Panasonic TY-WK22LT1U User manual

Wide-screen LCD Television (22LT SERIES)

Wall Mount Kit

Installation Manual

Model No. TY-WK22LT1U

●Please read this instruction manual carefully for the correct usage. After reading,

retain it in a convenient location for future reference.

●To achieve the best possible performance and to maintain safety, always request a

certified professional for the installation of the wall mounting bracket.

●Retain all removed parts. They may become necessary when returning to the original

installation condition.

●

Caution: This bracket intended for use only with Panasonic LCD TV Model TC-22LT1/TX-

22LT2 series. Use with other apparatus may result in instability causing possible injury.

TQZH376

Wall mounting bracket A (Main unit side)

Wall mounting bracket dimensional drawings

Wall mounting bracket B (Wall side)

Metal plate (main unit side)

[Unit: mm]

Printed in Japan MBS0202-0(MS)

■Be aware of safety factors

concerning the mounting

strength

Insufficient strength may

cause the wide-screen

LCD television to fall, re-

sulting in bodily injury.

■Do not hang anything from the

wide-screen LCD television,

place a stepladder against it,

etc.

The wide-screen LCD tele-

vision may become dam-

aged or it may fall, causing

bodily injury.

Installation

Prohibited

WARNING

■Do not install in humid or

dusty areas, or where the

wide-screen LCD television

may be exposed to lampblack,

steam or heat.

Fire or electrical shock may

occur as a result.

■Make sure there is sufficient

air circulation so that the am-

bient temperature does not

exceed 35°C.

Heatmaybuildupwithinthe

wide-screen LCD televi-

sion,causing fire asa result.

Installation

Prohibited

CAUTION

This symbol indicates that the item must be followed with caution.

Safety precautions Be sure to follow

To prevent injury to the user and others and to prevent damage to property, items that must

be followed are explained as shown below.

■The following displays categorize the degree of danger when mishandled.

WARNING

■Items that must be followed are explained using the following symbols.

This symbol indicates that the item must always be followed.

This symbol indicates that the item is prohibited.

Possibility of serious injury and even death when

mishandled.

CAUTION Possibility of injury or damage to surrounding

property.

■Installation to be performed by

certified personnel only.

Inadequate installation

may cause the wide-screen

LCD television to fall, re-

sulting in bodily injury.

■Do not install where tolerance

is weak.

If the tolerance of the

mounting location is weak,

the wide-screen LCD tele-

vision may fall resulting in

bodily injury.

Installation

Prohibited Prohibited

WARNING

Cautions concerning installation work

To achieve the best possible performance and to maintain safety, always

request a certified professional for the installation of the wall mounting

bracket.

The stand of the wide-screen LCD television must be removed.

Before performing work, always turn off the power and disconnect the power

plug of the AC adapter from the wall outlet.

Allow sufficient strength for safety.

The weight of the wide-screen LCD television is approximately 9.5 kg.

When mounting on a wall, perform work so that it can withstand the weight of

the television and so that the bracket will not come loose from vibration, etc.

Reinforce the bracket if the mounting section strength is insufficient.

The television may fall if the installation is insufficient or if the screws are loose.

●Wall surface strength

Wall surface material

Plywood................... Thickness of at least 20 mm is required.

Concrete.................. Thickness of at least 55 mm is required.

* Use reinforcing plate or bar if the wall surface material is < board, plaster-

board, particle board, > concrete, etc., or if there is not enough mounting

strength due to aging, etc.

Use the supplied cable clampers to fix cables. Never fix cables using staples.

■Do not install with the wide-

screen LCD television facing

downward, on its side, or up-

side down.

Heatmay build up withinthe

wide-screen LCD televi-

sion,causing fire asa result.

■Maintain space of at least 5 cm

on top and to the sides of the

wide-screen LCD television

and at least 4 cm in the rear.

Vent holes are located on

the rear of the wide-screen

LCD television. Blocking

these holes may result in

fire.

■Always remove the wall

mounting bracket when re-

moving the wide-screen LCD

television.

Injury may result when ac-

cidentally hitting the pro-

jected parts.

Take caution when removing for re-

pairs, etc.

■The wide-screen LCD televi-

sion is heavy. Always work in

pairs.

The television may fall,

causing bodily injury.

Installation

Prohibited

CAUTION

Wall mounting bracketA

(main unit side)

(1)

Wall mounting bracket B

(wall side)

(1)

Cable clamper

(3)

Clamper

(3)

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Metal plate (main unit)

(1)

Bracket mounting screwA

(main unit side) (6)

Angle fixing screw (for main

unit side/wall side fixing) (2)

M4x10 mm (Total: 8)

Bracket mounting screw B

(for plywood)

ø4x25 mm (4)

Fall prevention string

(2)

Accessories

Check for the following accessories before installing and connecting the wide-screen LCD

television to the wall mounting bracket. ( ) indicates quantity.

Cautions concerning installation location

■Avoid places with vibration and mount on a vertical surface with no vibration or

shock.

■Do not imbed the wide-screen LCD television, cover or block the vent holes.

For the usage environment, the ambient temperature must be in the range of

5°C – 35°C, and humidity must be in the range of 5% – 90%.

■Keep the wide-screen LCD television away from magnets, heat, steam,

lampblack, etc.

■Install in a location where the main unit power switch can be easily accessed

and where the signals from the remote control may easily reach the television

(about 6 m from the front).

■About the installation location

For the installation location of the wide-screen LCD television, thoroughly con-

sult the following items with the customer.

●The wide-screen LCD television is best viewed directly from the front.

●Avoid areas where the florescent lighting reflects on the wide-screen LCD

television surface. Although vertical angles can be adjusted, the mounting

bracket does not move horizontally.

●For the installation height, do not exceed the range of the connection cords

(AC adapter, antenna, etc.).

Be sure to install in a location where the AC adapter is not suspended and

where it can be placed on the floor, table, etc.

●Install where there are no objects within 20 cm below the wide-screen LCD

television.

●Check the installation height, depth, wall structure, etc., before performing

installation work.

Fall prevention string

x2 units

Wall mounting bracket B

(wall side)

Wall outlet

Bracket mounting screw B

x4 units

(ø4x25 mm)

Angle fixing screw

x2 units

(M4x10 mm)

Installation wall types

See 8a and 8b of “Installation (wall side preparation)”on

the back.

Plywood Concrete

Wall mounting

bracket B Wall mounting

bracket B

Cable clamper x3 units

AC adapter

Wide-screen LCD television

Video connection cable (optional)

Antenna

Bracket mounting screw A

x4 units

(M4x10 mm)

Metal plate

(main unit side)

Bracket mounting screwA

x2 units

(M4x10 mm) Clamper x3 units

Wall mounting bracketA

(main unit side)

Installation diagram

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Slide the stand in the

direction of the arrow

and remove by pulling

it up.

Removethe stand mount-

ing screws (6 units).

Locking

tabs

Hold the locks at the center of the

cable cover (both sides) and remove

the cover.

Locks

Pull the cover up in the direction the

shown and remove the stand cover.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Installation (main unit preparation)

Install wall mounting bracketsA and B (main unit side and wall side) correctly and securely.

1Remove the cable cover

Press down on the tabs (2 locations)

on the lower section of the cable

cover to release the locks, and pull

the tabs toward you.

2Remove the stand cover

Remove the cover mounting screws

(4 units).

3Remove the stand

Place a soft cloth on a

flat surface and place

the television on the

cloth with the LCD

panel facing down. Take

caution so that the LCD

panel does not get

scratched.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Turn the clampers 90°to lock.

At this time, mount the clampers so

that the hooks are facing down.

Fix the metal plate (main unit side)

using 2 mounting screwsA(main unit

side).

4Mount the clampers on the metal plate (main unit side)

Insert the clampers (3 units) into the

clamper mounting holes of the metal

plate (main unit side) from the side

with bulges.

5Mount the metal plate (main unit side)

Align the concave sections (2 loca-

tions) located on the upper section of

the metal plate with the convex sec-

tions on the rear of the wide-screen

LCD television.

6Attach the fall prevention strings

Attach the fall prevention strings (2 units) from the inner side of wall mounting bracket A

(main unit side) as shown in the diagram.

(M4x10 mm)

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Fix wall mounting bracketA (main unit side)

using 4 mounting screws A(main unit).

Be sure to securely fasten the screws on 4

locations (top, bottom, right and left).

7Mount wall mounting bracket A (main unit side)

Align the screw mounting section of

wall mounting bracket A (main unit

side) with the screw mounting sec-

tion on the rear of the wide-screen

LCD television.

Installation (wall side preparation)

8a Mount wall mounting bracket B (wall side) (Plywood)

Place wall mounting bracket B (wall side) on the installation position, determine

the screw positions so that the bracket is level, and make markings on the wall.

Fix wall mounting bracket B (wall side) using the 4 bracket mounting screws B

(plywood).

(M4x10 mm)

For plywood, thickness of at least 20 mm is required.

Use supplied bracket mounting screws B (for plywood) (ø4x25 mm)

Check to make sure there are no electrical wires within the wall.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

8bMount wall mounting bracket B (wall side) (Concrete)

Place wall mounting bracket B (wall side) on the installation position, determine

the screw positions so that the bracket is level, and make markings on the wall.

Embed the anchor bolt flush nuts into the installation position holes using the

method specified by the manufacturer.

Align wall mounting bracket B (wall mount) holes with the flush nuts, and screw in

the anchor bolts. Securely tighten the anchor bolts so that they do not become

loose. If necessary, lock the screws.

If washers are necessary, use washers that cannot be removed from the screw

holes of wall mounting bracket B or from the tip of the anchor bolts.

Anchor: Purchase commercially available product

Anchor bolt flush nut: 4 units

Anchor bolt: 4 units

For concrete, thickness of at least 55 mm is required.

Use a commercially available anchor (at least 5 mm in diameter, 30 mm in

length)

Check to make sure there are no electrical wires within the wall.

To prevent damage to the

wall, make sure that the

main unit is securely

mounted on the notches of

wall mounting bracket B

(wall side) before letting go

of the main unit.

Always work in pairs or

more when installing the

unit on the wall.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Example of

clamped cables

9a Bundling connector cables

Press down on the upper section of

the clamper with your thumb and pull

the edge using your index finger to

remove the hook.

Edge

Hook

9bBundling cables below the connector

Outer hole

Tip Inner hole

Clamp a single cable using the cable

clamper and insert the tip into the in-

ner hole.

Bundle all cables and insert the tip

into the outer hole.

Installation (mounting to wall)

10 Mount wall mounting bracket B (wall side)

Be sure to attach the fall prevention strings (2 units) on the hooks of wall mounting

bracket B (wall side).

Mount the main unit on wall mounting bracket B (wall side).

Cable

clamper

Clamper

Bundle the cables and apply the

clamper hook.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

11 Angle adjustment

This wide-screen LCD television wall mounting bracket can be installed in 4 angles:

5°upsweep, vertical, 5°downsweep and 10°downsweep.

Set the angle by adjusting the notches of wall mounting bracket B (wall side) and the

concave section of wall mounting bracket A (main unit side) to the desired angle by

referring to the diagrams below.

5°upsweep

5°downsweep

Vertical

10°downsweep

Lower notch

Upper notch

Fixing

hole

Lower notch

Upper notch

Fixing

hole

Lower notch

Upper notch

Fixing

hole

Lower notch

Upper notch

Fixing

hole

12 Angle fixing method

To prevent the main unit from falling, fix the main unit using angle fixing screws (2

units) from both sides using the fixing holes located on wall mounting brackets A and

B (main unit side and wall side).

If the fixing holes of the brackets do not align, installation is insufficient.

Check the installation again and fix so that screw holes are aligned.

Example: When adjusting the angle to 10°downsweep.

Angle fixing screw

(M4x10 mm)

Fixing hole

Caution

This manual suits for next models

Table of contents

Other Panasonic LCD TV manuals

Panasonic

Panasonic TC23LX60 - 23" LCD TV User manual

Panasonic

Panasonic TX-L42DT50Y User manual

Panasonic

Panasonic TC-55AS800U User manual

Panasonic

Panasonic Viera TC-L47WT50 Instruction Manual

Panasonic

Panasonic E50 series Assembly instructions

Panasonic

Panasonic TX-L24X6B User manual

Panasonic

Panasonic TC 19LX50 User manual

Panasonic

Panasonic Viera TH-L22X20ZK User manual

Panasonic

Panasonic TX-49FX780E Assembly instructions

Panasonic

Panasonic TCL42U22 - 42" LCD TV User manual

Panasonic

Panasonic Viera TH-50CS610A Assembly instructions

Panasonic

Panasonic Viera TX-32LX600F User manual

Panasonic

Panasonic Viera TC-L22C22X User manual

Panasonic

Panasonic TX-47AS800T Assembly instructions

Panasonic

Panasonic TC-L37E5-1 User manual

Panasonic

Panasonic TX-40CS620E User manual

Panasonic

Panasonic TC-L42U12 - 42" LCD TV User manual

Panasonic

Panasonic Viera TC-L50EM5 User manual

Panasonic

Panasonic TC26LX20 - 26" LCD TV User manual

Panasonic

Panasonic VIERA TX-32AS520B User manual

Panasonic

Panasonic TX-23LX50A User manual

Panasonic

Panasonic TH-L37S10R User manual

Panasonic

Panasonic TX-26LX62FA User manual

Panasonic

Panasonic Viera TX-L47ET5Y User manual

Popular LCD TV manuals by other brands

LG 32LC4R* Service manual

ViewSonic

ViewSonic N4200w-1 VS10945-1M Service manual

Salora

Salora 22LED1600 user manual

Samsung

Samsung LA32E420 E-manual

Dell

Dell W1900 19 Setting up

Samsung

Samsung LN40C670M1F user manual

Samsung

Samsung Series 4+ user manual

Samsung

Samsung 5 Series user manual

Grundig

Grundig 40 VLE 8230 BP manual

Philips

Philips 43PFL4901/F7 Service manual

Sony

Sony Bravia XBR-43X830C Service manual

LG 32LS350 owner's manual

VIORE

VIORE LED32VF60 Specifications

Toshiba

Toshiba Regza 42HL167 owner's manual

JVC

JVC LT-32A220 instructions

Philips

Philips 20TA1000/93 user manual

Philips

Philips 32PFL3158T/12 quick start guide

Sony

Sony Bravia KDL-V32XBR2 Specifications
