Panasonic Lumix DMC-3D1 User manual

DMC-3D1

Digital Camera

2-Lens System - 3D Photo and 3D Video Shooting

2-Lens System - "Wide & Zoom" and "Photo & Video" Dual

Shooting

Intuitive Operation with 3.5-inch 460,000-dot Smart Touch

Screen

Beautiful Low-light Images with High Sensitivity MOS Sensor

1,920 x 1,080 Full HD Video Recording

LUMIX Compact Digital Camera

Compact Digital Camera 3D1 - New Experience of the 3D Photo, 3D Video and 2D Dual Shooting

with the 2-Lens System Compact Camera

Metrics

Dimensions (W x H x D) 108.0 x 58.5 x 24.1 mm

(4.25 x 2.30 x 0.95 inch)

Weight Approx. 171 g without Battery and SD Memory Card (0.38 lb)

Approx. 193 g with Battery and SD Memory Card (0.43 lb)

Optics

Camera Effective Pixels 12.1 Megapixels

Sensor Size / Total Pixels / Filter 1/2.3-type High Sensitivity Mos Sensor x2 / 12.8 Total Megapixels / Pri-

mary Color Filter

Aperture F3.9 - 5.7 / 2-Step

(F3.9 - 9.0 (W) / F5.7- 13.0 (T))

Optical Zoom 4x

Focal Length f= 4.5 - 18.0 mm (2D: 25 -100mm, 3D(16:9): 33 - 132mm, 3D(4:3): 30 -

120mm in 35 mm equiv.)

(27-108mm in 35mm equiv. in video recording)

Extra Optical Zoom (EZ)

2D 4.9x (4:3 / 8M), 6.3x (4:3 / 5M), 7.8x (4:3 / under 3M)

Intelligent Zoom

2D 5x

Lens LUMIX DC VARIO x2

11 elements in 10 groups

(5 Aspherical Lenses / 9 Aspherical Surfaces)

Optical Image Stabilizer MEGA O.I.S. (On / Off)

Digital Zoom

2D 4x

Focusing Area

2D Normal: Wide 50 cm - infinity / Tele 100 cm - infinity

Macro / Intelligent Auto / Motion Picture: Wide 5 cm - infinity / Tele 100

cm - infinity

3D Normal: Wide 50 cm - infinity / Tele 100 cm - infinity

AF Assist Lamp Yes

Focus

2D Normal, AF Macro, Zoom Macro

Touch AF/AE

Quick AF ON/OFF(On in Intelligent Auto), Continuous AF(only for moti-

on picture)

AF Tracking

3D Normal

Touch AF/AE

Quick AF (Always On)

AF Metering

2D Face / AF Tracking / 23pt / 1pt / Spot

Touch Area

3D Face / 23pt / 1pt

Touch Area

Shutter Speed Still: 8 - 1/1300 sec

Starry Sky Mode : 15, 30 sec (only 2D)

Recording

File Format

2D Still Image: JPEG(DCF/Exif2.3)

Motion picture: AVCHD, MP4

3D Still Image: JPEG(DCF/Exif2.3),MPO

Motion picture: original fomat

Mode Dial / Mode Button

2D Intelligent Auto, Normal Picture, SCN, wide & zoom dual shooting

3D Normal Picture

Still Image Scene Mode

Portrait, Soft Skin Transform, Self-Portrait, Scenery, Panorama Assist,

Sports, Night Portrait, Night Scenery, Handheld Night Shot, Food, Par-

ty, Candle Light, Baby1, Baby2, Pet, Sunset,

High Sensitivity, Flash Burst, Starry Sky, Fireworks,

Beach, Snow, Aerial Photo, Pin Hole, Film Grain,

High Dynamic(Standard / Art / B&W), Photo Frame

Continuous Shooting Mode

2D Full- Resolution Image: 8 frames/sec

Max. 12 images (Standard / Fine Mode),

with AF Tracking: 4 frames/sec, 2 frames/sec

Motion Picture Recording (*2)

2D [HD Video] 1920 x 1080 pixels, 50i (FSH: 17Mbps / AVCHD) (Sensor

output is 25p)

[HD Video] 1280 x 720 pixels, 50p (SH: 17Mbps / AVCHD) (Sensor out-

put is 25p)

[HD Video] 1920 x 1080 pixels, 25 fps (FHD: 20Mbps / MP4) (Sensor

output is 25p)

[HD Video] 1280 x 720 pixels, 25 fps (HD: 10Mbps / MP4) (Sensor out-

put is 25p)

[STD Video] VGA: 640 x 480 pixels, 25 fps (4Mbps / MP4)

3D 1920 x 1080 pixels, side by side, 50i

AVCHD (Continuous recordable time [motion pictures])

2D approx. 70 min (FSH)

3D approx. 50min

*original format

MP4 (Continuous recordable time [motion pictures])

2D approx. 70min (FHD)

AVCHD (Actual recordable time [motion pictures])

2D approx. 30 min (FSH,SH)

3D approx. 25 min (FSH)

MP4 (Actual recordable time [motion pictures])

2D approx. 30 min (FHD)

Exposure Program AE

Exposure Compensation 1/3 EV step, +/- 2 EV

Auto (AE) Bracketing

2D 1/3 ~1EV step, Max +/-1, 3 frames

Light Metering Intelligent Multiple

ISO Sensitivity

2D Auto / i.ISO / 100 / 200 / 400 / 800 / 1600 / 3200

High Sensitivity mode (ISO 1600-6400)

3D Auto

Still Picture Recording

2D [1:1] 2992x2992(9M) / 2448x2448(6M EZ) / 1920x1920(3.5M EZ) /

1536x1536(2.5M EZ) / 480x480(0.2M EZ)

[4:3] 4000x3000(12M) / 3264x2448(8M EZ) / 2560X1920(5M EZ)

/2048X1536(3M EZ) / 1600x1200(2M EZ) / 640x480(0.3M EZ)

[3:2] 4000x2672 (10.5M) / 3264x2176 (7M EZ)/ 2560x1712 (4.5M EZ) /

2048x1360 (2.5M EZ) / 640x424(0.3M EZ)

[16:9] 4000x2248 (9M) / 3264x1840 (6M EZ)/ 2560x1440(3.5M EZ) /

1920x1080 (2M EZ) / 640x360 (0.2M)

3D [4:3] 3264x2448(8M)

[16:9] 3264x1840 (6M)

Image Quality

2D Fine / Standard

3D 3D mode: MPO

White Balance

2D Auto / Daylight / Cloudy / Shade / Incandescent / White Set

3D Auto

Color mode / Color Effect / My Color

2D Standard, Natural, Vivid, Black & White, Sepia, Cool, Warm

Happy (only in iA Mode)

Digital Red Eye Correction (Red-Eye Removal)

2D Yes

Optical Zoom in Motion Picture

2D Yes

Self Timer 2 sec / 10 sec

Playback

Playback Mode Normal Playback, Slideshow, Filtering Playback (Picture Only, Video

Only, Category, 3D, Favorites),

Dual Image Playback, Calendar Playback

Thumbnails / Zoomed Playback 12,30-thumbnails / Yes Touch Magnification

Calendar Display / Dual-Image

Playback

Yes / Yes

Set Favorites / Rotate Image

2D Yes / Yes

3D Yes / No

Show Histogram Yes

DPOF Print Setting / Set Protection

2D Yes / Yes

3D Yes(JPEG only) / Yes

Resize / Cropping / Aspect Conv. / Leveling

2D Yes / Yes / No / No

3D No / No / No / No

Copy / Title Edit / Text Stamp

2D Yes / Yes / Yes

3D Yes / No / No

Cut Animation

2D Yes

Video Divide Yes

PictBridge Support

2D Single / Multi / All / Favorites / DPOF

3D Single / Multi / All / Favorites / DPOF *JPEG only

Setup

OSD language Japanese, English, German, French, Italian, Spanish, Polish, Czech,

Hungarian, Netherlandic, Turkish, Portuguese, Finnish, Danish, Swe-

dish, Greek

Others

LCD Monitor 8.8cm(3.5") TFT Full Touch Screen LCD Display (460K dots), AR Coa-

ting

Field of View : approx. 100%

Power LCD mode, AUTO Power LCD mode

Built-in-Flash Auto, Auto/Red-eye Reduction, Forced On,

Slow Sync./Red-eye Reduction, Forced Off, Forced On/Red- eye Re-

duction

0.3 - 3.5m (Wide/ISO Auto), 1.0 - 2.4m (Tele/ISO Auto)

Recording Media Built-in Memory, SD Memory Card, SDHC Memory Card, SDXC Memo-

ry Card

Built-in-Memory Approx. 70MB

Microphone / Speaker Stereo / Yes

Interface mini HDMI, AV Output (NTSC), USB2.0 High speed

Power Li-ion Battery Pack (3.6V, Minimum:895mAh) (Included)

AC Adaptor (Input: 110-240V AC) (Optional)

Battery life (approx.) 200 pictures (CIPA Standard)*1

Included Software PHOTOfunSTUDIO 7.0 HD Edition

QuickTime

Adobe Reader

NOTE *1

Recording conditions by CIPA standard

- CIPA is an abbreviation of [Camera & Imaging Products Association].

- Temperature: 23 oC (73.4 oF)/Humidity: 50%RH when LCD monitor is

on.

- Using a Panasonic SD Memory Card (32 MB).

- Using the supplied battery.

- Starting recording 30 seconds after the camera is turned on. (When

the optical image stabilizer function is set to [ON].)

- Recording once every 30 seconds with full flash every second recor-

ding.

- Rotating the zoom lever from Tele to Wide or vice versa in every re-

cording.

- Turning the camera off every 10 recordings and leaving it until the

temperature of the battery decreases.

- The number of recordable pictures decreases in Auto Power LCD Mo-

de and Power LCD Mode.

- These are standard times taken at a temperature of 23 oC (73.4 oF)

and a humidity of 50%RH.

- The time available for recording varies depending on the environment,

the interval between recordings, and the manner of use.

- Actual recordable time is the time available for recording when repea-

ting actions such as switching the power supply [ON] / [OFF], starting/

stopping recording, zoom operation etc.

• The maximum time for continuous recording of 3D motion pictures is

29 minutes 59 seconds.

• Motion pictures with [FSH] in [AVCHD] can be recorded continuously

for up to 29 minutes 59 seconds.

• Motion pictures in [MP4] can be recorded continuously for up to 29 mi-

nutes 59 seconds or up to 4GB.
