Panasonic KX-TDA50G User manual
Small Business
Telephone System
Enhanced Communication Solutions
KX-TDA50G
The Panasonic KX-TDA50G
The Intelligent, Versatile and Affordable
Communications Solution for Small Businesses
As a small business, you thrive by providing hands-on, personalized service to your clients. You simply
can’t afford to be out of touch, either with customers or colleagues. While the elaborate communications
infrastructure of a larger enterprise may be beyond your means, Panasonic has an intelligent, versatile and
affordable way to bring anytime,anywhere communication to your business: the TDA50G Business
Phone System.
The TDA50G is another example of how Panasonic is big on small business. We offer small to mid-size
businesses like yours completely customizable and scalable communications solutions that are reliable,
affordable and flexible, allowing you to be more responsive to your customers, to stay better connected
to remote and mobile colleagues, and to quickly and effectively adapt to changes and challenges in the
marketplace. After all, when it’s your business, there’s nothing small about it.
Panasonic Enhanced Communications Solutions
What is the TDA50G?
The TDA50G is a conventional phone system suitable
for small businesses. The system can be configured to
support up to 48 extensions maximum and has built-in
caller ID capability.
Who is the TDA50G for?
This system is ideal for Law Firms, Real Estate Companies,
Hotels, Motels, Medical Offices and other small businesses
who are looking for an affordable and flexible phone system
that will grow as they grow. It provides reliable voice and data
communications, voice mail, wireless capability to stay
connected to remote and mobile colleagues, and the ability to
save money on communication charges with SIP Trunking*.
* SIP Trunking service offered by telephone service providers.
Consult Panasonic or your local dealer for compatibility.
Will the TDA50G grow along with my business?
The TDA50G features a modular design and so it will expand to accommodate a growing business—if you have
multiple locations, or if you open new offices as you grow.
What about our employees who work remotely or travel a great deal?
The TDA50G features state-of-the-art wireless technology, so it’s easy to stay connected to colleagues who are
constantly on the go. Incoming calls to an employee’s desk phone will automatically ring on their cell phone, while
voice mail messages will automatically be sent to their email inbox as an audio file.*
*Requires KX-TVA voice mail
Does Panasonic have applications to support my unique business needs?
Panasonic has a suite of industry-specific applications available for retail, hospitality, call center and many other
industries that are tested and available today.
What other capabilities does the TDA50G have?
The TDA system supports centralized voice mail, which services all locations within the extended voice mail
network. The TDA system also allows you to view the status of extensions in other locations.*
* Viewing extension status requires optional network DSS. Both features require optional enhanced SD card.
If my company transitions to IP-based telephony, will I have to replace the TDA50G?
The Panasonic TDA50G can accommodate conventional analog and proprietary analog/digital Panasonic phones,
as well as newer Panasonic IP phones. It also allows you to adopt new technologies like SIP trunking, without
replacing the system in favor of new hardware.
For more information visit Panasonic.com/ECS
How flexible is the TDA50G and can it be customized for my business?
The TDA50G is a reliable, affordable communication solution that will allow you to use conventional analog
and proprietary analog/digital Panasonic phones, or evolve toward newer technologies like IP handsets and
SIP trunking. It also provides state-of-the-art in-building wireless and the ability to seamlessly integrate cell
phone extensions into the system. It can even be networked with another unit at a branch office.
Cordless
Digital
Centralized Voice Mail
Cellular*
IP
Analog
TDA50G
Branch Office
Service
Provider
Network
SIP Trunking
* Requires enhanced SD card
For more information visit Panasonic.com/ECS
Phones for Every Need
The TDA50G gives businesses a choice of the solutions that best suit their unique needs. The system supports
analog and digital telephones, DECT wireless phones, and up to 4 IP phones.
TDA50G - Integrated Messaging Solutions
Integrated messaging solutions automate your message delivery so your customers can get the responsive,
professional support they deserve. The system records messages automatically, keeping you in touch twenty-
four hours a day. And of course, you’ll love the cost savings. Panasonic messaging combines convenience with
cost savings all while producing a more satisfied customer.
Email Integration and
Voice Mail with Auto Attendant
Add a KX-TVA series voice processing system and easily manage calls using the
built-in automated attendant service, voice mail with email integration, and more.
With the high level of integration between the TVA and the TDA50G, you can enjoy
features like voice mail LCD menus that allow you to access and manage your
voice mailbox using the LCD display and soft keys. With so many choices, it’s
easy to custom design a system that’s right for you.
IP Softphone
• Allows a PC to Operate as a system telephone
• 24 Programmable CO keys with Dual Color Indicators
• 6-Line Alphanumeric Display with Interactive Soft Keys
• Easy-to-Use Keyboard or Mouse Operation
• Message Waiting Indicator for Voice Mail
• Network Connection Indicator
SYSTEM SPECIFICATIONS
Accessory Capacities
Maximum Number of Cell Stations
Maximum Number of Wireless Telephone Handsets
Maximum Number of Doorphone / Door Openers
ESVM Maximum Voice Message (Outgoing Message) Channels
Maximum Voice Processing Sytems
BGM (Background Music)5/ MOH (Music On Hold) Inputs
External Paging Outputs
RS232C/SMDR Outputs
USB Connection
Optional Ethernet (10 BaseT)6Connection for CTI / Programming
4(8)4
28
4/4
2
1-VPS Unit
1
1
1
1
1
PANASONIC KX-TDA50G HYBRID IP-PBX
Initial Configuration Included Power Supply Unit
CO Line
Extensions
Analog CO Line
Digital Hybrid Port1
4 (with Caller ID)
4
Maximum Capacity Included Power Supply Unit with Additional Power Supply Unit
CO Line
Analog CO Line 12 12
12 12
Voice Over IP (H.323)
44
Extensions
Analog Phones (Single Line Device) 24 24
KX-T7600 Series2Phones (Digital Proprietary)
Other Digital Phones
4 24
4 24
DSS Console 4 4
KX-T7700 Series Phones (Analog Proprietary)
IP Proprietary Phones / Softphones
4 4
Voice Over IP (SIP)* 8 8
KX-DT300 Series ( Digital Proprietary) 24 (483) 24 (483)
24 (483)24 (483)
* Expandable to 8 lines with expansion card.
1 Just plug in either Analog phone (single line device), Analog Proprietary phone or Digital Proprietary phone.
Can support up to two KX-series phones plus one Analog phone on each port.
2 Latest series.
3 48 extensions using Digital XDP.
4 With additional power supply.
5 BGM, External paging, RS232C/SMDR, and USB are standard and included with the basic system.
6 Optional feature. To enable CTI and programming for remote maintenance tool over IP,
the KX-TDA5480 4 channel VoIP Gateway Card (IP-GW4) is required.
28 56
Design and specifications subject to change without notice. BTS090077BRO
Panasonic Communication Company
of North America
Executive Offices:
Three Panasonic Way, Secaucus, NJ 07094
(201) 348-7000
www.panasonic.com/ecs
Panasonic Customer Service
9 am - 9 pm (EST) Mon. through Fri.
10 am - 7 pm (EST) Sat. and Sun.
1-800-211-PANA
www.panasonic.com/support
For hearing or speech impaired TTY users, TTY 1-877-833-8855
