Outdoor Plus Custom Fire Pit User manual

Specications

Propane Gas Natural Gas

Max. Input BTU/Hr 78,000 78,000

Orice Size 2.5 mm

Manifold Pressure 10” Water Column 7” Water Column

Maximum Gas Supply Pressure 11” Water Column 14” Water Column

Maximum Inlet Supply Pressure 13” Water Column 14” Water Column

Regulator Pre-Set 11” Water Column

The Outdoor Plus ﬁre pits are designed for outdoor use only.

Carbon Monoxide Hazard

This appliance can produce carbon monoxide which has no odor. Using it

in an enclosed space can kill you. Never use this appliance in an enclosed

space such as a camper, tent, car, or home.

WARNING!

The Outdoor Plus

780 East Francis Street, Suite T

Ontario, CA 91761

(909) 786-1642

(909)-874-0146 (fax)

www.theoutdoorplus.com

Speciﬁcations............................................... ii

Safety Instructions........................................... 2

Set-Up .................................................... 4

Placement and Location............................................... 5

Liquid Propane ...................................................... 6

Natural Gas ........................................................ 9

Leak Testing Procedure .............................................. 10

Decorative Glass Placement .......................................... 11

Battery ........................................................... 11

Natural Gas Conversion.............................................. 12

Operating the Fire Pit........................................ 15

Lighting Instructions ................................................ 16

Turning Off Gas .................................................... 17

Cleaning, Maintenance, Storage............................... 18

Replacement Parts.......................................... 20

One Year Limited Warranty ................................... 21

Save these instructions!

Read this before installing or operating your

new Outdoor Plus re pit.

The Outdoor Plus manufactures a wide range of products and models and

specializes in custom fabrication. Although this manual describes features

common to all ﬁre pit models, the examples shown may not necessarily

reﬂect your speciﬁc ﬁre pit conﬁguration.

2Safety Instructions

Safety Instructions

Do not store combustible materials, gasoline and any other ﬂammable vapors and

liquids. A propane gas cylinder not connected for use shall not be stored in the

vicinity of this or any other appliance.

WARNING!

Improper installation, adjustment, alteration, service or maintenance can cause in-

jury or property damage. Read the installation, operating and maintenance instruc-

tions thoroughly before installing or servicing this equipment.

WARNING!

California Proposition 65 Warning: Chemicals known to the State of California to

cause cancer, birth defects or other reproductive harm are found in and/or created

by the combustion of natural gas, propane, butane and other fuels. Always operate

this unit as described in the owner’s manual and in well ventilated areas.

WARNING!

Do not use charcoal or other solid fuel in gas burning appliances.

Do not use your ﬁre pit for cooking. Do not heat any unopened glass or metal con-

tainer of food in the ﬁre pit. Pressure may build up and cause the container to burst,

possibly resulting in serious personal injury or damage to the ﬁre pit.

Never use the ﬁre pit in windy conditions. If used in a consistently windy area a

windbreak will be required. Always adhere to the speciﬁed clearances listed in this

manual.

Never allow clothing or other ﬂammable materials come in contact with any hot

surface until it has fully cooled. Never wear loose ﬁtting or hanging garments while

using your ﬁre pit. Fabric may ignite and result in personal injury.

When handling propane gas line and connectors, do not allow them to come in

contact with any metal surfaces. Do not drop propane connectors.

CAUTION!

Safety Instructions

In the event that a burner goes out, turn burner knobs to the full OFF position and let

it air out. Do not attempt to use the ﬁre pit until the gas has had time to dissipate.

Propane gas source to the ﬁre pit must be regulated. Do not operate if regulator has

been removed. Fire or explosion can occur.

In the event that a burner goes out, turn burner knobs to the full OFF position and let

it air out. Do not attempt to use the ﬁre pit until the gas has had time to dissipate.

Propane gas source to the ﬁre pit must be regulated. Do not operate if regulator has

been removed. Fire or explosion can occur.

In the event that a burner goes out, turn burner knobs to the full OFF position and let

it air out. Do not attempt to use the ﬁre pit until the gas has had time to dissipate.

Propane gas source to the ﬁre pit must be regulated. Do not operate if regulator has

been removed. Fire or explosion can occur.

Keep all electrical supply cords away from the heated areas of the ﬁre pit.

Clothing or other ﬂammable materials should not be hung from the appliance, or

placed on or near the appliance.

When using the ﬁre pit, do not touch the rock, ﬁre screen, or immediate surround-

ings, as these areas become extremely hot and could cause burns.

Do not reach over your ﬁre pit when hot or in use.

Never leave children unattended in the area where the ﬁre pit is being used. Close

supervision of children is necessary when any appliance is used near children. Nev-

er leave the ﬁre pit unattended when in use.

Do not store items of interest to children around or below the ﬁre pit.

Never allow children to sit or stand on any part of the ﬁre pit.

DANGER!

GAS SAFETY

SAFETY

4Set-Up

Set-Up

Setting up for use with liquid propane (LP)

1 Place the ﬁre pit in a desired location page 5

2 Connect the propane tank page 6

3 Perform a leak test page 10

4 Place the decorative stone or decorative ﬁre objects page 11

5 Insert the battery in the igniter

Setting up for use with natural gas (NG)

1 Place the ﬁre pit in a desired location page 5

2 Connect to an NG gas source page 9

3 Convert the oriﬁce to NG page 12

4 Perform a leak test page 10

5 Place the decorative stone or decorative ﬁre objects page 11

6 Insert the battery in the igniter page 11

You are responsible for ensuring that a natural gas line (if required) is

installed and safe for use. We recommend that a licensed contractor

install your ﬁre pit.

Installation must conform to local codes, or in the absence of local codes,

with either the National Fuel Gas Code, ANSI Z223.1 / NFPA54, Natural

Gas and Propane Installation Code, CSA B149.1, or Propane Storage and

Handling Code, B149.2), as applicable.

Set-Up

Placement and Location

Your Outdoor Plus ﬁre pit is designed for outdoor use only.

Never locate this appliance in a building, garage, or any other enclosed

room or under a sealed overhead structure, or in any type of enclosed

area such as a garage, shed, or breezeway. Keep clear of trees and

shrubs.

Do not place ﬁre pit under or near windows or vents that can be opened

into your home.

Maintain sufﬁcient distance as to not overheat any overhead combus-

tible material such as a patio cover.

The area surrounding your ﬁre pit should be kept clean and free from

ﬂammable liquids and other combustible materials such as mops, rags

or brooms, as well as solvents, cleaning ﬂuids, and gasoline.

Do not block the vents located near the base of your ﬁre pit as gas may

build up in case of leak and cause serious damage.

Do not install or operate your ﬁre pit in such a manner that the cross

ventilation openings are blocked. Fresh air must be able to pass though

installed vents to safeguard against residual gas accumulation. Failure

to allow proper ventilation may cause ﬁre or explosion.

Do not locate appliance where it can get excessively wet. Do not use

this appliance if any part has been underwater. Immediately call a quali-

ﬁed service technician to inspect the unit and to replace any part of the

control system and any gas control which has been underwater.

Place your ﬁre pit on a ﬂat and stable surface in an outdoor location such

as a patio deck.

Maintain the following clearances to combustible materials:

Sides and back 48 inches (122 cm) (measured from side)

Top 120 inches (305 cm) (measured from hearth)

6Set-Up

Liquid Propane

Your Outdoor Plus ﬁre pit is built with

a tank enclosure, but is not provided

with a propane tank. You will need to

provide one. The enclosure will ac-

commodate a 2 lb propane tank.

Use these speciﬁcation for purchas-

ing your propane tank:

Specications

The 2 lb propane gas supply cylinder

is constructed and marked in accor-

dance with the speciﬁcations for propane gas cylinders as required by

the U.S. Department of Transportation (DOT) or the CAN/CSA B339, Cyl-

inders, Spheres and Tubes for the Transportation of Dangerous Goods.

Manifold Pressure: For plumbed-in liquid propane installation, use a

regulator.

Supply Pressure: Maximum line pressure for plumbed-in propane is 14”

W.C psi (3.5 kPa). Minimum line pressure for propane is 11” W.C.

Pressure Regulator: The unit must be used with the supplied gas pressure

regulator and hose assembly. The regulator will control and maintain a

uniform gas pressure in the manifold. The burner oriﬁce has been sized

for the gas pressure delivered by the regulator. Replacement pressure

regulator and hose assemblies must be those speciﬁed in this manual.

Cylinder Speciﬁcation: Any propane gas supply cylinder used with this

ﬁre pit must be approximately 12 inches in diameter and 18 inches high.

The maximum fuel capacity is 20 lbs. of propane, or 5 gallons. Full cyl-

inder weight should be approximately 38 lbs. (43.7 lbs. nominal water

capacity.) Always use the cylinder dust cap on the cylinder valve outlet

during transport and when the cylinder is not connected to the ﬁre pit.

The 20 lb propane gas cylinder used must include a collar to protect the

cylinder valve.

Set-Up

Filler Valve: If you do not have an updated ﬁller valve on your exist-

ing propane tank, you will need to purchase one at your local hardware

store, as you will not be allowed to reﬁll the tank at any ﬁlling station.

Transporting Gas Cylinder: Only one cylinder should be transported at

a time. Transport cylinder in an upright and secure manner with control

valve turned off and the dust cap in place.

Connection

The ﬂex line that runs from the igniter to the burner has been connected

at the factory. You will only need to connect the propane line from the

igniter to the propane tank.

When connecting the regulator assembly to the tank valve, hand tighten

the black QCC-1 nut clockwise. DO NOT use a wrench to tighten. See

the image below.

8Set-Up

Location of the Propane Tank

Outdoor Plus ﬁre pits are built with an enclosure that safely holds a 2 lb

propane tank.

Place the propane gas cylinder in the enclosure as shown below.

Table of contents

Other Outdoor Plus Outdoor Fireplace manuals

Outdoor Plus

Outdoor Plus OPT-7224 User manual

Outdoor Plus

Outdoor Plus Sienna User manual

Outdoor Plus

Outdoor Plus PISMO OPT-2448 User manual

Outdoor Plus

Outdoor Plus REGAL OPT-RGL Series User manual

Outdoor Plus

Outdoor Plus EAVES OPT-LBT60 User manual

Outdoor Plus

Outdoor Plus SEDONA OPT-SED48 User manual

Outdoor Plus

Outdoor Plus VISTA User manual

Outdoor Plus

Outdoor Plus DEL MAR User manual

Outdoor Plus

Outdoor Plus FLORENCE User manual

Outdoor Plus

Outdoor Plus MARTILLO User manual

Outdoor Plus

Outdoor Plus OPT-R8424PCR User manual

Outdoor Plus

Outdoor Plus CATALINA User manual

Outdoor Plus

Outdoor Plus JULIUS User manual

Outdoor Plus

Outdoor Plus MERONA TOP-MC4622 User manual

Outdoor Plus

Outdoor Plus CORONADO User manual

Outdoor Plus

Outdoor Plus OLYMPIAN OPT-OLY60 User manual

Outdoor Plus

Outdoor Plus LUNA User manual

Outdoor Plus

Outdoor Plus REDAN User manual

Outdoor Plus

Outdoor Plus BILLOW User manual

Outdoor Plus

Outdoor Plus QUAD OPT-QD36 User manual

Outdoor Plus

Outdoor Plus OPT-R6024PCR User manual

Outdoor Plus

Outdoor Plus OPT-BLW60 User manual

Outdoor Plus

Outdoor Plus ROMA User manual

Outdoor Plus

Outdoor Plus RAMONA SQUARE OPT-RMNSQ36 User manual

Popular Outdoor Fireplace manuals by other brands

Legacy

Legacy Fire Pit owner's manual

Coleman

Coleman 5055-710 Assembly and instruction sheet

Uniflame

Uniflame GAD1348HN owner's manual

Jensen

Jensen 300NG owner's manual

FEUERHAND

FEUERHAND PYRON user manual

Firegear

Firegear KWB-NG1 Owners & installation manual

Classics

Classics FP35077 manual

Jensen

Jensen 1590LP owner's manual

Mayer Barbecue

Mayer Barbecue HEIZA MFK-220 Assembly instructions

Costway

Costway NP11018 Assembly instructions

Target

Target Foxborough Assembly instructions

Blumfeldt

Blumfeldt Merano manual

Blooma

Blooma Brasero Ulong manual

The Fireplace

The Fireplace JETMASTER 700 D installation instructions

Superior

Superior VRE4543EN Installation and operation instructions

Morsø

Morsø Forno manual

dobar

dobar CONICO 35439E owner's manual

EAST OAK

EAST OAK GFT22001 owner's manual
