavy duty. The powerful burners have push button ignition and
are shielded to prevent blockages from food residue. The user-friendly thermostat provides
precise regulation of the temperature and the height of the grill plate is adjustable, ensuring
absolute control during the cooking process.
Unpacked weight (kg)
97
Packed Weight (kg)
117
Dimensions (w x d x h) mm
880 x 775 x 1060
Warranty
2 Year
KW –Natural
KW –Propane
26
25.7
BTU –Natural
BTU –Propane
90,000
87,692
Input Gas Connection
3/4” BSP Male
GAS INPUT PRESSURE –Natural
GAS INPUT PRESSURE –Propane
20 mbar
37 mbar
Can be converted using conversion kit?
Yes
These units lead the industry in:
Design and aesthetic appeal
Performance
Power
Functionality
After sales support

Parry-British Built for Purpose
IN164-6
3
Safety Instructions
PRODUCT INSTALLATION MUST BE CARRIED OUT BY A REGISTERED ENGINEER
The unit should be installed in compliance with the INSTALLATION INSTRUCTIONS and the
NATIONAL REGULATIONS in force at the time. Particular attention should be paid to the Gas
Safety (Installation and Use) Regulations and the Health and Safety at Work Act.
All commercial gas catering equipment is recommended to be mounted below an extraction
canopy. Please consult a ventilation engineer or refer to Guidelines DW172 to calculate the
ventilation requirements for cooking areas containing different pieces of gas catering
equipment.
Each appliance requires a flow of fresh air for combustion. Under no circumstances should
air vents on the appliances, or air vents installed by the fitter in the room of the appliance to
supply combustion air, be altered or omitted in any way.
Attention should be drawn to the fact that parts of this unit by necessity, will get VERY HOT,
and will cause burns if touched accidentally. Therefore, it is the responsibility of the
supervisor or equivalent to provide SUITABLE PROTECTIVE CLOTHING for the user.
To prevent shocks, all appliances whether gas or electric, must be earthed.
To avoid scratching the highly polished exterior surface of this equipment whilst in transit,
the protective film on the exterior surfaces has NOT been removed. It is IMPORTANT that
this protective film is peeled off before the equipment is used.

Parry-British Built for Purpose
IN164-6
4
Installation Instructions
Before installation check data plate on rear of unit to ensure appliance is suitable for gas
supply available.
During installation the provision of combustion air to the appliance through base and rear of
appliance must be made. This should not be blocked at any time.
This appliance should be installed with adequate ventilation to prevent the occurrence of
unacceptable concentrations of substances harmful to health in the room in which it is
installed.
POSITIONING
The appliance must not be installed on or against combustible surfaces –minimum
clearances must be:
Rear 150mm (6”)
Sides 150mm (6”)
Hotplate to combustible material 1525mm (60”)
All local fire regulations should be observed.
It is recommended that the appliance be sited below a ventilating hood preferably of the
extractor type incorporating a grease filter.
Appliances are designed to be installed and fitted on a Parry stand for stability. If they are
fitted on any other surface they should be suitably secured.
GAS CONNECTION
The size of the supply pipe should be no less than ¾” B.S.P. and an easily accessible isolation
tap fitted close to the appliance in the gas line. Although a rigid connection is
recommended. An approved armoured flexible pipe may be used in conjunction with a
straining cable.
Before the appliance is commissioned the gas safety regulations require that all connections
on the gas line are tested for gas soundness between the gas meter and the appliance.
All packing and protective film must be removed from panels etc. prior to commissioning
the appliance.

Parry-British Built for Purpose
IN164-6
5
Installation Instructions
Gas hoses used to connect the appliance to the gas supply must be of the correct
specification for the gas and pressure of the appliance. The gas hose must comply with the
national requirements in force, and be CE marked, of a metal braided construction suitable
for commercial catering equipment. The hoses should be periodically examined and
replaced as necessary
The tube or hose shall be fitted such that there are no sharp bends or torsional strain which
may cause damage or failure of the tube or hose, especially near the end fittings. Torsional
strain can be prevented by using internal unions, swivel joints, etc. The bend radius should
not exceed that stated by the Manufacturer. The hose should not touch the ground and
should be no longer than 1.5m long.
A manual valve should be positioned upstream of the tube or hose unless the connection
fitting incorporates a self-sealing quick release coupling.
Where a quick release coupling is used for horizontal travel such as in commercial catering
appliances it is advisable that the coupling is facing downwards to prevent the ingress of
debris and ensure the hose is formed in to a smooth curve.
All units should have a restraining cable fitted preventing the unit from being pulled away
from the wall and causing the gas hose to become disconnected accidentally.

Parry-British Built for Purpose
IN164-6
6
Operating Instructions
This unit is not intended for use with lava rock
To light burner:
Turn knob to * position
Push knob in and ignite gas by pressing ignition button to the left of the control
knob. Keep the control knob pressed in for 15-20 seconds. Check gas is lit by looking
through the cooking grid at the pilot.
Release knob, gas should stay lit, if gas goes out repeat step 2.
Turn knob anti clockwise to obtain main gas. When turned to (high) the burners
are at their maximum output. Turning to (low) the burners are at their lowest
setting, which has been set at the factory and must not be adjusted by users.
To turn burner off turn knob in a clockwise direction all the way round to* which will
leave the pilot on.
To turn the pilot off turn the knob clockwise to the •off position
It is recommended that the char grill be run on full gas after ignition for 10 minutes, then
adjusted as necessary to obtain correct cooking temperatures
All burners are fitted with flame failure devices for safety and spark ignition for ease of
lighting.
We advise these appliances should not be left unattended while switched on.
These appliances are for professional use by qualified people only.
There are no user serviceable parts
Three drip trays are located beneath the burners to catch any spillage; a separate tray is
positioned at the front of the cooking grid. Both trays are removable for cleaning, but care
should be taken as during normal use the trays may get hot. Only remove when tray has
cooled or with suitable gloves.

Parry-British Built for Purpose
IN164-6
7
Cleaning Instructions
The appliance should be cleaned after every use.
Allow unit to cool down before cleaning
Wipe down the machine with a soft cloth, do not use abrasive materials.
Stainless steel cleaners maybe used and cleaning instructions on the product must be
adhered to.
Never clean the unit with water jets.
The cooking grids can be removed for cleaning.
The top drip tray which drains into the drip trays below can be lifted off for cleaning.
The main drip trays are divided into three trays to make removal and cleaning easier.
The burner shields lift off and burners can be cleaned in situ with a wire brush. The
burners should only be removed by an engineer.
Carefully clean the thermocouple probe, the ignitor electrode and pilot jet

Parry-British Built for Purpose
IN164-6
8
Maintenance Instructions
Ensure the appliance is isolated from the power supply before installing, cleaning or
maintaining the appliance.
Maintenance and service must only be undertaken by a qualified electrician.
Parry Catering provides a complete after-sales service by offering the sales of spare parts
directly to customers. Buying spares straight from the manufacturer allows customer to
experience exceptional value and speedy delivery on all spare parts.
For more information on buying spares visit:
www.parry.co.uk/parry-commercial-catering-spares
