Nordpeis Me Basic User manual

Art.no: SA-ME000-B14, SA-ME000-B24

Last updated: 19.06.2018

Test Report No: RRF 40 17 4683, NS 17 4683

NO Monterings og bruksanvisning

SE Installations och bruksanvisning

GB Installation and user manual

FI Asennus ja käyttöohje

DE Installations und Benutzerhandbuch

FR Manuel d’installation et d’utilisation

Me Basic

2

FIG 1 Me Basic = mm / air / chimney

483

520

1100

171

984

340

305

147

1075

100

173

70

483

520

1100

171

984

339

305

147

1075

100

173

70

340

3

Se egen monteringsanvisning

See separate instruction

Se egen mon teringsanvisning

Katso erilliset ohjeet

Beachten Sie die seperate Montageanleitung

Voir le manuel d’installation séparé

Referer til ME manualen og fjern Thermotteplatene fra brennkammeret.

Se monteringsanvisningen för ME och ta bort thermotte-infordringen.

Refer to the installation manual for ME and remove the Thermotte liner.

Katso ME-asennusohje ja irrota Thermotte-levyt.

Siehe die ME-Einbauanleitung und entfernen Sie den Thermotte-Mantel.

Reportez-vous au manuel d’installation du modèle ME et retirez l’habillage en

Thermotte.

NO

SE

FI

GB

DE

FR

Manual for ME

4

FIG 2

1.

2.

3 mm

3.

4.

3 mm

5

FIG 3

FIG 3a

6

FIG 4

1.

2.

3 mm

3.

4.

3 mm

7

6 mm

FIG 5

4 mm

x4

FIG 6

Nedre luftstilkobling / Undre luftanslutning

Bottom air connection / Palamisilmaliitäntä pohjassa

Unterer Luftanschluss / Raccordement d’air par le bas

8

x4

1.

2.

OK

FIG 7

FIG 8

9

FIG 8a

FIG 9

10

Monter Thermotteplatene i motsatt rekkefølge de ble tatt ut.

Sätt tillbaka thermotte-plattorna på samma sätt som de togs bort, men i omvänd ordningsföljd.

Re-install the thermotte plates in the reverse order as they were disassembled.

Asenna Thermotte-levyt päinvastaisessa järjestyksessä.

Bauen Sie die Thermotte-Platten in umgekehrter Ausbaureihenfolge wieder ein.

Remonter les plaques Thermotte dans l’ordre inverse du désassemblage.

NO

FI

GB

SE

DE

FR

FIG 9a

0mm

0mm

0mm

0mm
