Panasonic SLSW850 - PORT. CD PLAYER User manual

AD9907178C8

PortableCD Player

SL-SW850

Traverse Deck:RAE0220ZMechanismSeries

Colour

(S)............SilverType

Areas

EB............Great Britain.

EG............Europeand Russia.

GC............Asiaand Saudi Arabia.

GN............Oceania.

SPECIFICATIONS

Specification

Audio

No. ofchannels: 2 channels(left and right,

stereo)

Frequencyresponse: 20 to 20,000 Hz(+0.5dB, -1.5dB)

Outputvoltage: 0.6V(50k )

S/N: more than 94 dB*

Wowand flutter: Belowmeasurablelimit

DAconverter: 1 bit, MASH

Headphones outputlevel: Max. 9mW+9mW/16

(adjustable)

Pickup

Lightsource: Semiconductorlaser

Wavelength: 780 nm

General

Operational temperature range: 0°C-40°C

Rechargeabletemperature

range: 5°C-40°C

Power supply: DC 4.5V

Power consumption

Power source ANTI-SHOCK OFF/ON

When Using ACadaptor 2.8W/3.0W

When Using Battery(DC3V) 0.3W/0.35W

When recharging: Approx. 5.4W

Playtime

[When used in hold mode, at25°C(77°F)temperature and on

flatand stablesurface]

Batteries used ANTI-SHOCK OFF/ON

2“AA”(LR6)alkaline

batteries About20h/About25h

Ni-cd Rechargeablebatteries

(RFKFP3GAVABA) About10h/About12h

Theplaytime maybeless depending on theoperating

conditions.

Recharging time: About3h

Dimensions(WxHxD): 133x24.7x141.5mm

Weight: 327g with batteries

282g withoutbatteries

*These specificationswere measured in theANTI-SHOCK off

mode.

Note:

Specificationsare subjectto changewithoutnotice.

Weightand dimensionsare approximate.

Unauthorizedcopying and distribution isaviolation oflaw.

1. Precaution ofLaser Diode

CAUTION:

Thisproduct utilizes alaserdiodewiththeunitturned"on",

invisiblelaserradiation isemittedfrom thepickup lens.

Wavelength:780 nm

Maximum outputradiation powerfrom pickup:100 W/VDE

Laserradiation from thepickup lensissafetylevel, butbesurethe

followings:

1. Donotdisassembletheoptical pickup unit, since radiation from

exposedlaserdiodeisdangerous.

2. Donotadjust thevariableresistor on thepickup unit. Itwas

alreadyadjusted.

3. Donotlookat thefocuslensusing optical instruments.

4. Recommend nottolookat pickup lensfor along time.

ACHTUNG:

Dieses Produkt enthalteineLaserdiode. Imeingeschalteten

Zustand wird unsichtbareLeserstrahlung von derLasereinheit

abgestrahlt.

Wellenlage:780 nm

MaximaleStrahlungsleistung derLasereinheit:100 W/VDE

DieStrahlung anderLasereinheitist ungefahrlich, wenn folgende

Punkte beachtet werden:

1. DieLasereinheitnichtzerlegen, dadieStrahlung ander

freigelegtenLaserdiodegefahrlichist.

2. DenwerkseitigjustiertenEinstellreglerderLasereinhitnicht

verstellen.

3. NichtmitoptischenInstrumentenindieFokussierlines blicken.

4. NichtuberlangereZeitindieFokussierlines blicken.

2. Accessories

-Stereoheadphones ......................................... 1pc.

(RFEV708P-HS)

-Hand grip........................................................... 1pc.

(RGQT0006-K)

-Ni-Cdrechargablebatteries

withcarrying case...................... ...................... 1pc.

(RFKFP3GAVABA)

ForEB area

-ACadaptor ........................................................ 1pc.

(RFEA403B-S)

ForEGarea

-ACadaptor ........................................................ 1pc.

(RFEA401E-3S)

ForGC area

-ACadaptor ........................................................ 1pc.

(RFEA403Z-S)

ForGN area

-ACadaptor ........................................................ 1pc.

(RFEA403A-S)

-Plug adaptor...................................................... 1pc.

(SJP5213-2)

3. Operating Instructions

4. Handling Precautions for Traverse Deck

The laserdiode inthe traverse deck (optical pickup) maybreak downdue to potential difference

causedbystatic electricity

of clothes orhumanbody.

So, be careful of electrostatic breakdownduring repairof the traverse deck (optical pickup).

4.1. Handling thetraverse deck (optical pickup)

1. Thetraverse deck (optical pickup)isanextremely

high-precision construction and must notbesubjected

toimpact, excessivevibration, or othertypes ofrough

handling.

2. Inordertopreventstaticelectricitydamagetothelaser

diode, use ashortpinor similartool toshorttheoptical

pickup’sflexiblecircuitboardsaftertheyhavebeen

disconnectedfrom themaincircuitboard.

3. Handletheflexiblecircuitboardswithcare;excessive

force couldcause themtobebroken.

4. Donotturn thepre-set variableresistor (for adjustmentof

thelaserpower);ithas beenadjustedat thefactory.

(as shownin Fig. 1 )

Fig. 1

4.2. Grounding for electrostaticbreakdownprevention

1. Humanbodygrounding

Use theanti-staticwrist straptodischargethestatic

electricityfrom your body.

2. Worktablegrounding

Putaconductivematerial (sheet) or steel sheet on the

area wheretheoptical pickup isplaced, and ground

thesheet. (as shownin Fig. 2 )

Fig. 2

Caution:

Thestaticelectricityofyour clothes will notbegrounded

through thewrist strap.

So, take carenottolet your clothes touchthetraverse deck

(optical pickup).

5. Operation Checks and ComponentReplacement

Procedures

6. Checking the Operation Problemson the Traverse

Deck (Optical Pickup)

Make sure to followthe procedures belowto check the operation problems of the traverse deck

(optical pickup) before replacing it.

Replace the traverse deck onlyafterthe problemis identified.
