Outdoorchef Camden 480 C User manual

BARBECUE CULTURE – OUTDOORCHEF.COM

CAMDEN 480 C

OUTDOORCHEF.COM

CAMDEN 480 C

2 3

BLID DECKEL

Pos. Art. Nr. Description Beschreibung

B1 18.371.03 Teﬂonwasher U-Scheibe Teﬂon

B2 18.371.02 Washer U-Scheibe

B3 18.370.48 Nut Mutter

OUTDOORCHEF.COM

CAMDEN 480 C

4 5

Front side

5. 6.

1x10

1x17

1x2

OUTDOORCHEF.COM

CAMDEN 480 C

6 7

4 x z

18.370.76

2 x M

18.370.53

4 x d

18.370.63

4 x J

18.370.04

9 x a

18.370.60

2 x h

18.370.67

9 x I

18.370.25

2 x E

18.370.42

2 x r

18.370.73

TO TAKE NOTES

OUTDOORCHEF.COM

CAMDEN 480 C

CAMDEN 480 C | August 2015

SPAREPARTS ERSATZTEIL-LISTE

Pos. Art. Nr. Description Beschreibung

1 18.450.00 Lid handle bakelite Deckelgriff Bakelit

2 18.420.06 Upper Vent Disc with handle Ventilationsschieber oben mit Griff

3 18.430.00 Lid black Deckel schwarz

4 18.850.21 Heat indicator °C/°F Temperatur Anzeige °C/°F

5 18.850.12 Heat indicator-Nut Temperaturanzeige-Befestigungsmutter

6 18.822.49 Logo plate Logoplatte

7 18.420.41 Cooking grid Grillrost

8 18.420.20 Charcoal grate Kohlenrost

9 18.420.01 Bowl black Kugel schwarz

10 18.420.05 Tool holder Besteck Halter

11 18.420.15 Carry handle jetblack Handgriff jetblack

12 18.420.10 Leg upper part front jetblack Bein Oberhälfte vorne jetblack

13 18.420.13 Leg lower part front jetblack Bein Unterhälfte vorne jetblack

14 18.450.01 End cap Abschlusskappe

15 18.420.09 Legs upper part rear jetblack Bein Oberhälfte hinten jetblack

16 18.420.11 Leg lower part rear right jetblack Bein Unterhälfte hinten rechts jetblack

17 18.420.07 Lower vent disc with handle Ventilationsschieber unten mit Griff

18 18.420.08 Ash catcher Aschenschale

19 18.420.14 Stabilisation jetblack Stabilisation jetblack

20 18.420.39 Wheel axle jetblack Radachse jetblack

21 18.420.12 Leg lower part rear left jetblack Bein Unterhälfte hinten links jetblack

22 18.450.02 Wheel Rad

18.379.16 Hardware set Schraubenset

Attention

Please write your serial number on the backside of the manual for future reference. You will ﬁnd the number on the data plate attached to the trolley or the

bottom plate depending on the grill model. OUTDOORCHEF can only supply spare parts and honour warranty returns when the serial number is available.

Achtung

Bitte notieren Sie auf der Rückseite Ihrer Gebrauchsanweisung die Serien-Nummer. Je nach Grillmodell ﬁnden Sie die Nummer auf dem Datensticker, welcher

sich entweder am Grillgestell oder auf der Bodenplatte beﬁndet. OUTDOORCHEF kann Garantie und Ersatzteillieferungen nur mit der Serien-Nummer bearbeiten.

DKB Household Switzerland AG operates a policy of continuous product development and improvement.

As such we reserve the right to alter product design and or technical speciﬁcation without giving any prior notice.

Please read the user guide carefully before using your OUTDOORCHEF Charcoal Kettle Barbeque.

Lesen Sie die Bedienungsanleitung sorgfältig durch, bevor Sie Ihren OUTDOORCHEF Holzkohle Kugelgrill in Betrieb nehmen.

OUTDOORCHEF.COM 8
