Panasonic FZ-VEB55 Series User manual

Operating Instructions

Port Replicator

Model No. FZ-VEB55 series

Printed in Taiwan

HS1219-1010

DHQX1676YA/T1

English

Deutsch

Français

Italiano

Español

Svenska

Polski

Čeština

Magyar

Suomi

Slovenčina

Русский

Қазақша

Українська

简体中文

繁體中文

한국어

日本語

Before operating this unit, please read these instructions and precau-

tions, and save them for future use.

FZ-VEB551U_Port replicator_OI(DHQX1676YA_T1)_18L.indb 1 2019/12/23 16:09:57

Thank you for purchasing the port replicator for the Panasonic FZ-55 notebook computer series*1.

By connecting your peripheral devices to the port replicator, you can save yourself the trouble

of having to connect and disconnect several cables every time you transport the computer.

*1 This port replicator cannot be used for other models.

zParts Included

Operating Instructions (This book)......................................................................1

zThis manual explains the procedure for default settings. The procedure may differ

according to the settings.

z: Reference to the on-screen manuals of the computer.

NOTE

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are

trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United

States and other countries.

Names of products, brands, etc., appearing in this manual are trademarks or registered

trademarks of their respective own companies.

Introduction

FZ-VEB551U_Port replicator_OI(DHQX1676YA_T1)_18L.indb 2 2019/12/23 16:09:57

English

Safety Precautions

To reduce the risk of injury, loss of life, elec-

tric shock, fire, malfunction, and damage to

equipment or property, always observe the

following safety precautions.

Explanation of symbol word panels

The following symbol word panels are used

to classify and describe the level of hazard,

injury, and property damage caused when

the denotation is disregarded and improper

use is performed.

WARNING

Denotes a potential hazard that could

result in serious injury or death.

CAUTION

Denotes a hazard that could result in

minor injury.

The following symbols are used to classify

and describe the type of instructions to be

observed.

This symbol is used to alert users

to a specific operating procedure

that must not be performed.

This symbol is used to alert users

to a specific operating procedure

that must be followed in order to

operate the unit safety.

FZ-VEB551U_Port replicator_OI(DHQX1676YA_T1)_18L.indb 3 2019/12/23 16:09:58

WARNING

zDo Not Touch This Product In a

Thunderstorm If Connected with

the AC Cable or Any Other Cables

Electric shock may result.

zDo Not Place Containers of Liquid

or Metal Objects on Top of This

Product

If water or other liquid spills, or if

paper clips,coins, or foreign

matter get inside this product,fire

or electric shock may result.

•If foreign matter has found its way

inside, immediately unplug the AC plug

and remove the unit from this product.

Then contact your technical support

office.

zIf a Malfunction or Trouble Occurs,

Immediately Stop Use

If a Malfunction Occurs,

Immediately Unplug the AC Plug

Remove the Unit (This Product)

From This Product (the Unit)

•This product is damaged

•Foreign object inside this prod-

uct

•Smoke emitted

•Unusual smell emitted

•Unusually hot

Continuing to use this product while any

of the above conditions are present may

result in fire or electric shock.

•If a malfunction or trouble occurs,

immediately unplug the AC plug. Then

contact your technical support office for

repair.

Safety Precautions

FZ-VEB551U_Port replicator_OI(DHQX1676YA_T1)_18L.indb 4 2019/12/23 16:09:58

English

CAUTION

zDo Not Place This Product on

Unstable Surfaces

If balance is lost, this product

may fall over or drop, resulting in

an injury.

zDo Not Keep This Product

Wherever There is a Lot of Water,

Moisture, Steam, Dust, Oily

Vapors, etc.

Otherwise, possibly resulting in

fire or electric shock.

zDo Not Leave This Product in High

Temperature Environment for a

Long Period of Time

Leaving this product where it will

be exposed to extremely high

temperatures such as near fire or

in direct sunlight may deform the cabinet

and/or cause trouble in the internal parts.

Continued use in such a resulting condi-

tion may lead to short-circuiting or insula-

tion defects, etc. which may in turn lead

to a fire or electric shocks.

zUse Only the Specied AC Adaptor

With This Product

Using an AC adaptor other than

the one supplied (supplied with

the Panasonic computer or one

sold separately as an accessory) may

result in a fire.

FZ-VEB551U_Port replicator_OI(DHQX1676YA_T1)_18L.indb 5 2019/12/23 16:09:58

CAUTION

zDo Not Connect a Telephone Line,

or a Network Cable Other Than the

One Speci ed, Into the LAN Port

If the LAN port is connected to a

network such as the ones listed

below, a fire or electric shock

may result.

•Networks other than 1000BASE-T,

100BASE-TX or 10BASE-T

•Phone lines (IP phone (Internet Protocol

Telephone), Telephone lines, internal

phone lines (on-premise switches),

digital public phones, etc.)

zUsing this product continuously in

a hot environment will shorten the

product life. Avoid use in these types

of environments.

zWhen using in hot or cold environ-

ment, some peripherals may fail to

work properly. Check the operation

environment of the peripherals.

Safety Precautions

FZ-VEB551U_Port replicator_OI(DHQX1676YA_T1)_18L.indb 6 2019/12/23 16:09:58

English

Regulatory Information

For U.S.A.

Federal Communications Commission Radio Frequency Interference Statement

Note: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This equip-

ment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio com-

munications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television recep-

tion, which can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

zReorient or relocate the receiving antenna.

zIncrease the separation between the equipment and receiver.

zConnect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

zConsult the Panasonic Service Center or an experienced radio/TV technician for help.

Warning

To assure continued compliance, use only shielded interface cables when connecting to a

computer or peripheral. Also, any changes or modifications not expressly approved by the

party responsible for compliance could void the user’s authority to operate this equipment.

FZ-VEB551U_Port replicator_OI(DHQX1676YA_T1)_18L.indb 7 2019/12/23 16:09:58

Regulatory Information

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

This device is Class B verified to comply with Part 15 of FCC Rules when used with Pana-

sonic Notebook Computer.

Responsible Party: Panasonic Corporation of North America

Two Riverfront Plaza

Newark, NJ 07102

Support Contact: https://na.panasonic.com/us/support

6-M-1

For Canada

Canadian ICES-003

CAN ICES-3(B)/NMB-3(B)

7-M-2

FZ-VEB551U_Port replicator_OI(DHQX1676YA_T1)_18L.indb 8 2019/12/23 16:09:58

English

For EU

Disposal of Old Equipment

Only for European Union and countries with recycling systems

This symbol on the products, packaging, and/or accompanying documents means that

used electrical and electronic products must not be mixed with general household waste.

For proper treatment, recovery and recycling of old products, please take them to

applicable collection points in accordance with your national legislation.

By disposing of them correctly, you will help to save valuable resources and

prevent any potential negative effects on human health and the environment. For

more information about collection and recycling, please contact your local municipality.

Penalties may be applicable for incorrect disposal of this waste, in accordance with national

legislation.

36-E-2

Interface Cable

Use of an interface cable longer than 3 m {9.84 feet} is not recommended.

11-E-1

Declaration of Conformity (DoC)

“Hereby, Panasonic declares that this Port Replicator is in compliance with the

essential requirements and other relevant provisions of EU Council Directives.”

Authorised Representative:

Panasonic Testing Centre

Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, Germany 18-E-0

FZ-VEB551U_Port replicator_OI(DHQX1676YA_T1)_18L.indb 9 2019/12/23 16:09:58

Regulatory Information

For Turkey

Accordance with the WEEE Regulation.

Disposal of Old Equipment and Batteries Only for European Union and

countries with recycling systems

These symbols on the products, packaging, and/or accompanying documents

mean that used electrical and electronic products and batteries must not be mixed

with general household waste.

For proper treatment, recovery and recycling of old products and batteries, please

take them to applicable collection points in accordance with your national legislation.

By disposing of them correctly, you will help to save valuable resources and

prevent any potential negative effects on human health and the environment. For

more information about collection and recycling, please contact your local munici-

pality.

Penalties may be applicable for incorrect disposal of this waste, in accordance

with national legislation.

53-E_Tr-1

FZ-VEB551U_Port replicator_OI(DHQX1676YA_T1)_18L.indb 10 2019/12/23 16:09:59
