Check for damaged or
misaligned parts before using the
splitter. Do not use the splitter if
it is damaged and have it
serviced before use.
Keep both hands away from
edge plate during use. Wedge
can cut through sin and break
bones.
Wear safety glasses to avoid eye
injury from pieces of log that may
fly out while splitting.
High pressure fluid can inject
under skin resulting in serious
injury. Make sure all fittings are
tight before applying pressure.
Relieve system pressure before
servicing. Do not check for leaks
with hand. Use a piece of
cardboard to check for leaks. If
skin injection occurs, seek
immediate treatment.
Serious injury or death can occur
if splitter is improperly towed.
Do not ride or transport cargo on
the splitter. Drive with the splitter
securely attached. Turn off the
vehicle before leaving the splitter
unattended. Choose a level
surface to operate the splitter
and block the wheels to prevent
rolling.
Position muffler at least 7 feet
away from combustible objects.
Stop the engine before adding
fuel and keep heat, sparks and
flames away.
Do not add fuel while the engine
is still running or hot.
Use an approved container to
add fuel to the splitter. Do not
pump fuel directly into the splitter
at a gas station.
Do not change or add to the
exhaust system, fuel tanks or
fuel lines.
Check for fuel leaks before use.
OPERATING
INSTRUCTIONS
1) Load a log onto the beam and
against the endplate.
2) Make sure hands are clear of
the splitter.
3) Push control valve handle
forward by one hand to split log.
4) Push control valve handle
backward by one hand to return
wedge to original position.
5) Clear split wood from work
area.
MAINTENANCE
Before performing maintenance,
ensure the engine is turned off
and move the control handle
forwards and backwards to
relieve hydraulic pressure.
After performing maintenance,
ensure all guards, shields and
safety features are put back in
place. Failure to do so can result
in injury.
Refer to the engine owner’s
manual for engine maintenance.
Inspect for exposed wire mesh
and leaks on the hoses before
each use. Replace all worn and
damaged hoses before starting
engine.
Inspect for cracks and leaks in
the hydraulic fittings before
each use. Replace all damaged
fittings before starting engine.
Check for loose nuts and bolts
before each use. Tighten loose
nuts and bolts before use.
Apply grease to beam surface
before each use.
Clear debris from moving parts
before each use.
