Panasonic SV-MP120VE User manual

TD0503015C2

Digital AudioPlayer

SV-MP120VE

Colour

(K)....................Black Type

SPECIFICATIONS

Specifications

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Memorysize: 512 MB

Supportedsampling frequency:

MP3; 32 kHz, 44.1kHz, 48 kHz,

WMA; 8kHz to44.1kHz

Supportedbit-rates: MP38kbpsto320 kbps(128

kbpsisrecommend) WMA32

kbpsto192 kbps(96 kbpsis

recommend)

No. of channels: Stereo, 2channels(MUSIC, FM

RADIO) Mono, 1channel (IC

RECORDER)

Frequencyresponse: 20Hz to20,000Hz (+0dB, -6dB)

(MUSIC), 300 Hz to4,300 Hz (IC

RECORDER,HQ mode)

MicS/N: 30 dB (IC RECORDER,HQ mode)

RadioFrequencyrange(FM): 87.9MHz to107.9MHz (200kHz

steps),87.5MHz to108.0MHz

(50/100 kHz steps),

Output: 4.5mW+ 4.5mW(16 ,M3

jack)

Power supply: DC 1.5V (onealkaline

LR03,AAA battery)

Approximateplaytimes: 13 hours (MUSIC),

7hours (FM RADIO)

Approximaterecording times: 13 hours (IC RECORDER, HQ

mode)

7hours (FM RADIO)

Maximumdimensions(WxHxD): 53.2x61.1x17.5mm

Mass: 41.7gwithbattery/ 30.4g

without battery

-Specificationsaresubject to changewithoutnotice.

-Theplaytimes shown depend on operating conditions.

-Mass and dimensionsareapproximate.

-MB meansonemillion bytes. Useablecapacitymaybeless.

-Thisproduct iscompatiblewith thefollowing character code. The

displaymaynotappear correctlywith other character codes.

2005 Matsushita ElectricTAIWAN Industrial Co., Ltd. All rights

reserved. Unauthorized copying and distribution isaviolation of

law.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1. Accessories

-Stereo earphones

(L0BAB0000193) ............................................................. 1pc.

-USBCable

(K1HA05AD0004)............. ................................................ 1pc.

-Neck Strap

(VFC4028) .....................................................................1pc.

-CD-ROMDriver

(RFET0002) .................................................................... 1pc.

2. Location of Controls

3. Operation Checks and Component Replacement /

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Procedures

1. Thissection describes procedures for checking the operation of

the major printed circuitboards and replacing the main

components. /

2. For reassemblyafter operation checks or replacement, reverse

the respective procedures special ressemblyprocedures are

described onlywhen required.

3. Select item from the following index when checks or replacement

are required.

Contents

1. Checking for the mainP.C.B.

2. Checking for the memoryP.C.B.

3. Checking for the LCD ass’y.

4. Checking for the prevent electrostaticdischarge.

3.1. Removal of the batterycover

3.2. Removal of the front cabinet

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

3.3. Removal of the SUB P.C.B.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

3.4. Removal of the jack holder

3.5. Removal of the MainP.C.B.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

3.6. Removal of the LCD Ass’y

3.7. Removal of the LCD holder

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

3.8. Removal of the USBcover

3.9. Removal of the holder knob

3.10. Removal of the RECbutton and playbutton and volume button

and mode button

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

4. Instructions for Repair Service

5. Service Position

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

6. Service Mode

6.1. Checking Procedures for IC3C2HBZG000008

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
