Parker F11 series User manual

7 ParkerHannin

PumpandMotorDivision

Trollhättan,Sweden

ServiceManual

Series F11

BulletinHY30-5503-M1/UK

Assembling

1.Placetheringgearontheshaft

withtheguidepinlocatedagainstthe

guidehole.

2.Pressdownthebigtaperedroller

bearingtogetherwiththeringgear.

3.Placethedistanceringonthebig

taperedrollerbearing.

4.Placethesmalltaperedrollerbear-

ingontheshaftasonthepicture.

5.Pressdownthesmalltaperedroller

bearinginsmallstepsuntilcorrect

preloadisachived.Nottotightandno

backlash.

6.Placethelockwasher(s)ontothe

shaft.

8ParkerHannin

PumpandMotorDivision

Trollhättan,Sweden

ServiceManual

Series F11

BulletinHY30-5503-M1/UK

Assembling

7.Assembletheroundnutandtighten

ituntiloneopeningisincorrectposi-

tionforthelockwasher.

10.Assemblethecylinderbarrel.

Instructions on page 11.

8.Securetheroundnutasshownin

thepicture.

11.AssembletheO-ringsonthedis-

tancering.

9.Assemblethevalveplate.Make

suretheslotisincorrectpositionand

thevalveplateislocatedasshownin

picture.

12.Carefullytapdownthedistance

ringtothebarrelhousing.Lubricate

themwithoilbeforeassembly.

9 ParkerHannin

PumpandMotorDivision

Trollhättan,Sweden

ServiceManual

Series F11

BulletinHY30-5503-M1/UK

Assembling

13.Assembletheshims.

14.Assemblethepistons.Lubricate

theballsocketsbeforeassembly.

15.Assembletheshaftpackagewith

pistonsintothecylinderbarrel.

16.Makesurethetimingiscorrect.

17.Carefullytapdownthebearing

housing.

18.Lubricatethesealingsurfaceon

theshaftbeforeassemblingtheshaft

seal.
