HX-DC1

Upright HD Camcorder

Full-HD* Recording in MP4 Format

14-megapixel Still Picture Recording*

285° Rotating, 3.0-inch Wide-screen LCD

12x Double Range Zoom

MPEG-4 AVC/H.264

A stylish, easy-to-hold vertical design

Upright Full-HD Camcorder

GENERAL

Power Supply DC3.7V (Battery) / 5.0V (USB)

Dimension (W x H x D) approx. 86.2 x 120.8 x 38.1mm (3.40 x 4.76 x 1.50inch)

Power Consumption 2.9W (Recording) / 3.1W (Charging)

On-Screen Display Language English, German, French, Italian, Netherlandic, Swedish, Spanish, Po-

lish, Czech, Turkish

Weight

Without Battery and SD Card approx. 163g (0.360lb)

With Battery and SD Card approx. 181g (0.399lb)

SENSOR SECTION

Image Sensor 1/2.33" CMOS Sensor

Total Pixels 14.4 Megapixels

Effective Pixels

Motion Image 11.9 Megapixels [16:9]

14.3 Megapixels [4:3]

Still Image 11.9 Megapixels [16:9]

14.3 Megapixels [4:3]

LENS SECTION

Price*: 179.99 GBP

*Panasonic Online Shop Price

F Value F3.5(WIDE), F3.7(TELE)

Optical Zoom 5x

Focal Length 6.8 - 34.0mm

35mm Film camera Equivalent

Motion Image (W-Range Zoom W mode) 40.1- 240.6mm [16:9], 39.2- 235.2mm [4:3]

(W-Range Zoom T mode) 82.4- 494.4mm [16:9], 80.9- 485.4mm [4:3]

Still Picture 39.9 - 199.5mm [16:9], 38.6 - 193.0mm [4:3]

CAMERA SECTION

Image Stabilizer E.I.S. [Electorical Image Stabilizer]

Focus Auto/Manual

White Balance Auto/ Manual (Sunny, Cloudy, Incandescent, Whiteset)

Standard Illumination 1400 lx

Iris Auto

Minimum Illumination 17lx (Scene mode off: 1/30), 5lx (Low Light Mode: 1/15)

Zoom

Optical Zoom 5x

Advanced Zoom / W-Range

Zoom (Only for Motion Image)

W-Range Zoom 12x

Digital Zoom 60x [Motion Image] , 50x [Still Image]

Shutter Speed

Motion Image 1/30 - 1/10000

(Low Light Mode: 1/15 - 1/10000)

Still Image 1/2 - 1/1500

MONITOR

Monitor (LCD) 7.5cm (3.0") Wide LCD ( 230,400 dots)

STILL IMAGE SECTION

Recording Format JPEG(DCF/Exif2.2)

Recording Image Size

Still Picture [4:3]

14 megapixels-H (4352 x 3264), 14 megapixels-S (4352 x 3264)

2 megapixels (1600 x 1200),0.3 megapixels (640 x 480)

[16:9]

10 megapixels (4352 x 2448)

2 megapixels (1920 x 1080), 0.9 megapixels (1280 x 720)

Simultaneous Recording [16:9] 2.1 megapixels, (1920 x 1080)

0.9 megapixels,(1080 x 720)

[4:3] 0.3 megapixels, (640 x 480)

Yes

Creating still picture from moti-

on picture

Flash Yes

RECORDING SECTION

Signal System 1080/60i* ,1080/30p* , 720/60p* ,720/30p* , 480/30p* ,540/30p*

Recording Format MPEG-4 AVC/H.264

Recording / Playback Mode 1080/ 60i* , (1920 x 1080)

1080/ 30p* , (1920 x 1080)

720/ 60p* , (1280 x 720)

720/ 30p* , (1280 x 720)

480/ 30p* , (640 x 480)

540/ 30p* , (960 x 540)

Audio Recording System AAC (2ch)

Microphone 2ch stereo

Speaker Dynamic type

Media Remaining Indication yes

Media (Motion/ Still Image) SD/SDHC/SDXC Memory Card

INTERFACES

AV output

HDMI Yes(mini)

USB 2.0 Hi-Speed

STANDARD ACCESSORIES

AC Adaptor Yes

Rechargeable Battery Pack min. 700 mAh / Lithium-Ion

AV Cable Yes

USB Cable Yes

Included Software HD Writer VE1.0

NOTES * In PAL regions, images are converted from 60i to 50i, 60p to 50p and

30p to 25p for playback.
