OSEE AURORA1600-4K User manual
AURORA1600-4K
Multi-image Processor
User Manual
Product Information
Model: AURORA1600-4K Multi-image Processor
Version: V010002
Release Date: February 15th, 2022
Company
OSEE TECHNOLOGY LTD.
Customer Support
Address: No.22 Building, No.68 zone, Beiqing Road, Haidian District,
Beijing, China
Post Code: 100094
Tel: (+86) 010-62434168
Fax: (+86) 010-62434169
Web: http://www.osee-dig.com
E-mail: sales@osee-dig.com
About this manual
Important
The following symbols are used in this manual:
The further information or know-how for described subjects above which
helps user to understand them better.
The safety matters or operations that user must pay attention to when using
this product.
Contents
The user manual applies to the following device types:
❖AURORA1600-4K-16
❖AURORA1600-3G-16
The images of AURORA1600-4K-16 adopted in the following descriptions, and
AURORA1600-4K-16 is called AURORA1600-4K for short in the following
documentary. The basic features and functionalities for AURORA1600-4K-16
and AURORA1600-3G-16 are almost the same. Any of the different
specifications between the device types are elaborated. Before reading the
manual, please confirm the device type.
Contents
Contents ..........................................................................................................I
Chapter 1 Product Overview.........................................................................1
Chapter 2 Safety.............................................................................................5
Chapter 3 Unpack and Installation...............................................................7
Chapter 4 AURORA1600-4K Features........................................................11
4.1 Front Panel Features ........................................................................11
4.2 Rear Panel Features..........................................................................11
4.2.1 Arrangement of Rear Connectors...................................................11
4.2.2 Operations of Rear Panel...............................................................12
4.2.3 Timing.............................................................................................18
Chapter 5 Specifications.............................................................................21
Product Overview
1
Chapter 1 Product Overview
This article is mainly about AURORA1600-4K, developed by OSEE with high
intelligent, which applied the 1U Multi-image Processor, which performs
multi-channels input signals displayed on one screen for surveillance. It
attaches, switches and zooms the video sources, and provides ideal visual
effect, flexible operation environment and easiness for configuration and
maintenance.
The device has the compact module structure, supports up to 16 channels of
12G/6G/3G/HD/SD-SDI inputs, and up to 4 channels of SDI/SFP outputs, two
HDMI outputs, the resolution is up to 4K. Signals can be appointed to any
output for display freely, and it allows the user easily to set up a display system
in 1U frame with 4 inputs, 8 inputs, 12 inputs or 16 inputs.
The device integrates an internal control software to connect to and configure
the controller. You can configure multi-walls and multi-scene with the input
video sources, and set them at any position and in arbitrary size in the
operating interface of the software. Each video window has adequate
resolution to show very high-quality frame effects. The software is a
WYSIWYG editor and easy to use.
The 1U Multi-image Processor and its inner control software compose the
Multi-image system, and it is widely used in studio, transmission control rooms,
video conference center, general control center, TV Stations and so on.
Figure 1-1 Module of 1U Multi-image Processor
Module
Input
Output
AURORA1600-4K-16
16 channelsSDI video input
16 channels analog audio input
4 channels SDI output
4 channels SFP output
2 channels HDMI output
1-channel audio output
AURORA1600-3G-16
16 channelsSDI video input
16 channels analog audio input
4 channels SDI output
4 channels SFP output
2 channels HDMI output
1-channel audio output
The appearance of AURORA1600-3G-16 is exactly as same as AURORA1600-4k-16’s.
The 12G resolution for SDI inputs (SDI IN1~16) are only available for AURORA1600-4K-16 device.
AURORA1600-4K-16 supports 12G/6G/3G/HD/SD-SDI adaptable video input, whilst
AURORA1600-3G-16 supports 6G/3G/HD/SD-SDI.
Product Overview
2
1U Multi-image Processor supports the following features:
Features
◼Using professional case for high reliability
◼Using 1U compact module structure
◼The window of a video source can be moved from one screen to
another screen in real time
◼Support the general video formats and the inputs are adaptive
◼Support up to 4K through one single output interface
◼Support up to 16 displays in a single screen
◼Support up to 4K resolution through four combined output interfaces
per 50/60 frame rate
◼All modules are redundant designed, and support online replacement
◼Signals can be appointed to any output for display flexibly
◼Support dual power supply. It is usually load balanced when the power
supply is normal, and once there is a fault in power supply, it will power
on the redundant power to keep persistent
◼Provide Video/Audio detection and alarming: video loss, video black,
and audio loss
◼Provide various detections on modules, temperature and power supply
Functionality
◼Support dual UMD, dual TALLY, and up to 4 channels of UV audio
meter, and support dynamic TSL protocol
◼Support several timing methods: LTC timing, native network timing,
manual timing
◼Support AFD information display and Network control
◼Support several types of timers: analog clock timer, digital clock timer,
countdown timer, and digital data timer.
◼Support various operation methods: web control and computer control
Topology Chart
The topology chart for this unit is shown as in Figure 1-2:
4
