One Forall Topline User manual

Retain For Future Reference

Topline

USER GUIDE & CODE BOOK

Universal Remote Control

URC-5550

BASIC FUNCTIONS

ABOUT YOUR Topline 5…

INSTALLING THE BATTERIES…

FEATURES AND FUNCTIONS…

LANGUAGE SELECTION…

SETTING THE CLOCK…

SETTING UP YOUR DEVICES…

Setting Up Your TV…

Setting Up Your Other Devices…

Searching For Your Code

Recording Your Codes...

REASSIGNING THE DEVICE KEYS…

THE SCAN KEY…

TELETEXT & FASTEXT…

ADVANCED FUNCTIONS

SEQUENCES…

Power Sequence…

Installing Other Sequences…

Deleting a Sequence…

TIMED SEQUENCES…

Recording When Your Not Home…

Deleting a Timed Sequence…

THE SHIFT KEY…

Shifted Functions

Sleeptimer…

VOLUME LOCK...

CHANNEL +/- SIMULATION...

CLEAR ALL...

TROUBLE SHOOTING...

CUSTOMER SERVICE…

Product Support…

Key Magic…

Telephone Upgrade…

SET-UP CODES

Televisions

Video Recorders

Satellite Receivers

Cable Converters

Video Accessories

CD Players

Miscellaneous Audio

Home Automation

Audio Amplifiers

Tuners

Table of Contents

Thank you for purchasing the ONE FOR ALL Topline 5 Home Theater

Universal Remote Control. Your Topline 5 package contains:

• Your Topline 5 remote control

• Your Topline 5 manual

Your User Guide & Codebook is divided into three parts: Basic Functions,

Advanced Functions and Set-Up Codes. You may need this guide again in the

future, so please be sure to keep it.

Your Topline 5 needs four new AAA/LRO3 Akalines batteries.

Your ONE FOR ALL Topline 5 is designed to let you use one remote to

operate 5 Devices: any combination of Television, Videos, Satellites, Cable

Converters, CD Players, Amplifiers and Tuners. This also includes those

devices wich operate over 100kHz. You can choose any combination of 5

devices you would like to operate.

Also, what makes the Topline 5 even more unique is it includes “Timed

Sequences” which allows you to initate a sequence of key presses at a

specific time - a feature which is great for video programming, for example.

The following pages explain in simple steps how to set up the Topline 5 and

customize it for your home entertainment environment.

About your Topline 5

Your Topline 5 requires four (4) new alkaline AAA/LRO3 batteries. To install

the batteries:

Remove the battery cover by pressing down on the

bottom portion and sliding the cover off.

Match the batteries to the + and - marks inside the

battery case, then insert the batteries.

Slide the battery cover back into place.

Once the batteries are inserted all the segments in the display screen will

show. If the display screen is blank or if the screen reads [BATTERY LO], the

batteries are running low and you must replace them with fresh batteries to

ensure proper functioning. The Topline 5’s internal back-up batteries ensure

that programming information is not lost if the batteries are changed;

however, you will need to reset the clock upon changing batteries.

Installing the Batteries

Basic Features

Device

Keys

TV/VCR

Magic

Volume

Scan

Channel

Menu Keys

Stop

Pause

Slow

Play Fast Forward

Record

Rewind

Number

Keys

Power

ESC

Lite

Enter

Shift

Mute

LCD

Teletext

Fastext

FEATURES AND FUNCTIONS

Key Function

The LCD screen guides you through setting up and

operating your home entertainment equipment.

Device Keys

The TV, VCR, SAT, CD and AUX keys select the device to be

controlled. For example, pressing the TV key allows the

remote to control the functions of your Television, after

pressing VCR you can operate your Video, etc. For more

detailed information, please see page 10.

Power

The Power key controls the same function it did on your

original remote. When SHIFT is pressed first, this key is

also used to access the Sleeptimer of your device (see page

20).

If available on your orginal remote, these directional keys

are used to access the menu function or programming

guides.

During set-up and programming your Topline 5, the up

and down keys are used to scroll through the LCD

screens.

Magic

The MAGIC key is used to set up your Topline 5 and to

access the menu and special features.

Esc

The Esc (Escape) key is used to exit the LCD screen and go

back to normal operation.

Lite

The LITE key is used to turn On and Off the Topline 5’s

backlit keypad and LCD. Press the LITE key once to turn on

the backlight feature. The backlight will stay on for

approximately ten seconds each time a key is pressed. To

deactivate the backlight, press the LITE key again.

Enter

The Enter Key is used to make selections on the LCD

menu. It is also used to make selections in your on-screen

programming menus.

Shift

The Shift key accesses advanced features which are

located under the following keys: POWER, VOL+/-, CH+/-,

MENU+/-, left, right.

Volume +/-, Channel +/-, Mute

These keys operate just as those on your original remote

control. When SHIFT is pressed first, volume and channel

can be used to control color and brightness (see page 20).

Basic Features

ESC

LITE

ENTER

SHIFT

TV VCR SAT

CD AUX

POWER

POW

MENU+

MENU-

( )

()

MUTE VOL- VOL+

CH- CH+

MAGIC

FEATURES AND FUNCTIONS

Key Function

Number Keys

The Number keys (0-9, 10, 20) provide functions just like

your original remote, such as direct access programme

selection. If your original remote uses one/two digit input

switching (-/-- symbol), this function can be obtained by

pressing the -/-- key, which is the same as the 10 key.

If your original remote used an AV key, this can be found

by pressing the 20 key.

Scan

The Scan key allows you to easily browse through the

programmes on your TV, VCR or Satellite. See page 16 for

more details.

A, B

These keys can be used for programming Sequences. See

page 17 for more detail.

Video Recorder Keys

After pressing VCR, these keys operate the functions of

your VCR. To prevent accidental recording, the Record key

must be pressed twice to start recording.

Teletext/Fastext Keys

After pressing the TV key, the top row of VCR keys are

used to operate the main Teletext functions of your

Television. The symbols below the top row of keys are for

Teletext. Of course, your Television must be Teletext

capable. For an explanation of the teletext symbols, please

refer to page 16.

After pressing the TV key, the bottom row of VCR keys

marked red, green, yellow and blue allow you to access

the Fastext functions of your television. Again, your

television must be fastext capable to operate these

functions. For a more detailed explanation of how

Teletext and Fastext work, please refer to the manual of

your Televison.

Also, some devices require you to use the fastext keys to

operate menu control. If so, these keys will function the

same way as on your orginal remote.

Basic Functions

-/--

SCAN

REW

FF PAU

TV/VCR

SLOW

STOP REC

STOP

TV/VCR

REC

SLOW

(red)

(green)

(yellow)

(blue)

LANGUAGE SELECTION

It is possible to choose between three languages for the text which is

displayed on the LCD of the Topline 5. You can chose between English,

French and German. The default setting is English. To change the language

selection, follow the procedure below.

Press and hold the MAGIC key until the display screen

changes from [DEVICE and the TIME] to [TIMED SEQ].

Press MENU- twice, the display will change to

[CONFIGURE]. Press ENTER and the display will change to

[TIME SETUP].

Press MENU+ two times and the display will read

[LANGUAGE]. Press ENTER.

The display will read [ENGLISH]. Use the Menu- key to

cycle through the language choices. When you get to the

desired language, press ENTER. The display will return to

the main screen.

Basic Functions

ENTER

MENU-

MENU+

ENTER

MENU-

Notes:

- If you make a mistake in your selection, press ESC and repeat the

procedure starting with step number 1.

- When you replace the batteries, the language you have selected will

stay programmed.

MAGIC

SETTING THE CLOCK

The Topline 5 comes with both a 24hr clock and a 12hr clock. After installing the

batteries for the first time, the Topline 5 will default to the 24hr clock setting. To

set the clock, follow the procedure below. It is also possible during this

procedure to change to a 12hr clock setting, if desired.

Press and hold the MAGIC key until the display screen

changes from [DEVICE and the TIME] to [TIMED SEQ].

Press MENU- twice, the display will change to

[CONFIGURE]. Press ENTER and the display will change to

[TIME SETUP].

Press ENTER. The display will read [24HR CLOCK]. If this is

the setting you want, press ENTER, OR if you wish to

change to a 12hr clock, press MENU- and the display will

read [12HR CLOCK]. Then press ENTER.

The display will change to [TIME] and the first digit in the

clock will blink. Enter the first digit of the time, then the

next digit will blink. Continue entering the time until all

four digits of the clock have been set.

If you are using a 24hr clock, press ENTER. If you are using

a 12hr clock, the AM/PM will blink. Press MENU- to toggle

between AM and PM. Once this is selected, press ENTER.

The display will then change to the day of the week. Use

the MENU- key to cycle through the days until the proper

day is displayed on the screen, then press ENTER. The

display will return to the main screen [DEVICE and the

TIME] showing the selections you have made.

Basic Functions

Notes:

- If you make a mistake in your selection, press ESC, and repeat the

procedure starting with step number 1.

- When you replace the batteries, you will need to set the clock again.

ENTER

MENU-

ENTER

MENU-

ENTER

MENU-

ENTER

()

MAGIC

SETTING UP YOUR TV

To set up the Topline 5 for your television:

Find your Television code in the Set-Up Code section

(starting on page 28). Codes are listed by brand name. The

most popular code is listed first. Make sure your Television

is switched on; any programme is fine.

Press the TV key, then press and hold the MAGIC key

until the display screen changes from [TV and the TIME] to

[TIMED SEQ].

Press MENU- once, the display will change to [CODE

SETUP]. Press ENTER and the display will change to [DEV

SET UP].

Press ENTER and the display will change to [TV].

Enter your three-digit TV code using the number keys,

then press ENTER.

Aim the Topline 5 at your TV and press POWER. Your

Television should turn off. If your TV turns off, press the

ESC key to return to the main screen [TV and the TIME].

If your TV does not turn off, enter the next code in the

list then press ENTER. Press POWER to see if your TV turns

off. Once your TV turns off, you have found the correct

code. Turn your device back on and try all the remote’s

functions to ensure they are working properly. Press the

ESC key to return to the main screen [TV and the TIME].

Write your code in the three boxes on page 14 for easy future reference.

Basic Functions: Setting Up Your Devices

ENTER

MENU-

ESC

POWER

Her finder du kodern

Admiral 087, 093, 418, 213, 264

Adyson 217, 216

Agazi 264

AGB 516

Agef 087

Aiko 216, 009, 037, 371, 035, 072, 361,

191

Aim 037, 274

Akai 361, 208, 371, 037, 191, 035,

009, 072, 218, 163

Akiba 218, 282, 455, 037

Notes:

- To control your Television, [TV] must be displayed on the screen. This can

be obtained by pressing the TV key.

- To set up more than one device, before pressing the ESC key during step

6, you can press the next device key you want to program and enter the

code for that device.

- If a code is entered which is not in the memory of the Topline 5, the

display will read [NOT FOUND]

- If your TV does not respond, try every code listed for your brand during

step 6. If none of the codes listed operate your TV, try the Search Method

described on page 13, even if your brand is not listed at all.

MAGIC

This manual suits for next models

Table of contents

Other One Forall Universal Remote manuals

One Forall

One Forall URC-7542 User manual

One Forall

One Forall URC-6230 User manual

One Forall

One Forall URC 1810 User manual

One Forall

One Forall KAMELEON 4 User manual

One Forall

One Forall URC-3710 User manual

One Forall

One Forall Zapper URC-6520 User manual

One Forall

One Forall URC 3050 User manual

One Forall

One Forall URC-7530 User manual

One Forall

One Forall 705016 User manual

One Forall

One Forall URC-7711 User manual

One Forall

One Forall DVD EXPERT URC-4041 User manual

One Forall

One Forall Cinema 6+ URC 6800 User manual

One Forall

One Forall URC-7740 User manual

One Forall

One Forall OFA Kameleon URC-6690 User manual

One Forall

One Forall Xsight Colour User manual

One Forall

One Forall URC-3415 User manual

One Forall

One Forall URC10820N User manual

One Forall

One Forall URC-3425 User manual

One Forall

One Forall URC-1312 User manual

One Forall

One Forall URC-6230 User manual

One Forall

One Forall Audio Zapper User manual

One Forall

One Forall KAMELEON URC-8308 User manual

One Forall

One Forall URC6810 User manual

One Forall

One Forall KAMELEON 5 URC-8305 User manual

Popular Universal Remote manuals by other brands

Pronto

Pronto Peel quick start guide

GE 24929 instruction manual

Radio Shack

Radio Shack Wireless Remote Control System owner's manual

AUVIO

AUVIO Universal Home Theater Remote user guide

Philips

Philips Icon SRU4106 Specifications

THOMSON

THOMSON ROC4309 Operating instruction

Philips

Philips pm625S instruction manual

GE RM94931 instruction manual

RCA

RCA RCU600WMS - Universal Remote Control user manual

Blackweb

Blackweb BWB17AV002 user guide

Marmitek

Marmitek DoorGuard 300 user manual

Chunghop

Chunghop RM-L618 user manual

GE RM24965 instruction manual

Anderic

Anderic KTN828 operating manual

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control brochure

Medion

Medion E74023 instruction manual

intensity

intensity RM02A Operation manual

GE RM24950 instruction manual
