Nortel IP Phone 1110 User manual

Carrier VoIP

Nortel IP Phone 1110 User

Guide (CICM)

ATTENTION

Clicking on a PDF hyperlink takes you to the appropriate page. If necessary,

scroll up or down the page to see the beginning of the referenced section.

NN10300-021

Document status: Draft

Document version: 1.0

Document date: 30 November 2006

The information in this document is sourced in Canada, the United States of America, and the United Kingdom.

This is the Way, This is Nortel, Nortel, the Nortel logo, the globemark design, and the NORTEL NETWORKS

corporate logo, are trademarks of Nortel Networks. All other trademarks are the property of their respective owners.

Contents

New in this release 7

Features 7

Overview 9

IP Phone terminal description 9

Terminal display 11

Terminal indicators 11

IP Phone 1110 menu systems 13

Logoff 13

Call Services menu 13

Settings menu 14

Regional menu 14

User menu 14

Terminal menu 14

Call menu 14

Inbox 15

Outbox 15

Directory 15

Menu Hierarchy 16

How to use the navigation keys 17

Connecting the IP Phone to the LAN 19

Logging on 21

Logging off 23

Making calls 25

Making a call using off-hook dialing 25

Making a call using handsfree dialing 25

Making a call using predial 26

Editing a predialed number 26

Answering calls 27

Answering a call 27

Answering a second call 27

Carrier VoIP

Nortel IP Phone 1110 User Guide (CICM)

NN10300-021 1.0 Draft

(I)SN10 30 November 2006

4Contents

Ending a call 29

While on an active call 31

Using call hold 31

Transferring a call 31

Using conference call 32

Using call forward 33

Navigating the menu system 35

Navigating the main menu 35

Navigating the Call Services menu 36

Navigating the Settings menu 36

Navigating the Regional menu 36

Navigating the User menu 37

Navigating the Terminal menu 37

Navigating the Call menu 37

Navigating the Feature menu 38

Using the Call Services menu 41

Activating a feature from the menu 41

Using a softkey to activate a feature 42

Assigning a feature to a key 42

Removing a feature assignment from a softkey 42

Viewing softkey assignments 43

Displaying softkey labels while on a call 43

Hiding softkey labels 44

Viewing feature proﬁles 44

Labeling softkeys 45

Using the Regional Menu 47

Selecting the language 47

Selecting the time zone 48

Enabling Daylight Saving Time 48

Disabling Daylight Saving Time 49

Setting the time format 49

Setting the date format 50

Resetting the default time 51

Using the User menu 53

Viewing your user name 53

Viewing your login type 53

Viewing, disabling, or enabling Auto Login 54

Changing your password 55

Carrier VoIP

Nortel IP Phone 1110 User Guide (CICM)

NN10300-021 1.0 Draft

(I)SN10 30 November 2006

Contents 5

Using the Terminal menu 57

Accessing the Audio menu 57

Viewing and editing your audio settings 58

Changing the default volume 59

Selecting a ring tone 60

Selecting the dialpad feedback 61

Enabling and disabling handsfree 61

Adjusting the contrast level of the display 62

Performing a ﬁrmware upgrade 62

Using the Call menu 65

Resetting softkeys to the defaults 65

Using the Feature menu 67

Using the Assign menu 67

Deﬁning the Key type 68

Resetting the feature keys to the defaults 69

Labeling a feature 69

Using the Options menu 70

Enabling or disabling auto hide 70

Deﬁning your default feature 71

Assigning the Outbox to a key 72

Using the Directory menu 73

Adding or editing a directory entry 73

Deleting an entry from the directory 75

Making a call using the directory 75

Using the Inbox 77

Accessing the Inbox 77

Viewing Inbox call information 78

Storing a number from the Inbox 78

Using the Inbox to make a call 79

Resetting the Inbox 79

Using the Outbox 81

Accessing the Outbox 81

Viewing Outbox call information 82

Storing a number from the Outbox 82

Using the Outbox to make a call 83

Resetting the Outbox 83

Call Services 85

Feature proﬁles 85

Softkey assignment 86

Carrier VoIP

Nortel IP Phone 1110 User Guide (CICM)

NN10300-021 1.0 Draft

(I)SN10 30 November 2006

6Contents

Mute feature 91

Using the dialpad to enter text 93

Use the IP Phone with the IP Softphone m6350 95

Access Code summary 97

Carrier VoIP

Nortel IP Phone 1110 User Guide (CICM)

NN10300-021 1.0 Draft

(I)SN10 30 November 2006

New in this release

The following section details what’s new in the Nortel IP Phone 1110 User

Guide (CICM) (NN10300-021) for the release (I)SN10.

Features This new document for Nortel Communication Server 2000/2100 supports

the integration of Nortel IP Phone 1110 into the Centrex IP Client Manager

(CICM) portfolio of supported terminals.

Carrier VoIP

Nortel IP Phone 1110 User Guide (CICM)

NN10300-021 1.0 Draft

(I)SN10 30 November 2006

8New in this release

Carrier VoIP

Nortel IP Phone 1110 User Guide (CICM)

NN10300-021 1.0 Draft

(I)SN10 30 November 2006

Overview

Nortel IP Phone 1110 brings voice and data to the desktop by connecting

directly to a Local Area Network (LAN) through an Ethernet connection.

When you are logged on the system, the handset and keypad of the IP

Phone 1110 operate in the same way as a standard Meridian Business Set

(MBS) telephone. You can access additional services and features through

the softkeys. The label beside a softkey identiﬁes the current function

associated with that key.

IP Phone terminal description

Nortel IP Phone 1110 offers these features:

•four light-emitting diode (LED) indicator lamps

— message waiting lamp

— data lamp

— link/data lamp

•multiﬁeld LCD screen

— adjustable contrast

— backlight

•four softkeys to access and utilize Centrex features that are available

through the Call Services menu

•ﬁve navigational keys

—up

—down

— left

— right

— send

•speaker for on-hook dialing or on-hook listening

Carrier VoIP

Nortel IP Phone 1110 User Guide (CICM)

NN10300-021 1.0 Draft

(I)SN10 30 November 2006

10 Overview

•ﬁxed keys:

— Services

— Inbox

— Volume control

— Hold

— Expand to PC

— Line

— Goodbye

•standard telephone dialpad

•Automatic network conﬁguration

•upgradeable ﬁrmware

"IP Phone 1110 components" (page 10) shows the location of the keys and

the components of the IP Phone.

The IP Phone does not have a microphone for handsfree talking. A mute

function is available through the Call Services menu.

Not all features are available on all telephones. Consult your system

administrator to verify which features are available to you.

IP Phone 1110 components

Carrier VoIP

Nortel IP Phone 1110 User Guide (CICM)

NN10300-021 1.0 Draft

(I)SN10 30 November 2006
