Mainboard nForce 680i SLI/

Mainboard nForce 680i LT SLI

nForce 680i SLI/

nForce 680i LT SLI

nVIDIA®nForce 680i SLI MCPs/

nForce 680i LT SLI MCPs

Support Socket 775

Intel®CoreTM 2 Extreme/ CoreTM 2 Quad/ CoreTM 2 Duo/

Pentium®Extreme Edition/

Pentium®Processors

User Manual

Dimensions (ATX form-factor):

244mm x 305mm ( W x L )

Operating System:

Windows®Vista/ Windows®XP

Mainboard nForce 680i SLI/

Mainboard nForce 680i LT SLI

Attention- Im

ortant Information

Follow the procedures below…

Troubleshooting Tips

Refer to other sections in this manual…

Things You Have To Know

The images and pictures in this manual are for reference only and may vary

from the product you received depending on specific hardware models, third

party components and software versions.

This mainboard contains very delicate IC chips. Always use a grounded

wrist strap when working with the system.

Do not touch any IC chip, lead, connector or other components.

Always unplug the AC power when you install or remove any device on the

mainboard or when confuguring pins and switches.

Packing List

nForce 680i SLI/ nForce 680i LT SLI Mainboard

I/O Shield

IDE Cable

SATA Cable

SLI Bridge

1394 Cable (Optional)

Cooling Fan (nForce 680i SLI only)

Mainboard Driver & User Manual CD

Mainboard Quick Installation Guide

Symbols

Mainboard nForce 680i SLI/

Mainboard nForce 680i LT SLI

Table of Contents

CHAPTER 1. GETTING STARTED .................................................... 1

INTRODUCTION....................................................................................................... 1

SPECIFICATION ....................................................................................................... 2

CONFIGURATION .................................................................................................... 5

Layout of nForce 680i SLI ..............................................................................5

Layout of nForce 680i LT SLI.........................................................................6

HARDWARE INSTALLATION ................................................................................... 7

CPU Processor Installation.............................................................................. 7

Memory Installation: DIMM0/1/2/3................................................................ 8

Back Panel Configuration.............................................................................. 10

Connectors ..................................................................................................... 13

Front Panel Headers: FRONTPNL................................................................ 14

EZ Control Button ......................................................................................... 15

Headers & Jumpers........................................................................................ 15

Audio Configuration...................................................................................... 17

Slots ............................................................................................................... 17

Power Supply Attachments............................................................................ 18

CHAPTER 2. BIOS SETUP ........................................................... 20

INTRODUCTION..................................................................................................... 20

MAIN MENU ......................................................................................................... 21

CHAPTER 3: SOFTWARE SETUP................................................... 23

SOFTWARE LIST ................................................................................................... 23

SOFTWARE INSTALLATION ................................................................................... 23

CHAPTER 4: TROUBLESHOOTING................................................. 27

APPENDIX I: 8/6/4/2 CHANNEL AUDIO EFFECT SETUP......................................... 30

APPENDIX II: RAID SETUP................................................................................... 32

APPENDIX III: SLI (SCALABLE LINK INTERFACE)SETUP .................................... 70

Mainboard nForce 680i SLI/

Mainboard nForce 680i LT SLI

Chapter 1. Getting Started

Introduction

Thanks for choosing nForce 680i SLI/ nForce 680i LT SLI mainboards. They are based on

nVIDIA®nForce 680i SLI/ 680i LT SLI Northbridge and Southbridge chipsets. The nForce 680i

SLI/ nForce 680i LT SLI support Intel®CoreTM 2 Extreme/ CoreTM 2 Quad/ CoreTM 2 Duo/

Pentium®Extreme Edition/ Pentium®Processors with FSB (Front Side Bus) frequencies up to

1333 MHz/ 1066 MHz/ 800 MHz.

The nForce 680i SLI/ nForce 680i LT SLI provide four DIMM (Dual In-Line Memory Modules)

sockets allowing you to install 240-pin, unbuffered non-ECC, DDRII 800/ 667/ 533 SDRAMs.

They also support Dual Channel Technology and allow you installing a total memory capacity

of 8 GB.

These mainboards provide two PCI-E x16 slots which can be used with two identical

SLI-ready PCI-Express graphics cards, enabling SLI Technology and significantly increasing

graphics performance <See Appendix III>. Furthermore, the nForce 680i SLI also provides

one PCI-E x8 slot for use with a graphics card. There are two PCI-E x1 slots provided for use

with PCI-E x1 compatible expansion cards. Two standard PCI slots for use with standard PCI

expansion cards are also allowed.

The nForce 680i SLI/ nForce 680i LT SLI provide one floppy disk drive connector that can be

used with 360KB/720KB/ 1.2MB/1.44MB/2.88MB drives. There is also one IDE connector for

connecting two IDE hard drives supporting Ultra ATA 33/66/100/133. Moreover, these

mainboards come with Serial ATA II feature, six SATA II connectors which the interfaces can

provide the transmit rate up to 3 Gbps and also support RAID 0/ 1/ 0+1/ 5 JBOD mode <See

Appendix II>

The onboard High Definition Audio CODEC (ALC885) supports 8/6/4/2 channel audio play

<See Appendix I>. These mainboards also support the Sony/Philips Digital Interfaces (SPDIF)

output function.

The nForce 680i SLI also comes with two onboard 10/100/1000 Mbps Ethernet LAN chips.

There are dual LAN ports on the back panel of your case that you can directly plug into an

Internet cable. The nForce 680i LT SLI only provides one 10/100/1000 LAN port.

There are maximal ten USB2.0/ 1.1 ports which can be set up on the nForce 680i SLI

mainboard. Eight USB2.0/ 1.1 ports are available on the nForce 680i LT SLI mainboard.

All the information (including hardware installation and software installation) in this manual are

for reference only. The contents in this manual may be updated without notice. The company

will not assume any responsibility for any errors or mistakes within.

Mainboard nForce 680i SLI/

Mainboard nForce 680i LT SLI

Specification

CPU

Support Socket 775

Support Intel®CoreTM 2 Extreme/ CoreTM 2 Quad/ CoreTM 2 Duo/ Pentium®Extreme

Edition/ Pentium®Processors

Support Hyper-Threading Technology

Support 1333 MHz/ 1066 MHz/ 800 MHz/ 533 MHz FSB (Front Side Bus) Frequencies

Chipset

Northbridge Chipset – nVIDIA®nForce 680i SLI SPP/ 680i LT SLI SPP

Southbridge Chipset – nVIDIA®nForce 680i SLI MCP/ 680i LT SLI MCP

I/O Controller – Winbond®W83627DHG

High Definition Audio Codec – Realtek®ALC885

LAN Controller – Marvell®88E1116

IEEE1394 Controller – TI®TSB43AB22A

Memory

Four DIMM sockets

Supports unbuffered & non-ECC DDRII 800/ 667/ 533 SDRAM

Supports a total memory capacity of up to 8 GB

Supports Dual Channel data bus

Onboard HD Audio CODEC (ALC885)

High performance CODEC with high S/N ratio (>100 db)

Compatible with Azalia 1.0 specification

Supports 8/6/4/2 channel playback capability

Supports jack sensing and re-tasking function

Microphone AEC, NS, and BF technology for voice application

Supports Sony/ Philips Digital Interfaces (S/PDIF) functionality

Mainboard nForce 680i SLI/

Mainboard nForce 680i LT SLI

Slots

Five PCI-Express interface slots for graphics cards and expansion cards

1. Two PCI-E x16 slots: supports x16 mode for true dual-graphics SLI configurations

2. One PCI-E x8 slot: supports x8 mode for future GPU physics applications nForce

680i SLI only

3. Two PCI-E x1 slots: supports up to x1 mode with 250 MB/s one-way bandwidth

Two PCI interface slots for expansion cards

FDD Connector

Supports one FDD connector to set up to two floppy disk drives

Supports 360KB/ 720KB/ 1.2MB/ 1.44MB/ 2.88MB

IDE Connector

One IDE connector

Supports up to two IDE devices

Supports Ultra ATA 33/66/100/133

Supports high capacity hard disk drives

Serial ATA II Connectors

Six SATA II connectors

Supports SATA 2.0 specification with data transfer rate up to 3 Gbps

One SATA II connector can only support one SATA II HDD

Onboard LAN Chip

Supports Dual LAN nForce 680i SLI only

Supports 10/100/1000 Mbps Ethernet LAN

I/O facility Connectors

Supports one PS/2 mouse port and one PS/2 keyboard port

Supports one IEEE1394 port on back panel

Supports one SPDIF OUT port on back panel

Supports one serial port (COM1) header and one IEEE1394 header with external

device connected

Mainboard nForce 680i SLI/

Mainboard nForce 680i LT SLI

Universal Serial Bus

Six onboard USB 2.0/ 1.1 ports nForce 680i SLI only

Two front USB headers come with this mainboard for additional four USB ports

Support a maximum of ten USB ports to connect USB compatible devices 

nForce 680i SLI only

BIOS

Phoenix-Award™ BIOS

Support APM 1.2

Support ACPI 2.0 power management

Green Function

Supports ACPI (Advanced Configuration and Power Interface)

Supports Phoenix-Award™ BIOS power management function

Supports S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4 (suspend to

disk – depends on OS), and S5 (soft – off).

Shadow RAM

Integrated memory controller provides shadow RAM functionality and supports ROM

BIOS

Flash Memory

Supports flash memory functionality

Supports ESCD functionality

Hardware Monitor Function

Monitors CPU/ Northbridge/ Chassis Fan Speed

Monitors CPU temperature

Monitors CPU/ Memory/ System voltages

Mainboard nForce 680i SLI/

Mainboard nForce 680i LT SLI

Configuration

Layout of nForce 680i SLI

Mainboard nForce 680i SLI/

Mainboard nForce 680i LT SLI

Layout of nForce 680i LT SLI

Other manuals for nForce 680I LT SLI

This manual suits for next models

Table of contents

Other Nvidia Computer Hardware manuals

Nvidia

Nvidia UFM 4.0 Instructions for use

Nvidia

Nvidia GeForce2 Ti SP6600Ti User manual

Nvidia

Nvidia JETSON AGX XAVIER User manual

Nvidia

Nvidia Jetson AGX Orin Series Installation and operating manual

Nvidia

Nvidia JETSON TX2 User manual

Nvidia

Nvidia Quadro PLEX 7000 User manual

Nvidia

Nvidia TESLA C2075 User manual

Nvidia

Nvidia Mellanox User manual

Nvidia

Nvidia MSTFLINT Operator's manual

Nvidia

Nvidia Jetson Orin NX Guide

Nvidia

Nvidia Quadro User manual

Nvidia

Nvidia Clara AGX User manual

Nvidia

Nvidia Mellanox ConnectX-5 Manual

Nvidia

Nvidia TESLA K20 User manual

Nvidia

Nvidia Mellanox ConnectX-5 User manual

Nvidia

Nvidia Mellanox ConnectX-6 MCX654106A-ECAT User manual

Nvidia

Nvidia JETSON XAVIER NX Guide

Nvidia

Nvidia Geforce PCI-Express Series User manual

Nvidia

Nvidia Mellanox ConnectX-5 User manual

Nvidia

Nvidia BlueField-3 User manual

Nvidia

Nvidia GeForce FX Series User manual

Nvidia

Nvidia RTX 6000 User manual

Nvidia

Nvidia Mellanox ConnectX-6 Dx Series User manual

Nvidia

Nvidia TURING GPU User manual

Popular Computer Hardware manuals by other brands

EMC2

EMC2 VNX Series Hardware Information Guide

Panasonic

Panasonic DV0PM20105 Operation manual

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 user manual

Gigabyte

Gigabyte B660M DS3H AX DDR4 user manual

Raidon

Raidon iT2300 Quick installation guide

National Instruments

National Instruments PXI-8186 user manual

Hauppauge

Hauppauge WinTV-HVR-2250 Quick installation guide

Kontron

Kontron CP6002 user guide

Manhattan

Manhattan 702843 user manual

Aphex

Aphex 230 instruction manual

AMD

AMD Phenom II Product data sheet

Intel

Intel NUC 12 Pro user guide

dbx

dbx Zone Pro 1260 user manual

Galaxy

Galaxy GHDX2-2430S-24F4D Installation and hardware reference manual

Intel

Intel AXXRMFBU4 Quick installation user's guide

Kontron

Kontron DIMM-PC/MD product manual

ST X-NUCLEO-SAFEA1B How to use

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 installation manual

Nvidia nForce 680I LT SLI Instructions for use

Popular Computer Hardware manuals by other brands
