NOVOGO V Series User manual
User
Manual
2
Table of Contents
License Agreement 4
Precautions and Notice 6
Checking The Novogo V Series package 7
Identifying The Novogo V Series parts 8
Preparing The Novogo V Series 9
Installing The Novogo V Series in the car
Installing in your automobile
Removing your Novogo V Series and docking kit
Installation Notes
10
10
12
13
Main Menu 14
Navigation
Address
Point Of Interest
Select On Map
Favorites or Recent Destinations
15
16
17
18
19
Home 21
Voice Command 22
Route Planning 23
Map Screen 24
Settings
User mode
26
26
3
Table of Contents
Map information
Route information
Signpost information
Speed limit
Volume
Representation
Touchscreen calibration
Auto mode
Routing options
Itinerary
Time zone
Format
TMC
Home address
Product information
26
27
27
28
28
29
29
30
30
31
31
32
32
33
33
Novogo Map Disc
using the novogo map disc
Recover my Map
Switch Language
Backup / Restore
34
34
35
36
37
Safety Notices and Warnings 38
Other Safety Information 39
4
PLEASED READ THIS LICENSE AGREEMENT CAREFULLY BEFORE USING THE PRODUCT ACCOMPANIED WITH THIS DOCUMENT. BY
USING ALL OR ANY PORTION OF THE NOVOGO SOFTWARE AND/OR HARDWARE, YOU ACCEPT ALL THE TERMS OF THIS AGREE-
MENT BETWEEN YOU, THE END USER, AND NOVOGO INC.
1) NOVOGO Inc. grants you (Licensee) a limited license (License) to use the NOVOGO Navigation System hardware (Hard-
ware) and software (Software) in the accompanied package acquired with this License. This License is non-exclusive and
non-transferable. Unless otherwise granted by NOVOGO Inc., Licensee may not rent, lease, or lend software to another
person.
2) The License is effective upon, and from the date of, the agreement by Licensee to the terms herein and execution of this
License until the formal release of the licensed product at any place, unless terminated by NOVOGO Inc.
3) Hardware and Software include, but not limited to, NOVOGO GPS Navigator, SD memory card, suction-mount automo-
bile cradle, AC adapter, Cigarette lighter charger, (optional) remote controller, (optional) carrying case, Map CD/DVD,
USB cable, and all written or electric document from NOVOGO Inc. or its suppliers.
4) Licensee may install the Software on only one computer provided that it is combined with one navigation system. Licen-
see may only make one copy of the Software for backup purposes. Downloading the map data and transferring to an-
other navigation system is explicitly prohibited.
5) The copyrights and other intellectual or proprietary rights to the Software and Hardware are owned by NOVOGO Inc. or
its suppliers. Licensee acknowledges that the Software is the property of NOVOGO Inc. and Licensee is not permitted to
analyze it by decompiling or disassembling (reverse engineering), or to modify it and make software based on the work.
If Licensee needs any information regarding Hardware/Software structure for Licensee’s own purpose, please contact
NOVOGO Inc. at [email protected].
License Agreement
5
6) NOVOGO Inc. reserves the rights to terminate this License Agreement at any time for any reason. Upon termination of this
License Agreement, Licensee shall discontinue using Software and Hardware for any purpose, by any means and in any
form, in whole or in part, unless agreed otherwise by NOVOGO Inc. in written.
7) In addition to the criminal penalties and civil liabilities provided by the Taiwan Copyright Law, Licensee shall be liable for
any damages and losses caused to NOVOGO Inc. in accordance with this License Agreement if Licensee uses the Software
and/or Hardware in breach of any terms in this License.
8) The License is subject to Law of the Republic of China and Taiwan Taipei District Court is the only competent court for dis-
putes related to this License and the use of NOVOGO Hardware and/or Software.
License Agreement
6
Precautions and Notices
1) Please remove the battery and use only the cigarette lighter charger in the car when operating under high tempera-
ture! The Li-ion battery can not be used above 50'C / 120'F.
2) When you get off the car, do not leave the Novogo Navigator on the dashboard that is subject to direct sunlight. The
overheating of the battery can cause malfunction and/or danger.
3) If the battery is running out of power or have not been used after a long period of time, it may need to be charged
for 3~5 minutes before you can turn it on.
4) Novogo provides one year warranty of the GPS Navigator and 6 months warranty of the battery. For any warranty
issues or technical supports, please contact with your dealer or visit our website www.novogo.com for more details.
5) GPS is operated by the United States government, which is solely responsible for the performance of GPS. Any change to
the GPS system can affect the accuracy of all GPS equipments.
6) GPS satellite signals cannot pass through solid materials (except glass). When you are inside a tunnel or building, GPS
signals will not be available.
7) A minimum of 3 GPS satellite signals is needed to determine current position. Signal reception can be affected by situa-
tions such as bad weather or dense overhead obstacles (e.g. trees and tall buildings).
8) Other wireless devices in the vehicle might interfere with the reception of satellite signals and cause the reception to be
unstable.
9) A docking kit is needed when using the device in a car. Be sure to place the device in an appropriate place, so as not to
obstruct the driver’s view, and avoid the deployment in front of airbags.
0) Use this product prudently. The product is intended to be used only as a navigation aid. It is not for
precise measurement of direction, distance, location or topography.
1) The calculated route is for reference only. It is the user’s responsibility to follow the traffic signs and local regulations
along the roads.
2) For your own safety, do not operate the Novogo Navigator while driving.
1
1
1
7
Checking The Novogo V Series package
Novogo V series GPS Navigator
Docking Station
Suction-Mount Car Holder
Extra Color Face Plate
Universal AC Adapter
Cigarette Lighter Charger
Mini USB Cable
Warranty Card
Carrying Bag
Quick User Guide
Novogo Map CD
Hardware Installation Guide
Removable Li-ion Battery
SD Memory Card with Map Data Pre-Loaded
External TMC Antenna
a
a
For V50 / V90
5
1 2 3
6 7
9
8
1
2
3
4
5
6
7
8
9
11
10
13
12
14
1413
4
10
11 12
8
17
18
Escape button
Speak button
19
20
21
22
Reset button
Audio volume dial
Audio output jack
DC power input
23
24
25
26
27
28
Battery compartment
Antenna (flip up/flip down)
Docking connector
Antenna lock (when raised)
Audio speaker
Memory card slots (SD/CF)
1
2
3
4
5
Audio volume dial
Battery compartment (removable Li-ion)
Antenna (flip up/flip down)
USB port
On/Off switch
6
7
CF memory card slot
SD memory card slot
8Screen Lock / Charging LED
9
10
11
12
13
14
15
16
Infrared port for remote controller
3.5 color TFT touchscreen
Zoom in/out buttons
Microphone
GPS Status / Save current position
menu button
Enter button
Selection stick
Identifying The Novogo V Series parts
6 7
12345
14
13
16
15
18
17
8 9 11 12
10 20
19 21 22 23 24 25 26 27 28
9
Preparing The Novogo V Series
Please charge the battery for
4 hours for the first time
Insert the SD memory card
with map data pre-loaded
Insert the battery
10
1) Assemble the Docking Station with
Car Holder
2) Cleaning the suction cup and windshield
first and attach the Car Holder to an area
that will NOT obstruct your driving view
and also AVOID the deployment in front
of airbags. Then push the tab towards the
windshield to lock the suction cup
3) Adjust the viewing angle by (1) Stretch
the arm, (2) Loosen the horizontal
screw or (3) Loosen the vertical screw.
Installing The Novogo V Series in the car
4) Flip up the GPS antenna and expose it
under open sky
5) Hook the Navigator with Docking Station first, press the
Navigator towards the Docking Station until it clicks in
place
