Nobles SS17-20 User manual

Nobles SS17-20

Walk-Behind Scrubber

Product Guide

Details Features, Advantages & Benefits

Model SS17-20 Walk-Behind Scrubber

SOLUTION DELIVERY SYSTEM

Feature Advantage Benefit

Solution Tank

Easily accessible solution tank.

Solution tank has 2 separate

access points for filling.

1. The front access area for

filling is a wide opening to

allow filling with a bucket.

2. The rear access fill port

allows easy filling with a

hose.

Quicker filling of the machine to

save time and is much more

convenient if space is restricted,

such as inside a tight janitor’s

closet.

Solution Tank

•10.5 gallon/40 liter solution tank

•Easy fill feature front or rear

•Rotationally-molded

polyethylene construction

•10 year warranty on all

rotationally-molded

polyethylene components

Larger capacity for reduced

empty-fill requirement.

Durable construction for long life

and dependable performance.

Extended warranty coverage.

Increases operator productivity.

Ease of use.

Reduces long-term repair &

operating life cycle costs.

Model SS17-20 Walk-Behind Scrubber

Solution Sight Tube

Sight tube at rear of machine

allows operator to see remaining

solution so they can better judge

how long before they need to refill

the machine.

Increased productivity by good

water management.

Easier to use and more

convenient for the operators.

Saves time by monitoring the

amount of solution remaining so

operators can scrub their way

back to a refill point.

Optional FaST™ System

FaST ―Foam-activated

Scrubbing Technology extends

operating scrub time per tank of

solution by minimizing the amount

of water used during the scrubbing

process.

This greatly reduces empty/fill

cycles and creates less

wastewater.

Overcomes the need for the

operators to handle detergent.

Easy replacement of FaST-PAK™

in special storage area.

Increases floor and scrubbing

process safety. FaST is the only

system certified by NFSI to

increase floor traction.

Increases operator productivity.

Is very easy to use.

Environmentally friendly.

Decreases detergent handling and

measuring.

Model SS17-20 Walk-Behind Scrubber

SCRUBBING SYSTEM

Feature Advantage Benefit

Scrubbing Path

Disc Head

•17” (430 mm),

•20” (500 mm),

Two choices of scrub head size

for every application.

1. Narrow width for superior

maneuverability and access

to hard to reach obstructed

areas.

2. Wider scrub path for

larger areas.

Disc heads for use with brushes

or pads and where there is no

debris.

Increases versatility of the machine.

Allows for greater customization of

the machine for the application.

Increasing productivity and cleaning

results.

Uses Standard Diameter Pads

Readily available pad size and

types.

Versatile applications.

Saves money and time buying

spare pads.

Model SS17-20 Walk-Behind Scrubber

Brushes

3 brush types available for both

disc and cylindrical heads:

•Soft Dyna Scrub,

•Medium Poly

•Aggressive Grit

Brush configurations for all types

of hard floor surfaces.

Versatile applications.

Model SS17-20 Walk-Behind Scrubber

Easy-to-Install Pad Drivers and

disc brushes

Push button removal feature

allows operators to remove the

brush by just pressing one button

to lock the drive motor, and then a

quick twist on the pad or brush

and it will release.

The brush or pad then falls to the

ground.

To refit the brush or pad, rotate

the mounting under the brush

deck until you can see the

mounting holes through the slots

in the brush deck. (Arrowed)

Align pins with slot, twist into

place. Lock motor by pressing lock

button if necessary.

Reduces operator training

requirements.

Saves time and is more

convenient for the operators

Easy replacement, or removal for

cleaning of the brushes and pads.

Model SS17-20 Walk-Behind Scrubber

Brush Drive Motors

Disc Head

•1 horse power/.75 kW

brush/pad drive motor

•230 rpm

Powerful brush/pad drive motor(s)

and high rpm for superior soil

removal from hard floor surfaces.

Suitable for use on all types of

hard floor surfaces.

Cleaner, safer floor surfaces.

Versatile applications.

Dual Brush/Pad Pressure

50lbs and 90lbs

(23kgs and 43kgs)

2 Choices of brush down

pressure system allows the

operator to select the correct

down pressure for the application.

Cleaner, safer floor surfaces.

Machine can be tailored for

different cleaning needs, which

increases versatility.

Self adjusting, Wrap-Around

Splash Skirt on scrub head

Splash skirt captures all over-

spray from scrub deck.

Eliminates the need for follow-

passes or mopping to pick-up

over-spray.

Fully self adjustable--no tools

required. This means that the

operator does not need to touch

the skirt

Increases operator productivity.

Cleaner, drier, safer floor surfaces.

Easier operation and lower

maintenance costs.

Model SS17-20 Walk-Behind Scrubber

RECOVERY SYSTEM

Feature Advantage Benefit

Parabolic Squeegee

The parabolic squeegee

maintains equal suction pressure

across the entire width of the

squeegee to ensure full pick-up of

all water.

The squeegee frame is made

from non corrosive materials for

longer life

Cleaner, drier, safer floor surfaces.

Decreased maintenance costs.

Quick Release, Break-away

Squeegee Design

Squeegee dislodges from

mounting when squeegee hits an

immovable object. This protects

the squeegee assembly from

damage. Operator can easily refit

the dislodged squeegee with out

tools.

Reduces squeegee maintenance

and replacement costs.

Model SS17-20 Walk-Behind Scrubber

Squeegee Raise and Lower

Handle

Simple mechanical raise and

lower of the squeegee. Vacuum

fan automatically switches on

when squeegee is lowered and

switches off when squeegee

raised.

Solution flows automatically when

machine moves forward and

stops flowing when machine

stops

Squeegee up

Squeegee down

Decreases maintenance costs and

is very easy to use.

180 Degree Pick-up Squeegee

Squeegee follows machine

around 180 degree turns both to

the left and the right to ensure

complete pick-up all water.

Increases safety and leaves

cleaner, drier floors.

Model SS17-20 Walk-Behind Scrubber

Factory Set “No Hassle”

Squeegee

No adjustments required for the

squeegee.

Makes operation and maintenance

easier and less costly. Operator can

not tweak the squeegee adjustment.

No Tool Squeegee Change

Allows for quick and easy

replacement of squeegee blades.

Just unclip the clamp,

And remove the squeegee

Decreases maintenance costs and

increases productivity from less

downtime.
