Original BTC Hatton 4 User manual

Hatton 4

Instruction Manual

Floor Light

MADE IN BRITAIN

ORIGINALBTC.COM

+44 (0)1993 882 251

UNIT 21 / 22 AVENUE ONE, STATION LANE, WITNEY, OX28 4XZ, ENGLAND

Established in 1990, Original BTC manufactures relaxed, familiar lighting for traditional and

contemporary homes.

All products are hand-assembled in Oxford from high quality components, produced in the UK.

Hatton 4 Floor Light

FF567

230V ac 50Hz IP20

* Warm white (2700k) low energy lamps recommended.

** Wattage value provided as a guide to suitable lamps. Lower wattage than stated may be used.

Safety Instructions

Cleaning and Maintenance

These instructions are provided for your safety in order to prevent the risk of Fire, Electric shock or

Injury. Please retain for future reference. When fitting is in operation, some parts will become hot;

take care when using/handling.

- Ensure the lamp type and max wattage is followed- do not exceed. Take care not to overtighten

lamp.

- Do not touch the lamp (bulb) or lamp holder while in operation, as both become very hot.

- Turn off and unplug fitting, leaving lamp to cool before changing lamp. Dispose of old lamps

carefully.

- Adjust light fitting only when power to the fitting is off and has been left to cool.

- Never leave a fitting without a lamp in position.

- Keep light fitting away from combustible materials such as soft furnishings.

- Ensure children do not play with the light fitting.

- Ensure the light is positioned on a solid, level and non-slip surface and make sure the position of

the cable does not pose a trip hazard.

- If the electrical flex or electrical components become damaged at any point, the fitting must be

unplugged from the power supply immediately and not operated until the damaged parts are

fixed/replaced.

- For use in a dry, indoor environment only. Ensure the fitting does not come into contact with any

liquids.

Metal finishes should only be cleaned with a soft, dry cloth. Do not use polishes or abrasives. Bone

china can be cleaned by hand, using a soft damp cloth with a diluted mild detergent (nonabrasive) if

necessary. Switch off power to the fitting before cleaning.

A unique style floor light with a beautiful multi faceted bone china shade. The Hatton’s chrome base

and black cotton braided cable provide a contemporary and authentic edge.

E27 GLS BALL

LAMP GUIDANCE

TYPE* WATTAGE**

BASE SHAPE

INCANDESCENT

CFL

ECO-HALOGEN

LED

100W MAX

18W

70W

12W

When handling the light, always support from below - do not lift from the shade.

Lamp assembly

Finial

Locator disc

1. Insert the bulb into the

lampholder. If using a tall bulb,

the shade holder can be moved

upwards if necessary by rotating

the shade rings.

2. Unscrew the knurled finial and

locator disc from the top of the

shade holder

3. Locate the shade over the

threaded top of the shade holder

4. Position the locator disc on top

of the shade and gently screw

down the finial onto the shade

holder

Shade

Shade holder

bulb

shade rings
