SERVICE MANUAL
SI : TSE: Check: Approved:
Date Revise Version Description
2008/2/3
V1.0 Initial Issue
HD71/HD710/HD75
Copyright February.2008. All Rights Reserved P/N: 36.8AE03G001
95.8AE01G00A ; 95.8AE01G019 ; 95.8AE01G001; 95.8AE01GC0A ; 95.8AE01GC0B ;
95.8AE01GC0C ; 95.8AE01GC0H ;95.8AE01GC0J ; 95.8AE01GC0L; 95.8AE01GC0T ;
95.8AE01GC1A ; 95.8AE02G019 ; 95.8AE02GC0E ; 95.8AE02GC0K
Corrine
HD71/HD710/HD75 Condential
II
HD71/HD710/HD75 Comparison List
HD75 HD71/HD710
DC.8AE02G001 D.C. HD710 DC.8AE01G001 D.C. HD71
70.8AE10G001
ASSY TYPE A ENGINE
MODULE HD71 70.8AE01G001
ASSY TYPE A ENGINE
MODULE HD71
70.8AE12G001
ASSY COLOR WHEEL
MODULE OERLIK 70.86V31G001
ASSY COLOR WHEEL
MODULE OERLIK
23.8AE19G021
COLOR WHEEL
R62G95B53R62Y35B53 23.87U19G011
COLORWHEEL
R90Y28G90C28W42B82,
70.8AE17G001
ASSY LAMP DRIVER
OSRAM 230W HD 70.87K04G001
ASSY LAMP DRIVER
OSRAM 230W EP
70.8AE15G001
OSRAM O3 MID 200W
LAMP DRIVER 70.87U06G001
OSRAM O3 MID 200W
LAMP DRIVER
39.8AE03G002
OSRAM RGBRYB 2X ,3x_
PAL WAVEFO 39.87J03G001
OSRAM 6S W42
WAVEFORM
70.8AE13G001 ASSY MB PCBA HD710 70.8AE02G001 ASSY MB PCBA HD71
80.8AE01G011
PCBA MAIN BD1 ENTEK
FOR HD710 80.8AE01G002
PCBA MAIN BD1 ENTEK
FOR HD71
HD71/HD710/HD75 Condential
III
Preface
This manual is applied to HD71/HD710/HD75 projection system. The manual gives you a
brief description of basic technical information to help in service and maintain the product.
Your customers will appreciate the quick response time when you immediately identify
problems that occur with our products. We expect your customers will appreciate the
service that you offer them.
This manual is for technicians and people who have an electronic background. Please
send the product back to the distributor for repairing and do not attempt to do anything that
is complex or is not mentioned in the troubleshooting.
Notice:
The information found in this manual is subject to change without prior notice. Any
subsequent changes made to the data herein will be incorporated in future edition.
HD71/HD710/HD75 Service Manual
Copyright February.2008
All Rights Reserved
Manual Version 1.0
HD71/HD710/HD75 Condential
IV
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-2
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Top Cover 2-2
Disassemble Keypad Board,Keypad and FPC Cable 2-3
Disassemble Lamp Module 2-4
Disassemble I/O Cover 2-4
Disassemble Top Shielding 2-5
Disassemble Main Board Module,Audio Board Moudle and
Component Module 2-6
Disassemble Left Cover and Right Cover 2-7
Disassemble Fan Module 2-8
Disassemble LVPS Module 2-9
Disassemble Engine Module 2-10
Disassemble Thermal Switch,Blow Duct Rubber 2-11
Disassemble Color Wheel and Photo Sensor Board 2-12
Disassemble DMD Chip and DMD Board 2-13
Disassemble Zoom Ring 2-14
Disassemble Focus Ring 2-15
Disassemble ROD Module 2-16
Disassemble Blower Module 2-17
Disassemble Limit Switch 2-18
HD71/HD710/HD75 Condential
V
Disassemble Engine Mask Plat and Lamp Driver 2-19
Disassemble System Support Shielding Module 2-20
Disassemble Speaker 2-21
Disassemble Lens Case,Lens Door,Lens Door Switch 2-22
Disassemble IR Board,IR Lens 2-23
Chapter 3 Troubleshooting
LED Lighting Message 3-1
Main Procedure 3-2
Chapter 4 Function Test & Alignment Procedure
Test Equipment Needed 4-1
Service Mode 4-1
OSD Reset 4-1
Test Condition 4-2
Test Inspection Procedure
4-4
PC Mode
4-4
Video Performance
4-8
Optical Performance Measure
4-10
Others4-11
Chapter 5 Firmware Upgrade
Equipment Needed 5-1
DLP Composer Lite Setup Procedure 5-2
USB Driver Upgrade Procedure 5-4
Firmware Upgrade Procedure 5-5
Chapter 6 EDID Upgrade
EDID Introduction 6-1
Equipment Needed 6-2
HD71/HD710/HD75 Condential V
Setup Procedure 6-3
EDID Key-In Procedure 6-3
Appendix A Exploded Overview I
Appendix B Serial Number System Denition XX
PCBA Code Denition XXI
HD71/HD710/HD75 Condential 1-1
Chapter 1
Introduction
1-1 Highlight
No Item Description
1Dimension (WxDxH) - 295x222x95.7mm
2 Weight - 6.5lbs Max
3Power Supply - Input 100-240V, 50-60 Hz
4 Resolution - Native resolution 1280x720
5Brightness
- 2000 lumens (typical) ( HD71/HD710)
- 1750 lumens (minimum) (HD71/HD710)
- 1100 lumens (typical) (HD75)
- 990 lumens (minimum) (HD75)
6 Contrast - 1800:1 full on/off (typical)
- 1300:1 full on/off (minimum)
7Uniformity - Typical : 80%
- Minimum : 65%
8 Throw ratio - 1.55 ~1.70:1 distance/width
9 Lamp life
- 100% Power 1500 hrs,50% survival rate with 50% lumen
maintenance
- 85% Power 2000 hrs,50% survival rate with 50% lumen
maintenance
10 Color wheel
- 6 segments R90G90B82C28Y28W42 3x speed (HD71/
HD710)
- 6 segments R62G95B53R62Y35B53 2x speed (HD75)
11 Lamp - OSRAM 200W Lamp
HD71/HD710/HD75 Condential
1-2
No Item Description
12 Temperature
- Operating: 5-35 °C, 80% humidity
- Storage: -20 - 60 °C, 80% humidity
- Altitude: 5-35°C @ 0 - 2,500 ft
5-30°C @ 2,500 - 5,000 ft
5-25°C @ 5,000 - 10,000 ft
- Maximum storage altitude 40,000 ft
13 Video compatibility
- NTSC NTSC M/J, NTSC 4.43
- PAL PAL B/D/I/G/H, PAL M, PAL N
- SECAM SECAM B/D/G/K/L
- SDTV 480i, 480p, 576i, 576p
- HDTV 720p 50\60Hz, 1080i 50\60Hz,
1080p 24\50\60H
14 I/O
- HDMI 1.3 x1
- YPbPr (RCA) x1 Must Have 3 x RCA component input
- D-sub RGB x1
- DVI-D w/HDCP x1
- Composite x1
- S-video x1
- USB x1 (For quick FW upgrade)
- RS232 (3pin) x1
- 12 Volt Trigger x1
- Audio Input 3.5mm stereo jack socket x3 (1 audio in for
composite & svideo,1 audio in for VGA & DVI and 1 audio in
for component)
HD71/HD710/HD75 Condential 1-3
1-2 Compatible Mode
Analog
Compatibility Resolution V-Sync [Hz]
VGA
640x480 60
848x480 60
720x400 70
SVGA 800x600 56
800x600 60
XGA
1024x768 50
1024x768 60
1024x768 70
WXGA
1280x768 50
1280x768 60
1280x768 70
HD
1280x720 50
1280x720 60
1920x1080 50
1920x1080 60
SXGA
1280x1024 50
1280x1024 60
1280x1024 70
SXGA+ 1400x1050 60
MAC 1152x870 75.06
MAC G4 640x480 60
i Mac DV 1024x768 75
HD71/HD710/HD75 Condential 1-4
Digital
Compatibility Resolution V-Sync [Hz]
SVGA
800x600 60
800x600 72
800x600 75
848x480 60
XGA
1024x768 50
1024x768 60
1024x768 70
1024x768 75
Wide
1280x720 24
1280x720 50
1280x720 60
1920x1080 24
1920x1080 50
1920x1080 60
