Panasonic HDC-SDT750 User manual

HDC-SDT750

3D Camcorder

3D Image Shooting with the 3D Conversion Lens

Advanced 3MOS System

1080/50p Recording (Full-HD 1920 x 1080, 50 Progressive Re-

cording)*

HYBRID O.I.S.** That Gives Hybrid Optical/Electrical Hand-

shake Correction

O.I.S. Lock

Easy 3D Playback on 3D compatible TVs/AVCHD Compatible

Player/Recorders

Full HD 3MOS Camcorder with 3D Conversion Lens for 3D video recording

GENERAL

Power Supply (Battery / AC Ad-

apter)

DC7.2V / 9.3V

Power Consumption Max. 6.0W (Recording)

Weight (w/o Battery) approx. 375g

Dimension (W x H x D) 66 x 69 x 138 [mm]

Media SD/SDHC/SDXC Memory Card

On-Screen Display Language English, German, French, Italian, Spanish, Polish, Czech, Netherlandic,

Turkish, Swedish

IMAGE SENSOR

Image Sensor 1/4.1-type MOS x 3

Total Pixels 9.15 megapixels (3.05 megapixels x 3)

Effective Pixels

Motion Image 7.59 megapixels (2.53 megapixels x 3)[16:9]

Still Image 7.89 megapixels (2.63 megapixels x 3 ) [3:2]

7.59 megapixels (2.53 megapixels x 3) [16:9]

6.96 megapixels (2.32 megapixels x 3 ) [4:3]

LENS SECTION

Focal Length 3.45-41.4mm

Lens Brand Leica Dicomar Lens

Award

2010-09-29T09:55:00

HDC-SDT750, Cnet,

Editor's Choice Award,

September 2010

Award

2010-09-29T09:56:00

HDC-SDT750, Trusted

Reviews, 8 out of 10 ra-

ting, September 2010

Award

2010-11-01T10:25:00

HDC-SDT750, Stuff, 5

Stars, November 2010

F Value F1.5(WIDE)/2.8(TELE)

Optical Zoom 12x

35mm Film camera Equivalent 35.0-420mm (16:9) [Motion Image]

35.7-428mm (3:2), 35.0-420mm (16:9), 38.8-466mm (4:3) [Still Image]

Filter Diameter 46mm

CAMERA SECTION

Standard Illumination 1400 lx

Minimum Illumination 1.6 lx (1/25 Low Light scene mode)

1 lx (Color Night View)

Image Stabilizer HYBRID O.I.S. [Optical Image Stabilizer]

Focus Auto / Manual

White Balance Auto / Indoor1 / Indoor2 / Sunny / Cloudy / White set

Shutter Speed

Motion Image [50i / 50p] Auto Slow Shutter ON : 1/25-1/8000 , video flash: 1/25-1/500

OFF : 1/50-1/8000, video flash: 1/50-1/500

[25P] Auto Slow Shutter ON : 1/25-1/8000 , video flash: 1/25-1/500

OFF : 1/50-1/8000, video flash: 1/50-1/500

Still Image 1/2-1/2000, video flash: 1/2-1/500

Iris Auto / Manual

Zoom

Intelligent Zoom 18x

Digital Zoom 30x / 700x (The maximum value of zoom magnification)

Backlight Compensation Yes

MONITOR

EVF Yes

Monitor (LCD) 7.6cm (3.0") Wide LCD ( 230,400 dots)

STILL IMAGE SECTION

Recording Format JPEG

Recording Image Size

Still Picture 14.2 megapixels (4608 x 3072), 8.6 megapixels (3600 x 2400), 5.5 me-

gapixels (2880 x 1920) [3:2]

13.3 megapixels (4864x2736), 8.3 megapixels (3840 x 2160), 5.3 me-

gapixels (3072 x 1728) [16:9]

12.2 megapixels (4032 x 3024), 7.7 megapixels (3200 x 2400),

4.9 megapixels (2560 x 1920), 0.3 megapixels (640 x 480) [4:3]

Simultaneous Recording 13.3 megapixels (4864 x 2736), 8.3 megapixels (3840 x 2160) , 2.1 me-

gapixels (1920x1080) [16:9]

Creating still picture from moti-

on picture

2.1 megapixels (1920 x 1080) [16:9]

Flash Yes

Award

2010-10-01T13:57:00

HDC-SDT750, PC Live!,

Editor's Choice Award,

October 2010

DPOF Max. 999 images

RECORDING SECTION

Signal System 1080 / 50p, 1080 / 50i

Compression (Recording For-

mat)

1080 / 50p : MPEG-4 AVC/H.264 (original format)

HA / HG / HX / HE : MPEG-4 AVC/H.264 (AVCHD standard compliant)

Recording / Playback MODE

Recording / Playback Mode 1080 / 50p (28Mbps / VBR) , (1920 x 1080)

HA (17Mbps / VBR) , (1920 x 1080)

HG (13Mbps / VBR) , (1920 x 1080)

HX (9Mbps / VBR) , (1920 x 1080)

HE (5Mbps / VBR) , (1920 x 1080)

Audio Compression Dolby Digital (5.1ch / 2ch)

Microphone 5.1ch Surround, Zoom and Focus Microphone

Speaker Dynamic type

Media Remaining Indication Yes

INTERFACES

HDMI Yes (mini)

Microphones (stereo mini) Yes

Headphone (stereo mini) Yes

USB 2.0 Hi-Speed

AV multi Yes

OTHERS

Accessory Shoe Yes (Cold)

STANDARD ACCESSORIES

HDMI cable (mini) Yes

3D Conversion Lens (VW-CLT1) Yes

GENERAL

Weight (w/o Battery) approx. 215g ( 0.42lb)

Dimension (W x H x D) 78 x 59 x 97 [mm] ( 3.07 x 2.32 x 3.82 [inch])

LENS SECTION (When attached with the 750 series)

F Value F3.2

Focal Length 2.5mm

35mm Film camera Equivalent 58mm (16:9) [Motion Image]

Minimum Illumination 28 lx (1/25)

STANDARD ACCESSORIES

Lens Front Cap Yes

Lens Rear Cap Yes

Lens Pouch Yes

AC Adaptor Yes

AC Cable Yes

DC Cable Yes

Rechargeable Battery Pack min. 1250 mAh / Lithium-Ion

AV multi Cable Yes

IR Remote Yes

Shoe Adaptor Yes

USB Cable Yes

Included Software HD Writer AE 2.6T

Lens Hood Yes

Stylus pen Yes
