One Forall BIG EASY URC-2585 User manual

Retain For Future Reference

“BIG EASY”®

USER GUIDE & CODE BOOK

Universal Remote

URC-2585

ABOUT YOUR BIG EASY

The Keypad 2

INSTALLING THE BATTERIES

SETTING UP THE BIG EASY

Setting Up Your Device 5

Using the AUX Key 6

ADVANCED FEATURES

Reassigning the Device Keys 7

Using the Scan key 8

Teletext and Fastext 9

Controlling Colour and Brightness 10

Sleeptimer 11

Punch-Through 13

Preventing Accidental Code Changes 13

TROUBLE-SHOOTING

Searching for Your Code 14

Code Blink Out 15

Helpful Hints 16

Consumer Help-Line 17

Quick Code Reference 18

SET-UP CODES

TVs 19

Videos 23

Satellite Receivers 25

Cable Boxes 27

Note: If you’re having problems operating all the functions

of your device, don’t worry, your ONE FOR ALL may just

need customising for your model type. Just call our

consumer help-line and we’ll get you on the right track.

Table of Contents

LED

Power

Scan key

Volume

Mute

Programme

Fast Forward

Pause

Fastext Keys

Record

Device Keys

Magic Key

Number Key

-/-- Key

Teletext Keys

Play

Rewind

Stop

Your ONE FOR ALL “Big Easy” Package contains:

Your BIG EASY Remote

Your BIG EASY Manual

Your manual is divided into two parts: set-up instructions and

device codes. You will need your manual to set up your new

BIG EASY so please be sure to keep it.

Your BIG EASY needs four new AAA/LR03 alkaline batteries.

Your BIG EASY can operate four devices: a Television, a Video

Recorder, a Satellite Receiver and a second Television, Video or

Satellite Receiver. Your BIG EASY can also operate Cable

Converters.

The Keypad

Key Function

LED LED

The LED (Light Emitting Diode) flashes red to

show the remote is working.

Power

The Power key controls the same function as on

your original remote.

Device Keys

The TV, VCR, SAT and AUX keys select the home

entertainment device to be controlled. For

example pressing the TV key allows the remote

to control the functions of your Television,

after pressing VCR you can operate your Video

Cassette Recorder and the SAT key operates

your Satellite Receiver or Cable Converter. The

AUX key operates a second Television, Video

Recorder or Satellite Receiver.

MAGIC Key

The MAGIC key is used to set up your BIG EASY

and to access special functions.

Scan

The Scan key allows you to easily browse

through the programmes on your Television,

Video Recorder, Satellite Receiver and Cable

Converter. See page 8 for more information.

Volume, Programme

The Volume and Programme keys control the

two most frequently used functions of your

Television and Satellite Receiver. They operate

just as those on your original remote.

AUX

SAT

VCR

MAGIC

About Your BIG EASY

Key Function

Mute

The Mute key operates the same function it did

on your original remote.

Number Keys

The Number keys (0-9, 10, 20) provide functions

just like your original remote, such as direct

access programme selection. If your original

remote uses one/two digit input switching

(-/-- symbol), this function can be obtained by

pressing the -/-- key, which is the same as the

10 key.

Video Recorder Keys

After pressing the VCR key, the Video Recorder

keys operate the functions of your Video

Recorder. To prevent accidental recording, the

Record key must be pressed twice to start

recording.

Teletext/Fastext Keys

After pressing the TV key, the top row of the

Video Recorder keys are used to operate the

main teletext functions. The symbols above the

keys are for teletext. The Text keys are used to

access the teletext functions of your Television.

Of course, your Television must be teletext

capable. For an explanation of the teletext

symbols, please refer to page 9 of this manual.

After pressing the TV key, the bottom row of

the Video Recorder keys marked red, green,

yellow and blue, allow you to access the fastext

functions of your television. Again, your

television must be fastext capable to operate

these functions. For a more detailed

explanation of teletext and fastext, please refer

to the manual of your television set.

REC

STOP

-/--

STOP

REC

(red)

(blue)

(yellow)

(green)

About your BIG EASY

Your BIG EASY needs four new AAA/LR03 alkaline batteries.

Remove the battery cover from the

back of your BIG EASY.

Match the batteries to the + and -

marks inside the battery case, then

insert the batteries.

Press the battery cover back into

place.

Note: In order to avoid having to reprogramme your ONE

FOR ALL after you remove the batteries, you will need to

insert new batteries within 15 minutes. Also it is best that

you do not use rechargable batteries.

Installing the Batteries

Setting Up Your Device

To set up the Big Easy for your television:

Find your Television code in the

Set-Up Code section (starting on page

19). Codes are listed by brand name. The

most popular code is listed first. Make

sure your Television is switched on.

Press and release your BIG EASY’s TV key,

then press and hold the MAGIC key

until the red light blinks twice (the light

will blink once then twice).

Enter your three-digit TV code using

the number keys. The red light will blink

twice.

Now, aim your BIG EASY at your

Television and press POWER.

If your Television switches off, your BIG

EASY is ready to run your Television.

Write your code in the three boxes on page 18, for quick, easy

reference.

To control your Television, press TV first.

Setting Up The BIG EASY

ONE FOR ALL

A-Mark

Admiral

Anam

Anam National

AOC

Archer

All & Howell

003

179, 180, 016, 047, 093

180

055, 161

019, 030, 052, 003, 136

003

016

030, 046, 186, 056

000

000, 000, 000, 046

MAGIC

Important notes:

- To set up your Video Recorder or Satellite, follow the same

instructions above, only press the VCR or SAT key during

step 2.

- To set up your Cable Box, follow the instructions above

only press the SAT key during step 2.

- If your Video’s original remote control does not have a

power key, press PLAY instead of POWER when searching

for your code.

- If your Device does not respond, follow steps 1 - 4 with

each code listed for your brand. If none of the codes listed

for your brand operate your Device, then try the search

method described on page 14, even if your brand is not

listed at all.

Setting Up the BIG EASY

Using the AUX Key

The AUX key on your BIG EASY can be used to control a

second Television, Video Recorder or Satellite Receiver.

To set up the AUX key to control a second TV:

Press and hold the MAGIC key until

the red light blinks twice (the light will

blink once then twice).

Press 9 9 2 TV AUX.

Find your Television code in the Set-Up

Code section (starting on page 19). Codes

are listed by brand name. The most

popular code is listed first. Make sure

your Television is switched on.

Press and release your BIG EASY’s AUX

key, then press and hold the MAGIC

key until the BIG EASY’s red light blinks

twice.

Enter your three-digit TV code using

the number keys. The red light will blink

twice.

Now, aim your BIG EASY at your

Television and press POWER.

If your Television switches off, your BIG

EASY is ready to run your Television.

When you want to control your second

TV, press AUX first.

ONE FOR ALL

A-Mark

Admiral

Anam

Anam National

AOC

Archer

All & Howell

003

179, 180, 016, 047, 093

180

055, 161

019, 030, 052, 003, 136

003

016

030, 046, 186, 056

000

000, 000, 000, 046

MAGIC

AUX

MAGIC

Important notes:

- To set up your Video Recorder or Satellite, follow the same

instructions above, only press the VCR or SAT key during

step 2.

- To set up your Cable Box, follow the instructions above

only press the SAT key during step 2.

- If your Video’s original remote control does not have a

power key, press PLAY instead of POWER when searching

for your code.

- If your device does not respond, follow steps 3 - 6 with

each code listed for your brand. If none of the codes listed

for your brand operate your Television, Video Recorder or

Satellite Receiver, then try the search method described on

page 14, even if your brand is not listed at all.

Reassigning the Device Keys

If you want, you can change any of the device keys (TV, VCR,

SAT or AUX) to operate another type of device. The chart

below lists how to change the keys and to set up that device:

To Change: Press:

MAGIC*992 VCR TV,

then TV MAGIC*Code

MAGIC*992 SAT TV,

then TV MAGIC*Code

MAGIC*992 TV VCR,

then VCR MAGIC*Code

MAGIC*992 SAT VCR,

then VCR MAGIC*Code

MAGIC*992 TV SAT,

then SAT MAGIC*Code

MAGIC*992 VCR SAT,

then SAT MAGIC*Code

MAGIC*992 TV AUX,

then AUX MAGIC*Code

MAGIC*992 VCR AUX,

then AUX MAGIC*Code

MAGIC*992 SAT AUX,

then AUX MAGIC*Code

*Hold down the MAGIC key until the red light blinks twice.

To reset a device key to its original function, press:

TV key MA*992

VCR key MA*992

SAT key MA*992

AUX key MA*992

*Hold down the MAGIC key until the red light blinks twice.

Advanced Features

SAT

AUX

VCR

AUX

VCR

SAT

VCR

SAT

VCR

MAGIC

VCR

SAT

AUX

VCR

SAT

AUX

MAGIC

Using the Scan Key

Your BIG EASY comes with a special Scan key which lets you

go through every programme available on your Television,

Video Recorder, Satellite Receiver or Cable Converter.

For example, to scan through the programmes on your Television:

Aim the BIG EASY at your Television and

press TV, then Scan. You will

automatically move through all the

programmes available on your Television

stopping at each pro-gramme for about

three seconds. Remember, the BIG EASY

must remain aimed at your Television the

entire time you are using Scan.

When you find a programme that you

would like to watch, simply press the

Scan key again to stop the Scan feature.

To use Scan with your Video Recorder, Satellite Receiver or

Cable Converter, simply press the appropriate device key

(VCR, SAT or AUX), then Scan.

Advanced Features

Note: Scan may not function with devices that did not have

a programme +/- key on the original remote.

Table of contents

Other One Forall Universal Remote manuals

One Forall

One Forall URC-3445 User manual

One Forall

One Forall URC-7240 User manual

One Forall

One Forall URC-2500 User manual

One Forall

One Forall URC-6420 Administrator guide

One Forall

One Forall URC-1625 User manual

One Forall

One Forall URC-6532 User manual

One Forall

One Forall URC-7530 User manual

One Forall

One Forall URC-7721 User manual

One Forall

One Forall URC-7711 User manual

One Forall

One Forall KAMELEON 4 User manual

One Forall

One Forall URC-3710 Administrator guide

One Forall

One Forall Mosaic URC-9990 User manual

One Forall

One Forall URC-7940 User manual

One Forall

One Forall URC-4021 User manual

One Forall

One Forall Xsight Colour User manual

One Forall

One Forall OFA Kameleon URC-6690 User manual

One Forall

One Forall URC-7930 User manual

One Forall

One Forall KAMELEON 5 User manual

One Forall

One Forall URC-7542 User manual

One Forall

One Forall URC-44 User manual

One Forall

One Forall URC-6210 User manual

One Forall

One Forall Audio Zapper User manual

One Forall

One Forall URC 7980 User manual

One Forall

One Forall URC-7556 User manual

Popular Universal Remote manuals by other brands

Pronto

Pronto Peel quick start guide

GE 24929 instruction manual

Radio Shack

Radio Shack Wireless Remote Control System owner's manual

AUVIO

AUVIO Universal Home Theater Remote user guide

Philips

Philips Icon SRU4106 Specifications

THOMSON

THOMSON ROC4309 Operating instruction

Philips

Philips pm625S instruction manual

GE RM94931 instruction manual

RCA

RCA RCU600WMS - Universal Remote Control user manual

Blackweb

Blackweb BWB17AV002 user guide

Marmitek

Marmitek DoorGuard 300 user manual

Chunghop

Chunghop RM-L618 user manual

GE RM24965 instruction manual

Anderic

Anderic KTN828 operating manual

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control brochure

Medion

Medion E74023 instruction manual

intensity

intensity RM02A Operation manual

GE RM24950 instruction manual
