Panasonic SC-BT200 User instructions

Easy Setting Guide Blu-ray Disc Home Theater Sound System

Model No. SC-BT200

The order of setting

Main unit’s front panel

SETUP MIC

Setup microphone

(included)

Place the speaker setup microphone

at the actual seating position

(Listening position).

Front speakers

(L, R)

Surround speakers

(LS, RS)

Recommend

45° to 60°

120°

RED

PURPLE

GREY

WHITE

GREEN

BLUE

Preparing

the speakers

See below

1Place the

speakers

See below

2Connect the

cables

See rear

3Turn on the

main unit

See rear

→

speaker

FRONT

Lch

Insert the wire fully, taking

care not to insert beyond

the wire insulation.

+: White

: Blue

Attach the stickers at the position of the circled number in

the illustration below. Also, be sure to match the circled

number on the sticker, with the number indicated in the

illustration below.

Connecting the speaker cables.

e.g., Front speaker Lch

PUSH !

Step 1

Step 2

Front

speakers Surround

speakers Center speaker Subwoofer

PURPLEGREEN

Rch

RED

Lch

WHITE

Rch

GREY

Lch

BLUE

12 3 45

Refer to the rear label of the speaker before connecting the appropriate cable.

Do not use a front speaker as a surround speaker or vice versa.

Verify the type of speaker with the label on the rear of the speaker.

Preparing the speakers Place the speakers

WHITE

White

Blue

RQCA1841

F0309AC0

SMART SETUP

See SMART SETUP

screen

SCBT200EBESG-PSG0317.indd1SCBT200EBESG-PSG0317.indd1 2009/03/2319:54:432009/03/2319:54:43

SPEA

CENTER

WOOFER

SUB-

AC IN

RETURN

SMART SETUP

Would you like to start smart setup?

Yes

Main unit

Preparing the remote

control

AUX(TV)

SPEAKERS

AV OU T

CENTER

3Ω3Ω

WOOFER

FRONT

6521

3Ω

SURROUND

VIDEO

OUT

VIDEO

OUT

AV OUT

3Ω

SUB-

)

(

By connecting this unit to the network, you can use the BD-Live and

VIERA CAST features.

Main unit

Shielded

LAN cable

(not included)

Telecommunications

equipment (modem, etc.)

Hub or broadband router

Internet

Other connection

Broadband Network Connections

(Optional)

R6/LR6, AA

Connect the AC mains lead to

the main unit before connecting

to the household mains

socket.

To a household

mains socket

(AC 220–240 V, 50 Hz)

AC mains lead

(included)

Turn on your TV and select the appropriate video

input mode (e.g., VIDEO 1, AV 1, HDMI, etc.) to suit

the connections to this unit.

The on screen display will guide you through the steps.*

CANCEL

PIP

VOL

1 2 3

4 5 6

7 8

VOL

PLAY

BD/SD

iPod

EXT-IN

MUTE

RADIO

abc

def

jkl

mno

tuv

ghi

qrs

xyz

Press [ ] to turn

on the main unit.

Connect the AC mains lead Turn on the TV 3Turn on the main unit 4The SMART SETUP starts

Turn on the main unit

OR With a Component Video cable

For detailed information, refer to the operating instructions.

OPTICAL

2(STB) 1(TV)

DIGITAL IN

COMPONENT

VIDEO OUT

VIDEO

OUT

AUX(TV)

AV OUT

SPEAKERS

CENTER

FRONT

6521

SURROUND

WOOFER

SUB-

FM ANT

75Ω

RF IN

RF OUT

RF IN YPRPB

COMPONENT

VIDEO IN VIDEO IN

OPTICAL OUT

AUDIO OUT

AV IN

Connect the cables by colour or by the numbers indicated in the illustration

to the appropriate terminals on the rear panel of the unit.

PURPLE GREEN RED WHITE GREY BLUE

Audio cable

(not included)

HDMI cable (not included)

Set top Box,

VCR, etc. RF cable

(not included)

To your cable TV service

or antenna

Adhesive tape

FM indoor antenna

(included)

Main unit’s speaker

terminals (rear panel)

With an HDMI cable

(Recommend connection)

Optical digital audio

cable (not included)

Component Video cable

(not included)

Video cable

(included)

Connect the cables

Press [, ] to select [Yes].

* If you want to restart the SMART SETUP, press [BD/SD] 

to select “BD/DVD” and press [SMART SETUP] on the 

main unit.

SCBT200EBESG-PSG0317.indd2SCBT200EBESG-PSG0317.indd2 2009/03/2319:54:442009/03/2319:54:44
