Operating Your Wine Cellar
IMPORTANT: Do not plug in the wine cellar for at least 24 hours after unit is set in place.
Failure to do so may result in the unit working improperly.
Two-Compartment Design
The FSW36 has two separate compartments, each having a capacity of 18 bottles. Each com-
partment has its own door and separate control panel. This design feature enables you to
operate one or both compartments and also enables you to set a different temperature for
each compartment. Each control panel also displays the current temperature and allows you
to turn the interior lights on and off independently of each other. The operating instructions
below apply to both compartments and must be implemented separately.
OPERATING INSTRUCTIONS
Turning on the Unit
The wine cellar turns on automatically when it is plugged in.
If you want to use the Automatic Temperature (default) setting, do nothing further. The unit will
automatically set the temperature in the compartment at 55 degrees Fahrenheit (13 degrees
Celsius). If you want to set another temperature, see below.
Temperature Setting
Wine Storage Temperatures: While wines store best at temperatures around 56-58 degrees
Fahrenheit, your unit also allows you to store wine at drinking temperatures. Generally RED
WINE should be kept at 60-62 degrees Fahrenheit and WHITE WINE, which is usually served
chilled, should be kept at 54-55 degrees Fahrenheit.
To adjust the temperature, press the SET button, then use the UP/ DOWN keys to navigate to
the preferred temperature. For example, if you are storing red wine, you may want to set a
temperature of 61 degrees Fahrenheit.
When the correct temperature appears in the DISPLAY Window of the Control Panel, press
SET to confirm. Remember that each compartment has separate controls so you will need to
set the temperature in both compartments separately.
Please note: Cold air falls and warmer air rises, and there will be a small temperature varia-
tion from the bottom of the unit to the top. The temperature gauge is located in the middle of
the unit and records the temperature at the middle of the unit. The temperature at the bottom
of the unit will always be slightly colder.
Drip Trays
Packed with the unit are two small plastic trays. They should be placed at the back of each
compartment, on the shelf just above the tilted rack. These trays will catch any water that
condenses on the walls of the compartments, and also help maintain the proper humidity level
so that corks will not dry out. Every month or so, they should be checked and emptied if nec-
essary. 5
