Nordmende RIUI161NMA+ User manual
EN Buit-in Refrigerator
User Manual
RIUI161NMA+
TM
EN
2
EN
3
Index
BEFORE USING THE APPLIANCE................................. 4
General warnings...................................................................... 4
Old and out-of-order fridges...................................................... 6
Safety warnings ........................................................................ 7
Installing and operating your fridge freezer .............................. 8
Before Using your fridge freezer............................................... 9
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS .......................................................... 10
HOW TO OPERATE THE APPLIANCE .......................... 11
Thermostat setting....................................................................11
Accessoires ............................................................................. 12
Making Ice cubes: ............................................................... 12
CLEANING AND MAINTENANCE.................................. 13
Defrosting the fridge compartment .......................................... 14
Freezer compartment; ............................................................. 14
Replacing the light bulb ........................................................... 15
FOOD STORAGE IN THE APPLIANCE ......................... 16
Fridge compartment................................................................. 16
Freezer compartment .............................................................. 16
ASSEMBLY INSTRUCTION .................................................... 18
SHIPMENT AND REPOSITIONING ................................ 18
BEFORE CALLING YOUR AFTER SALES SERVICE... 27
TIPS FOR SAVING ENERGY.......................................... 29
ELECTRICAL CONNECTION (FOR UK TYPE PLUG) .. 30
How to wire a 13 amp plug. ................................................. 30
The operating instructions apply to several models. Differences
may therefore occur.
EN
4BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless
they are of the type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of
the appliance, it must be xed in accordance with the
instructions.
• If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
- staff kitchen areas in shops, ofces and other working
environments.
EN
5
BEFORE USING THE APPLIANCE
- farm houses and by clients in hotels, motels and
other residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it
must be replaced by the manufacturer, a service agent
or similarly qualied persons in order to avoid a hazard.
• A specially grounded plug has been connected to the
power cable of your refrigerator. This plug should be
used with a specially grounded socket of 16 amperes.
If there is no such socket in your house, please have
one installed by an authorised electrician.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.
EN
6BEFORE USING THE APPLIANCE
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock
before discarding it, because children may get trapped
inside it and may cause an accident.
• •Old fridges and freezers may contain isolation material
and refrigerant with CFC or HFC. Therefore, take care not
to harm environment when you are discarding your old
fridges.
• Please ask your municipal authority about the disposal of
the WEEE reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before
installing and using your appliance. We are not
responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction
manual, and keep this manual in a safe place to resolve
the problems that may occur in the future.
• This appliance is produced to be used in homes and it
can only be used in domestic environments and for the
specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the
appliance to be cancelled and our company will not be
responsible for losses incurred.
• This appliance is produced to be used in houses and it is
only suitable for cooling / storing food. It is not suitable for
commercial or common use and/or for storing substances
except for food. Our company is not responsible for losses
to be incurred in the contrary case.
EN
7
BEFORE USING THE APPLIANCE
Safety warnings
• Do not connect your fridge freezer to the mains electricity
supply using an extension lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow
children to play with the appliance or let them hang off the
door.
• Never touch the power cord/plug with wet hands as this
could cause a short circuit or electric shock.
• Do not place glass bottles or beverage cans in the ice-
making compartment as they can burst as the contents
freeze.
• Do not place explosive or ammable material in your fridge
freezer. Place drinks with high alcohol content vertically in
the fridge compartment and make sure that their tops are
tightly closed.
• When removing ice from the ice-making compartment, do
not touch it. Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-
cream or ice cubes immediately after you have taken them
out of the ice-making compartment.
• Do not cover the body or top of fridge with lace. This affects
the performance of your fridge freezer.
• Secure any accessories in the fridge freezer during
transportation to prevent damage to the accessories.
EN
8BEFORE USING THE APPLIANCE
Installing and operating your fridge freezer
Before starting to use your fridge freezer, you should pay
attention to the following points:
• The operating voltage for your fridge freezer is 220-240 V
at 50Hz.
• The plug must be accessible after installation.
• Your fridge freezer may have a smell when it is operated for
the rst time. This is normal and the smell will fade away
when your fridge starts to cool.
• Before connecting your fridge freezer, ensure that the
information on the data plate (voltage and connected load)
matches that of the mains electricity supply. If in doubt,
consult a qualied electrician.
• Insert the plug into a socket with an efcient ground
connection. If the socket has no ground contact or the plug
does not match, we recommend that you consult a qualied
electrician for assistance.
• The appliance must be connected with a properly installed
fused socket. Power supply (AC) and voltage at the
operating point must match with the details on the name
plate of the appliance (name plate is located on the inside
left of the appliance).
• We do not accept responsibility for any damages that occur
due to ungrounded usage.
• Place your fridge freezer where it will not be exposed to
direct sunlight.
• Your fridge freezer should never be used outdoors or
exposed to rain.
• Your appliance should be at least 50 cm away from stoves,
gas ovens and heater cores, and at least 5 cm away from
electrical ovens.
• When your fridge freezer is placed next to a deep freezer,
there should be at least 2 cm between them to prevent
humidity forming on the outer surface.
• Do not place heavy items on the appliance.
• Clean the appliance thoroughly, especially the interior,
before use (see Cleaning and Maintenance).
• The installation procedure into the kitchen unit is given in
EN
9
BEFORE USING THE APPLIANCE
the installation manual. This product is intended to be used
in proper kitchen units only.
• Use the adjustable front legs to make sure your appliance
is level and stable. You can adjust the legs by turning them
in either direction. This should be done before placing food
in the fridge freezer.
• Before using your fridge freezer, wipe all parts with
a solution of warm water and a teaspoon of sodium
bicarbonate, then rinse with clean water and dry.
Place all parts in the fridge freezer after cleaning.
• Install the plastic distance guide (the part with black vanes
at the rear) by turning it 90° (as shown in the gure) to
prevent the condenser from touching the wall.
• The fridge freezer should be placed against a wall with a
free space not exceeding 75 mm.
Before Using your fridge freezer
• When using your fridge freezer for the rst time, or after
transportation, keep it in an upright position for at least 3
hours before plugging into the mains. This allows efcient
operation and prevents damage to the compressor.
• Your fridge freezer may have a smell when it is operated for
the rst time. This is normal and the smell will fade away
when your fridge freezer starts to cool.
EN
10
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
This manual for information about the parts of the appliance.
Parts may vary according to the appliance model.
1. Ice tray
2 Freezer room door
3. Freezer door Open/Close indicator
4. Fridge shelf
5. Crisper cover
6. Crisper
7. Thermostat knob
8. Bottle shelf
9. Butter cheese shelf
10. Egg holder
11. Iluminate On/Off button
12. Fridge Iluminate
2
3
4
5
6
7
8
9
11
12
1
10
Table of contents
Other Nordmende Refrigerator manuals
Nordmende
Nordmende RFF315NFWHA+ User manual
Nordmende
Nordmende RUL120NMWHA+ User manual
Nordmende
Nordmende RF4DVRIXA+ User manual
Nordmende
Nordmende RFF332SLA+ User manual
Nordmende
Nordmende RETNF368BLUEA+ User manual
Nordmende
Nordmende RTL397WHA+ User manual
Nordmende
Nordmende RFF263SLA+ User manual
Nordmende
Nordmende RET347BLUEA+ User manual
Nordmende
Nordmende RFA91IX User manual
Nordmende
Nordmende RET346C User manual
Nordmende
Nordmende RUL121NMWHA+ User manual
Nordmende
Nordmende RUI111NMWHA+ User manual
Nordmende
Nordmende RFAM510BLA+ User manual
Nordmende
Nordmende RF4DRIXA+ User manual
Nordmende
Nordmende RITL395A+ User manual
Nordmende
Nordmende RIL1232A+ User manual
Nordmende
Nordmende RFF263WHA+ User manual
Nordmende
Nordmende RFA90IX User manual
Nordmende
Nordmende RFF334SL User manual
Nordmende
Nordmende RET340R User manual
