Panasonic MC-9040 User manual

10/19/2016 s0000000000.html

file:///C:/Users/sh.dehghani/Desktop/MC9040OTSVC_VCD00070001C3/viewing/SGML_VIEW_DATA/OT/MC9040/SVC/s0000000000.html#cover 1/1

ServiceManual

TOPNEXT

ORDERNO.VCD00070001C3

VacuumCleaner

MC9040

©1995MatsushitaElectricIndustrialCo.,Ltd.Allrightsreserved.Unauthorizedcopyinganddistributionisa

violationoflaw.

@

TOPNEXT

10/19/2016 mc_9040.html

file:///C:/Users/sh.dehghani/Desktop/MC9040OTSVC_VCD00070001C3/viewing/SGML_VIEW_DATA/OT/MC9040/SVC/index.html 1/1

1PICTORICALDIAGRAM

TOPPREVIOUSNEXT

*AC220V50/60Hz,240V50Hz

Thecolouroftheleadwirein()isforAC220V(withC3purg).

TheproductsofAC240Vonlyhaveafuse(15A)intheupperbody.

AsforAC220Vproduct,thefuse(13A)isinstalledinC3plug.

@

TOPPREVIOUSNEXT

10/19/2016 mc_9040.html

file:///C:/Users/sh.dehghani/Desktop/MC9040OTSVC_VCD00070001C3/viewing/SGML_VIEW_DATA/OT/MC9040/SVC/index.html 1/1

2SHEMATICDIAGRAM

TOPPREVIOUSNEXT

*AC220V50/60Hz,240V50Hz

TheproductsofAC240Vonlyhaveafuse(15A)intheupperbody.

AsforAC220Vproduct,thefuse(13A)isinstalledinC3plug.

@

TOPPREVIOUSNEXT

10/19/2016 mc_9040.html

file:///C:/Users/sh.dehghani/Desktop/MC9040OTSVC_VCD00070001C3/viewing/SGML_VIEW_DATA/OT/MC9040/SVC/index.html 1/1

3.1LOWERBODY

TOPPREVIOUSNEXT

Removing

1.Insertascrewdrive()intothereversesideoftheFrameandpushouttheClawattheframefortaking

outtheLowerBody(Fig.1).

Assemble

1.AttachtheLowerBodytotheFrameandpushinslowlytoattachit.Alignthe´▴´markonFrame&Lower

Body.

Fig.1

@

TOPPREVIOUSNEXT

10/19/2016 mc_9040.html

file:///C:/Users/sh.dehghani/Desktop/MC9040OTSVC_VCD00070001C3/viewing/SGML_VIEW_DATA/OT/MC9040/SVC/index.html 1/1

3.2MAINSWITCHUNIT

TOPPREVIOUSNEXT

1.RemovetheHandlefromtheBodyCoverandcutofftheleadwire(Black/Brown)connectingattheFuse

Assembly,attheendofpowercord.

Reconnecttopowercordbyclosedendconnector.

2.Connectanewswitchunit(spottedwithleadwires)totheFuseleadwireusingaclosedendconnector.

Fig.2

@

TOPPREVIOUSNEXT

10/19/2016 mc_9040.html

file:///C:/Users/sh.dehghani/Desktop/MC9040OTSVC_VCD00070001C3/viewing/SGML_VIEW_DATA/OT/MC9040/SVC/index.html 1/1

3.3THERMOPROTECTORUNIT

TOPPREVIOUSNEXT

1.CuttheleadwirebluetoreplacetheThermoProtectorUnit.(Fig.3)Connectbyclosedendconnector.

Fig.3

@

TOPPREVIOUSNEXT

10/19/2016 mc_9040.html

file:///C:/Users/sh.dehghani/Desktop/MC9040OTSVC_VCD00070001C3/viewing/SGML_VIEW_DATA/OT/MC9040/SVC/index.html 1/1

3.4FUSEASSEMBLY

TOPPREVIOUSNEXT

1.IfFuseofthemainswitchisdamaged,cutofftheleadwire,whichconnecttheFusetothecordwire

(Black/Brown)andleadwireconnectedattheMainSwitch.

ReplacetheFuseandconnecttotheCordwireandMainSwitchusingaclosedendconnector.(Fig.4)

Fig.4

@

TOPPREVIOUSNEXT

10/19/2016 mc_9040.html

file:///C:/Users/sh.dehghani/Desktop/MC9040OTSVC_VCD00070001C3/viewing/SGML_VIEW_DATA/OT/MC9040/SVC/index.html 1/1

3.5BLOWEROUTLETUNIT

TOPPREVIOUSNEXT

1.RemovetheBlowerOutletUnitbypullingthespringwhichislocatedattheBodycover,lockingthe

BlowerOutletAssemblyupwards.(Fig.5)

Fig.5

@

TOPPREVIOUSNEXT

10/19/2016 mc_9040.html

file:///C:/Users/sh.dehghani/Desktop/MC9040OTSVC_VCD00070001C3/viewing/SGML_VIEW_DATA/OT/MC9040/SVC/index.html 1/1

3.6POWERCORD

TOPPREVIOUSNEXT

Removing

1.Cutofftheleadwire(Black/Brown)andleadwire(White/Blown)toreplacethePowerCord.(Fig.6)

Fig.6

Assemble

1.Pullthewiretothemotorsupportercenter(Fig.7)andthewireaccordinglyintoBodyCoverstrainrelief.

(Fig.8)

Fig.7

Fig.8

@

TOPPREVIOUSNEXT

10/19/2016 mc_9040.html

file:///C:/Users/sh.dehghani/Desktop/MC9040OTSVC_VCD00070001C3/viewing/SGML_VIEW_DATA/OT/MC9040/SVC/index.html 1/1

3.7FILTERUNIT

TOPPREVIOUSNEXT

1.RemovetheClothBagfromtheExpander.(Fig.9)

Fig.9

@

TOPPREVIOUSNEXT
