Service Manual

TOP NEXT

ORDERNO.MKE0206604C1

B22

TV/DVD/VCR Combination

lPV-DF2002

TOP NEXT

http://servis-manual.com/

5.1.1SIMPLIFIEDFAULT FINDINGDATA

TOP PREVIOUS NEXT

SimplifiedSelf-DiagnosticSystemfacilitatesfindingthecauseofthefault.A4 digit fault codeand

communication forI2Cbuscodewill bedisplayedon TVscreen.

TheSimplified Fault findingdataisstored intheMemoryIC(IC6004).Thisdataisclearedafterit is

displayed, and thenthePOWERbutton ispressed backon.

1.Withpowerturnedoff,pressFF and REWbuttonson unit togetherforover3 seconds.

Fig. 1-1

2.TVpowercomeson and theunit goesintoservicemode.

4digit forfault codeand communicationforI2Cbuscodewill bedisplayed.

Fig. 1-2

Fig. 1-3

9.9.2004file://C:\Documents%20and%20Settings\Admin\Plocha\SCHÉMATA\VIDEA\PANAS...

http://servis-manual.com/

Fig. 1-4

Fig. 1-5

9.9.2004file://C:\Documents%20and%20Settings\Admin\Plocha\SCHÉMATA\VIDEA\PANAS...

http://servis-manual.com/

3.Pressany operation button exceptforPOWERorPLAY (DVD)on eithertheunit,orthe

remoteto detectthatakeyhasbeen pressed. The1stdigit changesto"0"onlywhen keyis

detected.

Fig. 1-6

Note:

When 1 to 4 listedin Lockcodeoccurs,theVCR stopsand all VCR function buttonsexceptfor

powerbecomenon-operational.

TOP PREVIOUS NEXT

9.9.2004file://C:\Documents%20and%20Settings\Admin\Plocha\SCHÉMATA\VIDEA\PANAS...

http://servis-manual.com/

5.1.2SELF-DIAGNOSTIC TESTFUNCTION

FORDVD

TOP PREVIOUS NEXT

Thisunit hasaSelf-Diagnosticfunction whichdetectsaproblemormalfunction withintheunit and

displaysitscorrespondingErrorcodeon TVScreen.

Note:

If,afterapprox.30 seconds,aunit setto DVD modeautomatically switchestoVCR mode,thereis

likelyaproblemwiththeDVD DecoderC.B.A.(IC8000, IC8100, IC8200, etc.)

5.1.2.1HowtoenterDVD Self-Diagnostic mode

1.InsertaDVD discintotheDVD Unit.

2.SettheunittoDVDmode.Then,pressSTOPbutton tostop playback.

Note:

Do notletaDVD play during DVDSelf-Diagnosticmode.

3.Pressand holdSTOP/EJECT,PLAY/REPEAT,and VOL-buttonsofVCR operation panelof

theunit togetherforover5secondswithno cassetteinserted.Theadjustmentoverlaywill

appearon theTVscreen.

Fig. 2-1

4.PressDISPLAY keyon theremotecontrolto enterDVD Self-Diagnosticmode.

Fig. 2-2

5.Press”1”keyon theremotecontrol.TheDVD Self-DiagnosticTestfunction will start

automatically.

Fig. 2-3

9.9.2004file://C:\Documents%20and%20Settings\Admin\Plocha\SCHÉMATA\VIDEA\PANAS...

http://servis-manual.com/

6.Afterafewminutes(approx. 1~5minutes),thecheckresultswill appearon TVscreen.

¡Ifno errorisdetected,"COMPLETED"will appearasshowninFig. 2-4.Besureto

pressPowerOFF toend.Then,press PowerON againand removeaDVD fromthe

DVD Unit.

Fig. 2-4

¡Ifsomeerrorisdetected, 2digit forErrorCodewill appearasshowninFig. 2-5.

Fig. 2-5

Fig. 2-6

TOP PREVIOUS NEXT

9.9.2004file://C:\Documents%20and%20Settings\Admin\Plocha\SCHÉMATA\VIDEA\PANAS...

http://servis-manual.com/

5.1.3HOW TO UPDATE THE FIRMWARE

OFDVD

TOP PREVIOUS NEXT

Itispossibleto updatethefirmwareversion oftheDVD Driveand theDVD Decoderusingeach

FirmwareDiscforDVDDriveand DVDDecoder.

5.1.3.1HowtoupdatethefirmwareofDVD

1.Confirmthefirmwareversion ofDVD Drive. Referto" SELF-DIAGNOSTICTEST

FUNCTION FORDVD ."

2.SettheunittoDVDmode.

3.PressOPEN/CLOSEbutton toopenthetray.Then,placetheFirmwareDiscforDVD Drivein

thetray.

4.Closethetray. Updatingwill beginautomatically.

5.Afterapprox. 1minute,thetraywillopenautomatically.

Note:

Ifthetrayhasstillnotopenedafter3 minutesorErrorIndication appears,updatingwas

unsuccessful.Inthiscase,repeatabovestepsfromstep1.

6.RemovetheFirmwareDiscfromthetray. Then, disconnecttheACPlug. (Thetraywill not

close.)

7.ConnecttheACPlugand turnon thepower.Then, resetall VCR memory.Referto" HOW

TORESETALLCOMBINATION DVD VCR MEMORYFUNCTIONS ."

5.1.3.2HowtoupdatethefirmwareofDVD Decoder:

1.ConfirmthefirmwareversionofDVD Decoder.Referto" SELF-DIAGNOSTICTEST

FUNCTION FORDVD ."

2.SettheunittoDVDmode.

3.PressOPEN/CLOSEbutton toopenthetray.Then,placetheFirmwareDiscforDVD Decoder

inthetray.

4.Closethetray. Updatingwill beginautomatically.

5.Afterapprox. 1minute,thetraywillopenautomatically.

Note:

Ifthetrayhasstillnotopenedafter3 minutesorErrorIndication appears,updatingwas

9.9.2004file://C:\Documents%20and%20Settings\Admin\Plocha\SCHÉMATA\VIDEA\PANAS...

http://servis-manual.com/

unsuccessful.Inthiscase,repeatabovestepsfromstep1.

6.RemovetheFirmwareDiscfromthetray. Then, disconnecttheACPlug. (Thetraywill not

close.)

7.ConnecttheACPlugand turnon thepower.Then, resetall VCR memory.Referto" HOW

TORESETALLCOMBINATION DVD VCR MEMORYFUNCTIONS ."

CAUTION:

1. DonotunplugtheACCord duringupdating.

2. Donotpressany buttonsduringupdating.

TOP PREVIOUS NEXT

9.9.2004file://C:\Documents%20and%20Settings\Admin\Plocha\SCHÉMATA\VIDEA\PANAS...

http://servis-manual.com/

5.1.4USAGESCREENMODE

TOP PREVIOUS NEXT

Function displayed on theTVmonitor:

lthetotalelapsed"Poweron"time(in days)

lthetotalelapsed"Cylinderrotation"time(inhours)

lthetotalelapsed"DVD play"time(inhours).

1.With powerturnedand no cassette,pressSTOP/EJECTbutton on VCRand 7 keyon remote

together.

TheUSAGESCREENwill bedisplayedon theTVMonitor.

Fig. 3

Note:

1.AfterreplacingtheCylinderUnit,pressCOUNTERRESETbutton on remoteinthismode.

OnlyTotalelapsed"Cylinderrotation"time(indays)will becleared to0.

2.AfterreplacingtheDVD Unit,pressADD/DLTbutton on remoteinthismode.OnlyTotal

elapsedtime"DVD Play"time(inhours)will becleared to0.

3.ToreleasefromUsageScreenMode,pressany operation button on VCR orinsertacassette

tapeinthismode.VCR will returntonormaloperation mode.

TOP PREVIOUS NEXT

9.9.2004file://C:\Documents%20and%20Settings\Admin\Plocha\SCHÉMATA\VIDEA\PANAS...

http://servis-manual.com/

5.1.10 SERVICEMODE

TOP PREVIOUS NEXT

Inordertoinhibit detection oftheSupply&Takeup PhotoTransistors,ReelSensor,and Cylinder

Lock, pressand holdSTOP/EJECT, PLAY/REPEAT,and CHdown buttonsofVCRoperation panel

on theunittogetherover5secondsinpoweron condition.

Fig. 7

Theunit goesintoservicemode.

Inthismode,Mechanismmovementcanbeconfirmed. WhenremovingCassetteUpAss’y,itcanbe

confirmedwithoutacassette.

Toreleasefromthismode,pressPOWERbutton offordisconnectACPlug.
