Novus NV-108S/P+ User manual
U s e r ’s m a n u a l
NV-108S/P+
NV-108S/P+ User’s manual ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
2
EMC (2004/108/EC) and LVD (2006/95/EC ) Directives
CE Marking
Our products are manufactured to comply with the requirements of the following directives and national
regulations implementing the directives:
Electromagnetic compatibility EMC 2004/108/EC.
Low voltage LVD 2006/95/EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and 1000VAC as well as
75VDC and 1500VDC.
WEEE Directive 2002/96/EC
Information on Disposal for Users of Waste Electrical and Electronic Equipment
This appliance is marked according to the European 1000VAC Directive on Waste Electrical and
Electronic Equipment (2002/96/EC) and further amendments. By ensuring this product is disposed of
correctly, you will help to prevent potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or the documents accompanying the product, indicates that this appliance may not be
treated as household waste. It shall be handed over to the applicable collection point for used up electrical and
electronic equipment for recycling purpose. For more information about recycling of this product, please contact
your local authorities, your household waste disposal service or the shop where you purchased the product.
RoHS Directive 2002/95/EC
Out of concern for human health protection and friendly environment, we assure that our products
falling under RoHS Directive regulations, regarding the restriction of the use of hazardous substances
in electrical and electronic equipment, have been designed and manufactured in compliance with the
above mentioned regulations. Simultaneously, we claim that our products have been tested and do not
contain hazardous substances whose exceeding limits could have negative impact on human health or natural
environment.
Information
The device, as a part of professional CCTV system used for surveillance and control, is not designed for self
installation in households by individuals without technical knowledge.
The manufacturer is not responsible for defects and damages that result from improper or inconsistent with
user’s manual installation of the device in the system.
INFORMATION
NV-108S/P+ User’s manual ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
3
WARNING!
THE KNOWLEDGE OF THIS MANUAL IS AN INDESPENSIBLE CONDITION OF A
PROPER DEVICE OPERATION. YOU ARE KINDLY REQUSTED TO FAMILIRIZE
YOURSELF WITH THE MANUAL PRIOR TO INSTALLATION AND FURTHER
DEVICE OPERATION.
WARNING!
USER IS NOT ALLOWED TO DISASSEMBLE THE CASING AS THERE ARE NO
USER-SERVICEABLE PARTS INSIDE THIS UNIT. ONLY AUTHORIZED SERVICE
PERSONNEL MAY OPEN THE UNIT
INSTALLATION AND SERVICING SHOULD ONLY BE DONE BY QUALIFIED SERVICE
PERSONNEL AND SHOULD CONFORM TO ALL LOCAL REGULATIONS
WARNING!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT DESCRIBED FOR THE GIVEN
PRODUCT IN USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE
PRODUCT, OR IF IT DOES NOT ARISE FROM THE USUAL APPLICATION OF THE
PRODUCT, MANUFACTURER MUST BE CONTACTED UNDER THE RIGOR OF
EXCLUDING THE MANUFACTURER’S RESPONSIBILITY FOR THE RESULTS OF SUCH AN
ACTION.
IMPORTANT SAFEGUARDS AND WARNINGS
1. Prior to undertaking any action please consult the following manual and read all the safety and
operating instructions before starting the device.
2. Please keep this manual for the lifespan of the device in case referring to the contents of this manual
is necessary;
3. All the safety precautions referred to in this manual should be strictly followed, as they have a
direct influence on user’s safety and durability and reliability of the device;
4. All actions conducted by the servicemen and users must be accomplished in accordance with the
user’s manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. Usage of additional devices and components neither provided nor recommended by the producer
is forbidden;
7. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers
etc.) is not recommended since it may lead to heat build-up and damaging the device itself
as a consequence;
8. Mounting the device on unstable surface or using not recommended mounts is forbidden.
Improperly mounted switch may cause a fatal accident or may be seriously damaged itself. Switch
must be mounted by qualified personnel with proper authorization, in accordance with this user’s
manual;
IMPORTANT SAFEGUARDS AND WARNINGS
NV-108S/P+ User’s manual ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
4
IMPORTANT SAFEGUARDS AND WARNINGS
9. Device should be supplied only from a power sources whose parameters are in accordance with
those specified by the producer in the device’s technical datasheet. Therefore, it is forbidden to
supply the switch from a power sources with unknown parameters, unstable or not meeting
producer’s requirements;
10. Signal and power cables should be placed in a way excluding the possibility of damaging them by
accident. Special attention must be paid to cables getting from the switch and connecting the
power supply;
11. Electric installation supplying the device should be designed to meet the specifications given
by the producer in such a way that overloading is impossible;
12. User cannot repair or upgrade the equipment himself. All maintenance actions and repairs should
be conducted only by qualified service personnel;
13. Unplug the switch from the power source immediately and contact the proper maintenance
department when the following occurs:
Damages to the power cord or to the plug itself;
Liquids getting inside the device or exposure to strong mechanical shock;
Device behaves in a way not described in the manual and all adjustments approved by the
manufacturer and possible to apply by user himself, seem not to have any effect;
Switch is damaged;
Atypical behaviour of the switch components may be seen (heard).
14. In necessity of repairs attention to using only original replacement parts (with their parameters
in accordance with those specified by the producer) should be paid. Non-licensed service and
non-genuine replacement parts may cause fire or electrocution;
15. After maintenance activities tests should be run to ensure proper operation of all the functional
components of the device.
Due to the product being constantly enhanced and optimized, certain parameters and functions described
in the manual in question may change without further notice.
We strongly suggest visiting the www.novuscctv.com website in order to access the newest manual
NV-108S/P+ User’s manual ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
5
1. PACKAGE CONTENTS
8 port PoE Switch,
Power supply,
Wall hangers,
DIN rail hanger,
User’s manual.
2. MAIN CHARACTERISTICS
8 10/100 Mbps PoE ethernet ports support IEEE 802.2af/at standards
PoE network port support IEEE802.3 af/at standard, it can provide 30W consumption and power
supply to the big consumption camera with infrared or heater.
Provide 2 uplink ports, 1000Mbps optical port and ethernet port.
UPLINK ethernet port can connect with NVR and other high bandwidth device conveniently up to
150 m.
UPLINK optical port reserve SFP port for users to select different performance SFP optical fiber
module, conveniently solving the problem of long distance transmission.
Surge Protection up to 4kV.
Fast and easy installation.
FOREWORD INFORMATION
Gigabit Media
Converter
Novus PoE Switch
Novus NVR
Novus Cameras
Optical Fiber
Ethernet Cable
NV-108S/P+ User’s manual ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
6
3. SPECIFICATION
FEATURES AND SPECIFICATION
NETWORK
Network Port
1～8 port:10/100Mbps PoE network port
UPLINK port:10/100/1000Mbps network port
SFP:1000Mbps optical fiber SFP module port
Transmission Distance
1～8 port:150m
UPLINK port: 100m
PoE+ 1-8: 20m
PoE 1-8: 150m
PoE Protocol IEEE802.3 af, IEEE802.3 at
Network Standard IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX,
IEEE802.3ab 1000BASE-T, IEEE802.3z 1000BASE-SX\LX
Package Data Cache 1 MB
MAC Address List 8k
FUNCTIONS
Key Button 8 reset buttons, one for each interface
1 switch reset button
Surge protection yes
INSTALLATION PARAMETERS
Dimensions (mm) 159 (W) x 46,5 (H) x 110 (D)
Weight 570 g
Power supply DC 48V~57V included
Device power consumption <5W
Power efficiency for 1-8 ports 110W for all ports, up to 30W for one port
Temperatura pracy -10˚C ~ +55˚C
NV-108S/P+ User’s manual ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
7
POSITION AND FUNCTIONS OF SWITCH COMPONENTS
4. POSITION AND FUNCTIONS OF SWITCH COMPONENTS
A.Power/UPLINK optical port indicator
B.SFP Optical port
C.UPLINK network port
D.PoE Network port
E.Power input
F.Grounding terminal
Front
Back
A
B C D
E
F
NV-108S/P+ User’s manual ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
8
POSITION AND FUNCTIONS OF SWITCH COMPONENTS
G. Power input
H. Power indicator
I. Reset button
J. PoE port reset button
Left
Up
G
H
I J
NV-108S/P+ User’s manual ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
9
NOTES
NV-108S/P+ User’s manual ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
10
AAT Holding sp. z o.o., ul. Puławska 431, 02-801 Warszawa, Polska
tel.: 22 546 07 00, faks: 22 546 07 59
www.novuscctv.com
2014-05-29 wer. 1.0 TW, MK
