NOMA 043-7332-6 User manual
PERSONAL COOL MIST ULTRASONIC HUMIDIFIER
PRODUCT NO. 043-7332-6
USER MANUAL
READ AND SAVE THESE INSTRUCTIONS
TABLE OF CONTENTS
2
01. KNOW YOUR HUMIDIFIER
02. OPERATING INSTRUCTIONS
03. CLEANING INSTRUCTIONS
04. PRODUCT SPECIFICATIONS
05. FAQs
06. SAFETY / CAUTIONS
07. TROUBLESHOOTING
08. WARRANTY & DISPOSAL
09. CERTIFICATION DETAILS
3
7
9
11
12
13
19
20
21
KNOW YOUR HUMIDIFIER
FEATURES
01.
02.
MIST OUTLET
CONTROL PANEL
01 01
02
3 4
KNOW YOUR HUMIDIFIER
COMPONENTS
01.
02.
03.
04.
05.
MIST CAP
AIR INPUT VENT
WATER TANK
USB PLUG
VENT
01 01
02
03
04
05
5 6
04. Power
Plug the USB cable into the humidier and press the Power Button once.
The humidier will turn on and start immediately.
OPERATING INSTRUCTIONS
SET UP DIRECTIONS 02
01. Place
Place your humidier on a at, moisture-proof surface.
03. Prepare
Place the mist cap back on the water tank and turn it until the mist outlet is
pointing in the direction you want.
05. Relax
Enjoy your humidier in quiet, peaceful, bliss. When the tank is empty, the
humidier will automatically shut off until the tank is relled.
02. Fill
Remove the mist cap and pour tap water into the water tank until the
water level reaches the “MAX” mark.
02.
78
CLEANING INSTRUCTIONS
CARE & MAINTENANCE 03
Make sure the humidier is turned off and unplugged.
Empty any residual water and rinse the water tank.
Wipe the water tank and mist cap clean with a cloth or towel.
Repeat the rst 2 operations of Daily Maintenance.
Add 1 teaspoon (2.4 mL) of undiluted white vinegar or cleaning solution
into the water tank and let it sit.
After 20 minutes, pour out the cleaning solution and rinse with warm
water.
Wipe the water tank and mist cap clean with a cloth or towel.
Daily Maintenance
01.
02.
03.
Weekly Maintenance
01.
02.
03.
04.
Repeat the rst 2 operations of Daily Maintenance.
Fill the water tank halfway with water then add a
½ tablespoon (7.2 mL) of chlorine bleach.
Swirl the solution in the water tank for a few minutes to ensure that the
full interior has been covered.
Let the solution sit in the water tank for 20 minutes.
Empty the water tank and rinse it with water until no disinfectant smell
is present.
Wipe the water tank and mist cap clean with a cloth or towel.
Disinfecting Water Tank
01.
02.
03.
04.
05.
06.
9 10
PRODUCT SPECIFICATIONS FAQs
OVERVIEW FREQUENTLY ASKED QUESTIONS
04 05
What happens when the tank runs out of water?
When the tank is empty, all indicators will blink 5 times and the unit will
automatically shut off until the tank is relled.
Will the humidier work if I plug it into a USB port instead of a wall outlet?
Yes, as long as the voltage coming out of the USB port is 5 V DC.
Q:
A:
Q:
A:
11 12
Product Name NOMA®Personal Cool Mist
Ultrasonic Humidier
Product Model 043-7332-6
Water Tank Capacity 100 mL
Run Time 8 hours
Mist Temperature Cool
Auto Shut Off Yes (when tank is empty)
USB Input Voltage 5 V DC
06
13 14
•
•
TO AVOID FIRE OR SHOCK HAZARD, USE
ONLY THE ADAPTOR PROVIDED TO PLUG
THE HUMIDIFIER DIRECTLY INTO A 120V AC
ELECTRICAL OUTLET.
DO NOT ALLOW CHILDREN TO HANDLE
THE HUMIDIFIER. SUPERVISION REQUIRED
WHEN PLACED IN A ROOM WITH CHILDREN.
WARNING: DO NOT ATTEMPT TO REFILL
HUMIDIFIER WITHOUT FIRST UNPLUGGING THE
UNIT FROM ITS ELECTRICAL OUTLET. FAILURE TO
HEED THIS WARNING MAY CAUSE PERSONAL
INJURY. BE SURE TO UNPLUG THE UNIT BY
PULLING ON THE PLUG AND NOT THE CORD.
DO NOT OPERATE THE HUMIDIFIER IF THERE
IS DAMAGE TO THE POWER CORD OR IF THE
HUMIDIFIER HAS BEEN DROPPED, DAMAGED
OR MALFUNCTIONS. RETURN THE HUMIDIFIER
TO AN AUTHORIZED SERVICE FACILITY.
USE HUMIDIFIER ONLY FOR INTENDED
HOUSEHOLD USE AS DESCRIBED IN
THIS MANUAL. ANY OTHER USE NOT
RECOMMENDED BY THE MANUFACTURER MAY
CAUSE FIRE, ELECTRIC SHOCK, OR INJURY
TO PERSONS. THE USE OF ATTACHMENTS
NOT RECOMMENDED OR SOLD BY THE
MANUFACTURER MAY CAUSE HAZARDS.
TO AVOID FIRE HAZARD, NEVER PLACE THE
CORD UNDER RUGS OR NEAR HEAT REGISTERS.
•
•
•
SAFETY/CAUTIONS
15 16
06
SAFETY/CAUTIONS
•
•
•
•
HUMIDIFIER SHOULD BE UNPLUGGED WHEN
NOT IN USE.
NEVER TILT, MOVE, OR ATTEMPT TO EMPTY UNIT
WHILE IT IS OPERATING. SHUT OFF AND UNPLUG
BEFORE REMOVING THE WATER TANK AND
MOVING THE UNIT.
THIS HUMIDIFIER REQUIRES DAILY AND WEEKLY
MAINTENANCE TO OPERATE EFFICIENTLY.
REFER TO DAILY AND WEEKLY CLEANING
PROCEDURES. USE ONLY CLEANERS
AND ADDITIVES RECOMMENDED BY THE
MANUFACTURER.
NEVER USE DETERGENTS, GASOLINE, GLASS
CLEANER, FURNITURE POLISH, PAINT THINNER,
OR OTHER HOUSEHOLD SOLVENTS TO CLEAN
ANY PART OF THE HUMIDIFIER.
NEVER CLEAN THE HUMIDIFIER WHILE IT
IS PLUGGED IN. DO NOT IMMERSE THE
HUMIDIFIER IN WATER.
DO NOT PLUG IN THE CORD WITH WET HANDS:
ELECTRIC SHOCK COULD RESULT.
DO NOT POUR WATER IN ANY OPENINGS
OTHER THAN THE WATER TANK.
TO PREVENT DAMAGE TO SURFACES, DO NOT
PLACE HUMIDIFIER UNDER OVERHANGING
SURFACES.
NEVER OPERATE HUMIDIFIER WITHOUT WATER
IN THE TANK.
TO AVOID FIRE OR SHOCK HAZARD, USE ONLY
THE ADAPTER PROVIDED.
•
•
•
•
•
•
17 18
ALWAYS PLACE HUMIDIFIER ON A FIRM,
FLAT, LEVEL SURFACE. A WATERPROOF MAT
COULD BE USED AS THIS UNIT CAN PRODUCE
LARGE AMOUNTS OF MOISTURE. ALWAYS
USE CAUTION WHEN PLACING ON FINISHED
FLOORS AND CARPETS.
DO NOT ALLOW THE MIST OUTLET TO DIRECTLY
FACE THE WALL. MIST COULD CAUSE DAMAGE,
PARTICULARLY TO WALLPAPER.
CHANGES OR MODIFICATIONS OF THIS
PRODUCT IS NOT EXPRESSLY APPROVED BY THE
PARTY RESPONSIBLE FOR COMPLIANCE COULD
VOID THE USER’S AUTHORITY TO OPERATE THE
EQUIPMENT.
DO NOT USE OUTDOORS.
•
•
•
•
DO NOT ATTEMPT TO REPAIR OR ADJUST ANY
ELECTRICAL OR MECHANICAL FUNCTIONS
ON THIS UNIT. DOING SO WILL VOID YOUR
WARRANTY. THE INSIDE OF THE UNIT CONTAINS
NO USER SERVICEABLE PARTS.
KEEP MATERIALS SUCH AS BEDDING, PAPERS,
CLOTHES AND CURTAINS AWAY FROM THE
UNIT. DO NOT COVER THE UNIT WITH ANY ITEMS
WHICH CAN BLOCK THE AIR INLET AND OUTLET.
NEVER DROP OR INSERT ANY OBJECT INTO
ANY OPENINGS.
DO NOT PLACE HUMIDIFIER NEAR HEAT
SOURCES SUCH AS STOVES, RADIATORS, AND
HEATERS. DO LOCATE YOUR HUMIDIFIER ON
AN INSIDE WALL NEAR AN ELECTRICAL OUTLET.
•
•
•
•
06
SAFETY/CAUTIONS
