Nixplay Oberflachen User manual
Let’s get
you started
A Brief Guide to Your Nixplay Frame
Read This First,
Please
Nixplay cares deeply about providing your family with a great frame and service. We go to
great lengths to ensure your frame is delivered into your hands in perfect working order.
If your Nixplay isn’t working perfectly, please do let us know. We’re here to help.
We’re just a phone call, email or chat away.
Find our telephone number, email and web address at the back of this guide.
Battery Warning:
The remote control supplied, is powered with and includes a coin/button cell battery.
1) This product contains a coin/button cell battery. If the coin/button cell battery is swallowed,
it can cause severe internal burns in just 2 hours and can lead to death;
2) If the battery compartment does not close securely, stop using the product
and keep it away from children;
3) Disposal of a battery into re or a hot oven, or mechanically crushing or cutting of
a battery, that can result in an explosion;
4) Leaving a battery in an extremely high temperature surrounding environment that can result
in an explosion or the leakage of ammable liquid or gas;
5) A battery subjected to extremely low air pressure that may result in an explosion or the
leakage of ammable liquid or gas.
Please read all instructions before use. Retain instructions for future reference.
Important Safety Information
Table of Contents
English
Get to know your frame
Before using the Remote Control
Positioning your frame
Wall mounting your frame
Create your Nixplay Account
Power your frame
Set up your frame
Starting to Nixplay
FCC
English
ISED
English
Français
Contact us
5
6
7
9
11
12
13
14
15
16
16
18
Get to know your frame
5
B
A
B
A
A) Senses movement and turns your frame on and off when motion sensor is enabled
B) Infra-red Sensor: Receives signals from the remote control
C) Power Adaptor DC -in
C
6
D) Infra-red Transmitter
E) On / Off
F) Up/Down/Left/Right Keys for Menu Navigation
G) Back
H) Settings
I) Play All Photos
J) Select / Play / Pause
K) Volume Up
L) Volume Down
E
F
D
G
H
I
K
L
J
M) Remove battery protector.
Before using the Remote Control
Pull
M
7
Positioning your frame
Your frame can be positioned as free-
standing in portrait or landscape mode.
Wall mounting instructions are later in
this guide.
Portrait
Landscape
Choose your frame orientation and align the
stand to the corresponding holes behind
your frame. Slide up to lock into place.
8
When not in use, the remote control
can be attached behind your frame
by magnet (not applicable when wall
mounted).
Slide the stand up/down to adjust the
viewing angle.
9
Wall mounting your frame
3
5mm
(0.2 inch)
21
1) Remove the back cover by sliding it
down to access the wall mount holes.
2) Use the included Wall Mounting Guide
to align where the screws need to be
drilled on the wall.
2 x M4 screws are included and required
for wall mount.
Depending on your wall type, you may
need to drill in the included anchors
before securing the screws.
3) Leave a 5mm gap between the wall
and the head of each screw where the
power cable can run through.
