Nor-tec Electric Steam Humidifiers User manual

Thank you for purchasing a NORTEC humidifier. Over thirty years

ago, we saw the need for a humidifier design that would end the

time-consuming and costly maintenance that was required by other

humidifiers. The main problem to overcome was to easily remove

the minerals that are left behind when water is boiled. At the

same time, a humidifier was needed to produce clean steam and

maintain long-term efficient operation.

The NORTEC electrode steam humidifier, with disposable cylinder,

meets all of the above criteria.

As clean steam is produced, the minerals that are in the water

remain in the steam generating cylinder and are periodically

removed through the automatic drain system. NORTEC’s patented

auto-adaptive control system is designed to produce 100% of rated

output capacity right up until end of cylinder life. At this time, the

cylinder is easily removed and replaced with a new clean cylinder.

While other humidifiers must be totally disassembled for cleaning

and require hazardous acids to remove the minerals, the cylinder in

your NORTEC humidifier is easily removed and replaced. Since the

cylinders are produced of inert plastics and retain only the water

borne minerals, disposal problems are at a minimum.

This ease of cleaning and cylinder replacement is one of the main

features that helps reduce customer maintenance costs. It allows

optimum service from the humidifier and keeps the time required

for maintenance to a minimum.

Low cost▶

Clean▶

Easy maintenance▶

AUTHORIZED AGENT

Remember to check

your cylinders regularly!

COLD & DRY WINTERS = INCREASED HUMIDIFIER DEMAND

Remember to check

your cylinders regularly!

U.S.A.

Walter Meier (Climate USA) Inc.

826 Proctor Avenue

Ogdensburg, NY 13669

CANADA

Walter Meier (Climate Canada) Ltd.

2740 Fenton Road

Ottawa, Ontario K1T 3T7

TEL: 1.866.NORTEC1

FAX: 613.822.7964

EMAIL: sales@humidity.com

WEBSITE: www.humidity.com

Replacement Cylinder Order Form

Name

Company

Address

City State/Province Zip/Postal Code

Phone Fax

Cylinder # Part # Humidiﬁer Speciﬁcations Price each Quantity Total

104 1519704 005/010 lbs/hr 380 - 600 V 1 ph $159.00

201 1519001 005/010 lbs/hr 110-240v 1ph $159.00

202 1519002 005/010 lbs/hr 110-277v 1 ph $159.00

203 1519003 005/010 lbs/hr 347-380V 1 ph $159.00

204 1519004 005/010 lbs/hr 440-600v 1 ph $159.00

301/321 1519020 020 lbs/hr 208-277v 1 ph $186.00

303 1519023 020 lbs/hr 208 - 240 V 3ph $186.00

305 1519025 020 lbs/hr 347 - 380 v 1ph $186.00

309 1519029 020 lbs/hr 440 - 600 V 1 ph $186.00

311 1519031 020 lbs/hr 440 - 600 V 3ph $186.00

403/421 1519040 030 lbs/hr 208 - 240V 3ph $229.00

411 1519051 030 lbs/hr 440 - 600 V 3ph $229.00

601/621 1519080 50/75/100/150/200 lbs/hr 208 - 240V 3ph $284.00

607 1519087 050/075/150 lbs/hr 460/575V 100/200 lbs/hr, 575V $284.00

The above are suggested prices for NORTEC standard replacement cylinders. Prices may vary

according to geographic location and are subject to change without notice. Freight is not included.

Replacement cylinders can be ordered directly from your local agent. You can also fill in this form

and forward it directly to Walter Meier (NORTEC). We will have our agent contact you.

With each replacement cylinder, a new drain o-ring is supplied. Please find it attached to this form.

Thank you for choosing NORTEC humidifiers.

2538814-B
