Panasonic SDR-S70 User manual

SDR-S70

Camcorder

SDXC/SDHC/SD Memory Card Recording

Dramatic Close-up with Enhanced Optical 78x Zoom

Advanced O.I.S. with Active Mode

33mm Wide-angle Lens

iA (Intelligent Auto) with AF/AE Tracking

Wind Noise Canceller for Clear Sound Recording

SD Card Camcorder with 33mm Wide-Angle, 78x Ultra Zoom

GENERAL

Power Supply (Battery / AC Ad-

apter)

DC3.6V / 5.0V

Power Consumption Max. 2.9W (Recording) / Max. 7.7W (Charging)

Weight (w/o Battery) approx. 212g

Dimension (W x H x D) 54.9 x 64.0 x 107.3 [mm]

Media SD/SDHC/SDXC Memory Card

On-Screen Display Language English, German, French, Italian, Spanish, Polish, Czech, Netherlandic,

Turkish, Swedish

IMAGE SENSOR

Image Sensor 1/8-type CCD

Total Pixels 0.8 megapixels

Effective Pixels

Motion Image 0.41 megapixels - 0.52 megapixels [4:3]

0.38 megapixels - 0.47megapixels [16:9]

Still Image 0.41 megapixels - 0.52 megapixels [4:3]

0.38 megapixels - 0.47megapixels [16:9]

LENS SECTION

Lens Brand Panasonic Lens

F Value F1.9(WIDE) / 5.7(TELE)

Optical Zoom 70x

Focal Length 1.48 - 104mm

35mm Film camera Equivalent Enhanced Optical Zoom OFF: 37.4mm - 2625mm [4:3]

36.5mm - 2571mm [16:9]

Enhanced Optical Zoom ON: 33.5mm - 2625mm [4:3]

32.8mm - 2571mm [16:9]

CAMERA SECTION

Standard Illumination 1400 lx

Minimum Illumination 5.0 lx (1/25 Low Light scean mode)

2 lx (Color Night View)

Image Stabilizer Advanced O.I.S. [Optical Image Stabilizer]

Focus Auto / Manual

White Balance Auto / Indoor1 / Indoor2 / Sunny / Cloudy / White set

Shutter Speed

Motion Image Auto Slow Shutter ON : 1/25-1/8000

OFF : 1/50-1/8000

Iris Auto / Manual

Zoom

Enhanced Optical Zoom 78x

Digital Zoom 100x / 3500x (The maximum value of zoom magnification)

Backlight Compensation Yes

MONITOR

Monitor (LCD) 6.7cm (2.7") Wide LCD ( 123,200 dots)

STILL IMAGE SECTION

Recording Format JPEG

Recording Image Size

Still Picture 0.3 megapixels (640 x 480) [4:3]

0.2 megapixels (640 x 360) [16:9]

Simultaneous Recording 0.3 megapixels (640 x 480) [4:3], 0.2 megapixels (640 x 360) [16:9]

Creating still picture from moti-

on picture

0.3 megapixels (640 x 480) [4:3], 0.2 megapixels (640 x 360) [16:9]

DPOF Max. 999 images

RECORDING SECTION

Signal System 625 / 50i

Recording Format MPEG2, H.264/AVC [Motion Image]

Recording / Playback MODE

Recording / Playback Mode XP (10Mbps / VBR) , (720 x 576)

SP (5Mbps / VBR) , (720 x 576)

LP (2.5Mbps / VBR) , (720 x 576)

Audio Recording System HDD / SD Card ; MPEG1 AudioLayer 2

Microphone Stereo mic. / Zoom mic.

Speaker Dynamic type

Media Remaining Indication Yes

INTERFACES

AV Out

USB 2.0 Hi-Speed

STANDARD ACCESSORIES

AC Adaptor Yes

AC Cable Yes

DC Cable included AC Adaptor

Rechargeable Battery Pack min. 1790 mAh / Lithium-Ion

AV multi Cable -

AV Cable Yes

IR Remote -

Shoe Adaptor -

USB Cable Yes

SD Memory Card -

Included Software VideoCam Suite 3.5
