Optoma GT2000HDR User manual
DLP®Projector
User manual
English
2
TABLE OF CONTENTS
SAFETY............................................................................................... 4
Important Safety Instruction....................................................................................................... 4
Laser Radiation Safety Information ........................................................................................... 5
Copyright ................................................................................................................................... 7
Disclaimer.................................................................................................................................. 7
Trademark Recognition ............................................................................................................. 7
FCC ........................................................................................................................................... 7
Declaration of Conformity for EU countries ............................................................................... 8
WEEE........................................................................................................................................ 8
Cleaning the Lens...................................................................................................................... 8
INTRODUCTION ................................................................................ 9
Package Overview..................................................................................................................... 9
Standard accessories................................................................................................................ 9
Product Overview ..................................................................................................................... 10
Connections.............................................................................................................................. 11
Keypad ..................................................................................................................................... 12
Remote control ......................................................................................................................... 13
SETUP AND INSTALLATION........................................................... 14
Installing the projector .............................................................................................................. 14
Connecting sources to the projector......................................................................................... 16
Adjusting the projector image................................................................................................... 17
Remote setup ........................................................................................................................... 19
USING THE PROJECTOR ............................................................... 21
Powering on / o the projector.................................................................................................. 21
Selecting an input source ......................................................................................................... 22
Menu navigation and features .................................................................................................. 23
OSD Menu tree......................................................................................................................... 24
Image picture mode menu........................................................................................................ 30
Image dynamic range menu..................................................................................................... 30
Image brightness menu............................................................................................................ 30
Image contrast menu................................................................................................................ 31
Image sharpness menu............................................................................................................ 31
Image gamma menu................................................................................................................. 31
Image color settings menu ....................................................................................................... 31
Image wall color menu.............................................................................................................. 31
Image 3D menu........................................................................................................................ 32
Image reset menu..................................................................................................................... 32
Display projection orientation menu ......................................................................................... 33
Display light source mode menu .............................................................................................. 33
Display dynamic black menu.................................................................................................... 33
English 3
Display gaming mode menu..................................................................................................... 33
Display screen type menu ........................................................................................................ 33
Display aspect ratio menu ........................................................................................................ 34
Display geometric correction menu .......................................................................................... 37
Display digital zoom menu........................................................................................................ 37
Display image shift menu ......................................................................................................... 37
Display reset menu................................................................................................................... 37
Setup test pattern menu ........................................................................................................... 38
Setup language menu .............................................................................................................. 38
Setup menu settings menu....................................................................................................... 38
Setup high altitude menu.......................................................................................................... 38
Setup lter settings menu......................................................................................................... 38
Setup power settings menu...................................................................................................... 39
Setup security menu................................................................................................................. 39
Setup keypad settings menu .................................................................................................... 39
Setup startup logo menu .......................................................................................................... 40
Setup background color menu.................................................................................................. 40
Setup device reset menu.......................................................................................................... 40
Input auto source menu............................................................................................................ 41
Input auto input switch menu.................................................................................................... 41
Input HDMI CEC settings menu ............................................................................................... 41
Input reset menu....................................................................................................................... 41
Audio volume menu.................................................................................................................. 42
Audio mute menu ..................................................................................................................... 42
Audio reset menu ..................................................................................................................... 42
Control device ID menu............................................................................................................ 43
Control remote settings menu .................................................................................................. 43
Control keypad settings menu.................................................................................................. 43
Control LAN menu.................................................................................................................... 43
Control control menu ................................................................................................................ 45
Setup network control settings menu ....................................................................................... 46
Control reset menu................................................................................................................... 53
Information menu...................................................................................................................... 54
ADDITIONAL INFORMATION.......................................................... 55
Compatible resolutions............................................................................................................. 55
Image size and projection distance .......................................................................................... 59
Projector dimensions and ceiling mount installation................................................................. 63
IR remote control codes ........................................................................................................... 65
Troubleshooting ........................................................................................................................ 67
Warning indicators.................................................................................................................... 69
Specications ........................................................................................................................... 70
Optoma global oces............................................................................................................... 72
English
4
SAFETY
The lightning ash with arrow head within an equilateral triangle is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be of sucient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
Please follow all warnings, precautions and maintenance as recommended in this user’s guide.
Important Safety Instruction
• Do not block any ventilation openings. To ensure reliable operation of the projector and to protect from
over heating, it is recommended to install the projector in a location that does not block ventilation.
As an example, do not place the projector on a crowded coee table, sofa, bed, etc. Do not put the
projector in an enclosure such as a book case or a cabinet that restricts air ow.
• To reduce the risk of re and/or electric shock, do not expose the projector to rain or moisture. Do not
install near heat sources such as radiators, heaters, stoves or any other apparatus such as ampliers
that emits heat.
• Do not let objects or liquids enter the projector. They may touch dangerous voltage points and short
out parts that could result in re or electric shock.
• Do not use under the following conditions:
± In extremely hot, cold or humid environments.
(i) Ensure that the ambient room temperature is within 0°C ~ 40°C
(ii) Relative humidity is up to 80%
± In areas susceptible to excessive dust and dirt.
± Near any appliance generating a strong magnetic eld.
± In direct sunlight.
• Do not use the unit if it has been physically damaged or abused. Physical damage/abuse would be
(but not limited to):
± Unit has been dropped.
± Power supply cord or plug has been damaged.
± Liquid has been spilled on to the projector.
± Projector has been exposed to rain or moisture.
± Something has fallen in the projector or something is loose inside.
• Do not place the projector on an unstable surface. The projector may fall over resulting in injury or the
projector may become damaged.
• Do not block the light coming out of the projector lens when in operation. The light will heat the object
and may melt, cause burns or start a re.
• Please do not open or disassemble the projector as this may cause electric shock.
• Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous
voltages or other hazards. Please call Optoma before you send the unit for repair.
• See projector enclosure for safety related markings.
• The unit should only be repaired by authorized service personnel.
• Only use attachments/accessories specied by the manufacturer.
• Do not look into straight into the projector lens during operation. The bright light may harm your eyes.
• This projector will detect the life of the light source itself.
English 5
• When switching the projector o, please ensure the cooling cycle has been completed before
disconnecting power. Allow 90 seconds for the projector to cool down.
• Turn o and unplug the power plug from the AC outlet before cleaning the product.
• Use a soft dry cloth with mild detergent to clean the display housing. Do not use abrasive cleaners,
waxes or solvents to clean the unit.
• Disconnect the power plug from AC outlet if the product is not being used for a long period of time.
• Do not setup the projector in places where it might be subjected to vibration or shock.
• Do not touch the lens with bare hands.
• Remove battery/batteries from remote control before storage. If the battery/batteries are left in the
remote for long periods, they may leak.
• Do not use or store the projector in places where smoke from oil or cigarettes may be present, as it
can adversely aect the quality of the projector performance.
• Please follow the correct projector orientation installation as non standard installation may aect the
projector performance.
• Use a power strip and or surge protector. As power outages and brown-outs can KILL devices.
Laser Radiation Safety Information
• This product is classied as CLASS 1 LASER PRODUCT - RISK GROUP 2 of IEC60825-1 : 2014 and
also complies with 21 CFR 1040.10 and 1040.11 as a Risk Group 2, LIP (Laser Illuminated Projector)
as dened in IEC 62471:5:Ed. 1.0. For more information see Laser Notice No. 57, dated May 8, 2019.
• As with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015.
• This projector is class 1 laser product of IEC/EN 60825-1:2014 and risk group 2 with the requirements
of IEC 62471-5:2015.
• Supervise children: no staring, and avoid use of optical aids!
• Notice is given to supervise children and to never allow them to stare into the projector beam at any
distance from the projector.
• Notice is given to use caution when using the remote control for starting the projector while in front of
the projection lens.
• Notice is given to the user to avoid the use of optical aids such as binoculars or telescopes inside the
beam.
• When turning on the projector, make sure no one within projection range is looking at the lens.
English
6
• Keep any items (magnifying glass etc.) out of the light path of the projector. The light path being
projected from the lens is extensive, therefore any kind of abnormal objects that can redirect light
coming out of the lens, can cause an unpredictable outcome such as a re or injury to the eyes.
• Any operation or adjustment not specically instructed by the user’s guide creates the risk of
hazardous laser radiation exposure.
• Do not open or disassemble the projector as this may cause damage by the exposure of laser
radiation.
• Do not stare into beam when the projector is on. The bright light may result in permanent eye damage.
Not following the control, adjustment or operation procedure may cause damage by the the exposure of laser
radiation.
English 7
Copyright
This publication, including all photographs, illustrations and software, is protected under international copyright
laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced
without written consent of the author.
© Copyright 2022
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no representations
or warranties with respect to the contents hereof and specically disclaims any implied warranties of
merchantability or tness for any particular purpose. The manufacturer reserves the right to revise this publication
and to make changes from time to time in the content hereof without obligation of the manufacturer to notify any
person of such revision or changes.
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations and pending
applications in other countries throughout the world.
HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
DLP®, DLP Link and the DLP logo are registered trademarks of Texas Instruments and BrilliantColorTM is a
trademark of Texas Instruments.
All other product names used in this manual are the properties of their respective owners and are Acknowledged.
FCC
This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15
of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this device does cause
harmful interference to radio or television reception, which can be determined by turning the device o and on is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the device and receiver.
• Connect the device into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables to maintain compliance with FCC
regulations.
Caution
Changes or modications not expressly approved by the manufacturer could void the user's authority, which is
granted by the Federal Communications Commission, to operate this projector.
English
8
Operation Conditions
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference and
2. This device must accept any interference received, including interference that may cause undesired operation.
Notice: Canadian users
This Class B digital apparatus complies with Canadian ICES-003.
Remarque à l'intention des utilisateurs canadiens
Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.
Declaration of Conformity for EU countries
• EMC Directive 2014/30/EU (including amendments)
• Low Voltage Directive 2014/35/EU
• RED 2014/53/EU (if product has RF function)
WEEE
Disposal instructions
Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure
utmost protection of the global environment, please recycle it.
Cleaning the Lens
• Before cleaning the lens, be sure to turn o the projector and unplug the power cord to allow it to
completely cool down.
• Use a compressed air tank to remove the dust.
• Use a special cloth for cleaning lens and gently wipe the lens. Do not touch the lens with your ngers.
• Do not use alkaline/acid detergents or volatile solvents such as alcohol for cleaning lens. If the lens is
damaged due to the cleaning process, it is not covered by the warranty.
Warning: Do not use a spray containing ammable gases to remove dust or dirt from the lens. This
may cause a re due to excessive heat inside the projector.
Warning: Do not clean the lens if the projector is warming up as this may cause the lens’ surface lm
to peel o.
Warning: Do not wipe or tap the lens with a hard object.
To avoid electric shock, the unit and its peripherals must be properly grounded (earthed).
English 9
INTRODUCTION
Thank you for purchasing an Optoma laser projector. For full list of features please visit the product page on our
website, where you will also nd additional information and documentation such as FAQs.
Package Overview
Carefully unpack and verify that you have the items listed below under standard accessories. Some of the items
under optional accessories may not be available depending on the model, specication and your region of
purchase. Please check with your place of purchase. Some accessories may vary from region to region.
The warranty card is only supplied in some specic regions. Please consult your dealer for detailed information.
Standard accessories
Projector Remote control Power cable
Documentation
Quick start user manual
Power adapter
Note:
•For access to the setup information, user manual, warranty information, and product updates
– please scan the QR Code or visit the following URL:
https://www.optoma.com/support/download
English
10
INTRODUCTION
Product Overview
1080p 1.3x/1080p 1.6x model
3
888 11
4
7
97
10
2 51 6
XGA/WXGA/1080p Short Throw/1080p Short Throw w/o network model
3
888 11 7
97
10
2 51 6
Note:
•Do not block projector intake and exhaust vents.
•When operating the projector in an enclosed space, allow at least 30 cm clearance around the intake
and exhaust vents.
•The 1080p Short Throw w/o network model does not support LAN connector.
No Item No Item
1. IR Receivers 7. Ventilation (inlet)
2. Keypad 8. Tilt-Adjustment Feet
3. Zoom Lever 9. Kensington™ Lock Port
4. Focus Ring 10. Input / Output
5. Ventilation (outlet) 11. Lens
6. DC Jack
Table of contents
Other Optoma Projector manuals
Optoma
Optoma Optoma EX525ST User manual
Optoma
Optoma 2788 User manual
Optoma
Optoma X400LVe User manual
Optoma
Optoma TX763 User manual
Optoma
Optoma Pico PK120 User manual
Optoma
Optoma EP716R User manual
Optoma
Optoma EX765W User manual
Optoma
Optoma TX615-3D User manual
Optoma
Optoma W415-M User manual
Optoma
Optoma ES550 User manual
Optoma
Optoma EX631 User manual
Optoma
Optoma HD7300 User manual
Optoma
Optoma EX685UT User manual
Optoma
Optoma Optoma EP747 User manual
Optoma
Optoma GT1080e User manual
Optoma
Optoma TX700 User manual
Optoma
Optoma OMA-S User manual
Optoma
Optoma WVGA single chip DLP User manual
Optoma
Optoma TX7000 User manual
Optoma
Optoma EP753 User manual
