Panasonic KX-TG6021 User manual

PQQW15464XA-RF DM1106PY2027

Setting up

For further information, visit http://www.panasonic.com/help

Base unit CHARGE 7 HOURS

Handset

Charger*1

(120 V AC, 60 Hz)

Use only the included Panasonic AC adaptor

PQLV203.

*1 KX-TG6022/KX-TG6023/KX-TG6052/KX-TG6053/KX-TG6054

(120 V AC, 60 Hz)

Noise filter

(For DSL service users)

Hooks

Confirm

“Charging” is

displayed.

[1]

10:30AM AUG.15

Charging

“Click” To single-line

telephone jack

(RJ11C)

Press

plug

firmly.

Use only the included

Panasonic AC adaptor

PQLV208.

Model No. KX-TG6021/KX-TG6022

KX-TG6023/KX-TG6051

KX-TG6052/KX-TG6053

KX-TG6054

Quick Guide

TG602x_605x_QG(e)_cover_MPO.fm Page 1 Friday, January 26, 2007 2:31 PM

– 2 –

Operating tips

{}: shows button names.

Using the navigator key

Press {^}, {V}, {<}, or {>}to navigate

through menus and to select items shown

on the display.

Adjusting audio volume

Press {^} or {V} repeatedly while talking.

Handset soft keys

The handset features 2 soft keys. By

pressing a soft key, you can select the

feature shown directly above it on the

display.

{Select}, {Save}, {OK}, and additional

other functions are assigned to soft keys.

Pay attention to soft keys to find functions

you need during handset operation.

Date and time (Handset)

1{MENU}i{4}{1}

2Enter the current month, day, and year by selecting 2 digits for each.

3Enter the current hour and minute (12-hour clock format) by selecting 2 digits for

each.

4{AM/PM}: Select “AM” or “PM”. i{Save}i{OFF}

Adding items to the phonebook (Handset)

1{Phonebook}i{Add}

2Enter the name (max. 16 characters). i{Next}

3Enter the phone number (max. 32 digits). i{Next}i{Save}i{OFF}

For further information, visit http://www.panasonic.com/help or refer to Operating

Instructions.

{V}

{^}

{<}{>}

10:30AM [1]

View Phone

CID book

TG602x_605x_QG(e).fm Page 2 Friday, January 26, 2007 2:27 PM

– 3 –

Basic operation (Handset)

Feature Operation

Adjusting the receiver/

speaker volume

Press {^} or {V} repeatedly while talking.

Making a call using the redial

list

{REDIAL}i{V}/{^}: Select the desired phone

number. i{C}

Viewing the caller list and

calling back

{View CID}iPress {V} or {^} repeatedly to

select the desired item. i{C}

Ringer volume 1{MENU}i{1}{1}

2{^}/{V}: Select the desired volume. i{Save}

Answering call-waiting call

(2nd call)

Press {CALL WAIT}when you hear call waiting

tone.

KX-TG6051/KX-TG6052/KX-TG6053/KX-TG6054

Answering system (Base unit)

Feature Operation

Auto answer on/off {ANSWER ON}

Recording your greeting

message

(max. 2 minutes)

1{GREETING REC}

2Within 10 seconds, press {GREETING REC}

again.

3Speak clearly about 20 cm (8 inches) away from

the MIC.

4To stop recording, press {STOP}.

Listening to new messages When the MESSAGE indicator flashes on the base

unit, press {MESSAGE}.

Listening to old messages When the MESSAGE indicator does not flash on the

base unit, press {MESSAGE}.

Erasing a message Press {ERASE}during playback.

Using the answering system

remotely

1Dial your phone number from a touch tone

phone.

2After the greeting message starts, enter your

remote code. (Default remote code is “11”.)

LThe unit plays back new messages.

LAfter playing back new messages, the voice

guidance starts.

3Follow the voice guidance as necessary.

For further information, visit http://www.panasonic.com/help

TG602x_605x_QG(e).fm Page 3 Friday, January 26, 2007 2:27 PM

– 4 –

Frequently asked questions

Question Cause/solution

How can I increase handset

volume level?

LPress navigator key {^} repeatedly while talking.

Why is the conversation

noisy or cutting off?

LTry to relocate the base unit so that distance from

location to use the handset will be minimized.

LSend your unit to service, if your unit has same

problem when the handset is next to the base unit.

Can I add another accessory

handset to my base unit?

LYes, you can add up to 4 handsets (including the

handset(s) sold with your own base unit) to a

single base unit.

LTo purchase accessory handset (KX-TGA600),

please visit http://www.panasonic.com

or call 1-800-332-5368. TTY users (hearing or

speech impaired users) can call 1-866-605-1277.

Can I keep battery charging

all the time?

LYou can leave handset on the base unit or charger

anytime. There is no damage to the battery.

How can I answer a call-

waiting call (2nd call)?

LPress {CALL WAIT}when you hear call-waiting

tone.

Quick troubleshooting

Check if another person is using the telephone.

Yes

Wait until they are finished.

Re-registration failed.

“System is busy. Please try again later.”

1Handset shows:

“System is busy.Please

try again later.”

is still displayed.

Try to re-register your handset

as explained later in this

guide.

Your telephone may need service.

Please visit http://www.panasonic.com/help for further troubleshooting.

TG602x_605x_QG(e).fm Page 4 Friday, January 26, 2007 2:27 PM

– 5 –

Quick troubleshooting

Place the handset on the base unit, then

check if “Charging” is displayed.

“Charging” is not displayed. “Charging” is

displayed.

Unplug and then plug AC

adaptor properly to both the

base unit and AC outlet.

Unplug the AC adaptor of the base unit and remove the

battery from the handset, then plug in the AC adaptor and

insert the battery into the handset again. Try re-registration

as explained later in this guide.

Lift the handset, then try again.

If handset still shows the same

message, try re-registration as

explained later in this guide.

“Charging” is still not

displayed.

Re-registration failed.

“Charging” is

displayed, now.

Your telephone may need service.

Please visit http://www.panasonic.com/help for further troubleshooting.

“No link to base. Move closer to base, try again.”

2Handset shows:

TG602x_605x_QG(e).fm Page 5 Friday, January 26, 2007 2:27 PM

– 6 –

Quick troubleshooting

Lift up the handset from the base unit or

charger.

Press {C} (TALK) at the handset, then

check if the display shows “Talk”.

Press {s} (SP-PHONE),

then check if the dial tone

is heard from the speaker

on the back.

No dial tone

Dial tone is

heard.

{C}

{s}

“No link to base.

Move closer to

base, try again.” is

displayed.

“Talk” is

displayed.

Try remedy for

2on previous

page.

Check the telephone

cord is properly

connected to both the

base unit and

telephone line jack on

the wall.

Your telephone

may need service

when only back

speaker provides

a dial tone.

3No dial tone is heard from handset.

Your telephone may need service.

Please visit http://www.panasonic.com/help for further troubleshooting.

Still no dial tone

No link to base.

Move closer to

base, try again.

Talk

Slow Mute

TG602x_605x_QG(e).fm Page 6 Friday, January 26, 2007 2:27 PM

– 7 –

Registering a handset to base unit

The included handset and base unit are preregistered. If for some reason the

handset is not registered to the base unit, register the handset.

For further registration information, visit

http://www.panasonic.com/RegisterYourHandset

Handset

Press {MENU}, then press {0}{0}{1}.

Handset

Press {OK}, then press {OFF}after a

beep sounds.

Base unit

KX-TG6021/KX-TG6022/KX-TG6023

Press and hold {LOCATOR}until the

IN USE indicator flashes.

LComplete next step within 1 minute.

KX-TG6051/KX-TG6052/KX-TG6053/

KX-TG6054

Press and hold {LOCATOR/INTERCOM}

until the IN USE indicator flashes.

LComplete next step within 1 minute.

KX-TG6021

KX-TG6022

KX-TG6023

KX-TG6051

KX-TG6052

KX-TG6053

KX-TG6054

Press LOCATOR

on base for 3sec

Then press OK

Press LOCATOR

on base for 3sec

Then press OK

{MENU}

{OK}

TG602x_605x_QG(e).fm Page 7 Friday, January 26, 2007 2:27 PM

1Read this Quick Guide or Operating

Instructions

LIf you lost Operating Instructions, you can

download at

http://www.panasonic.com/help

2Visit our website:

http://www.panasonic.com/help

LFAQs and troubleshooting hints are available.

3Contact us via the web at:

http://www.panasonic.com/contactinfo

4Call us at:

1-800-211-PANA (1-800-211-7262)

LMonday - Friday 9:00am - 9:00pm (EST),

Saturday/Sunday 10:00am - 7:00pm (EST)

To order a replacement battery,

please call: 1-800-332-5368

Or visit:

http://www.panasonic.com/batterystore

IMPORTANT!

If your product is not

working properly. . .

TG602x_605x_QG(e).fm Page 8 Friday, January 26, 2007 2:27 PM
