Nilfisk-Advance UZ 934 Manual

BOOK B

B0.6.1

00-12

01-06

TABLE OF CONTENTS

DESCRIPTION PLAN

Parts, line drawing B - 0.6.1 - 2

Parts, part numbers B - 0.6.1 - 3

Line drawing, cord set, fan unit B - 0.6.1 - 4

Cord set, fan units, table B - 0.6.1 - 5

Nozzle, Hose & Tube, line drawing B - 0.6.1 - 6

Nozzle, Hose & Tube, part numbers B - 0.6.1 - 7

UZ 934 DRY VACUUM CLEANER 1

BOOK B

B0.6.1

00-12

01-06

PARTS LIST

UZ 934 LINE DRAWING ALL PARTS2

BOOK B

B0.6.1

00-12

01-06

Item. Qty. Part No Description

11See table Cord set

21See table Protection sleeve

3 1 140 6873 000 Grating

4 1 140 6872 000 Handle

5 1 140 6871 000 Upper cover, neutral blue

1 140 6871 010 Upper cover,neutral blue UL approved

1 140 6871 040 Upper cover, grey

1 140 7314 020 Upper cover, KENT UL-approved, blue

140 7314 030 Upper cover, Euroclean UL-approved, blue

6 1 140 6879 000 Diffuser

7 1 140 5496 000 Switch

8 1 140 8166 010 Capacitor

9 2 001 8619 110 Carbon brush (without holder)

2 140 7719 000 Carbon brush f.140 7902 520 fan units. w. holder 230-240V

2 140 7720 000 Carbon brush f.140 7902 510 fan units. w. holder 110-120V

2 140 7721 000 Carbon brush f.140 7902 530 fan units. w. holder 100V

10 1 See table Fan unit

11 1 140 7901 000 Suspension ring, for the new Domel fan units (the 140 7902 XXX)

1 011 1548 000 Suspension ring, for the old type of motor

12 1 140 7040 080 Wire cpl.

1 140 7042 110 Wire cpl. UL-approved

13 2 140 9214 040 Screw

14 1 056 1014 060 Anti-strain clip

15 1 140 6876 000 Gasket

16 2 140 7016 000 Spring

17 1 140 6843 000 Screw

18 1 140 3894 000 Thermal protector

19 1 140 7040 110 Wire cpl.

1 140 7042 090 Wire cpl. UL-approved

PARTS LIST

UZ 934 PART NUMBER 3

20 1 140 7040 030 Wire cpl.

1 140 7042 100 Wire cpl. UL-approved

21 1 140 6870 000 Lower cover.

1 140 6870 010 Lower cover, UL-approved

22 1 140 6744 000 Lock Washer

23 6 140 7027 010 Screw

24 2 140 6875 000 Gasket

25 1 140 6880 000 Air filter

26 140 6905 020 Dust bag 10-pcs.

27 4 140 9214 040 >>Screw, Torx 40x14

28 1 140 6411 000 Hose locking

1 140 7205 010 Hose locking, more curved

29 1 140 6409 000 Hose connection

30 2 011 5840 030 Wheel

31 1 140 6408 000 Container Blue

1 140 6408 050 Container Grey

1 140 6428 000 Container cpl. Blue

1 140 6428 050 Container cpl. Grey

32 2 140 6422 000 Castor wheel

33 1 140 6960 000 Insulation cover

1 140 6960 010 Insulation cover, UL-approved

34 140 7775 000 Sticker - decal, Nilfisk label

35 1 140 7860 000 Holder for cabel, for 905 2513 (US variants)

BOOK B

B0.6.1

00-12

01-06

PARTS LIST

LINE DRAWING, CORD & FAN UNIT

BOOK B

B0.6.1

00-12

01-06

oN.dorPoN.dorPoN.dorPoN.dorPoN.dorPegatloVegatloVegatloVegatloVegatloVtesdroCtesdroCtesdroCtesdroCtesdroCeveelsnoitcetorPeveelsnoitcetorPeveelsnoitcetorPeveelsnoitcetorPeveelsnoitcetorPtinunaFtinunaFtinunaFtinunaFtinunaF

eulB1052509zH06/05V042-032X 020324604100053070410252097041

eulB2052509zH06/05V042-032X 060324604100053070410252097041

eulB3052509zH06/05V042-032X 000676604100053070410252097041

eulB4052509zH06/05V001X 040324604101072013900352097041

eulB5052509zH06/05V042-032X 070324604100053070410252097041

eulB6052509zH06/05V011X 031324604100053070410152097041

eulB7052509zH06/05V021X 040324604101072013900152097041

eulB8052509zH06/05V021X040958304101072013900152097041

eulB9052509zH06/05V022X

0223246041

0203401390gulp+ 01072013900252097041

eulB0152509zH06/05V011X 04032460410107201390

wolleY1152509zH06/05V042-032X 060324604100053070410252097041

wolleY2152509zH06/05V042-032X 020324604100053070410252097041

eulB3152509zH06/05V021X040958304101072013900152097041

eulB4152509zH06/05V721X 040324604101072013900452097041

eulB6142509zH06/05V042-032X 090324604100053070410252097041

eulB7152509zH06/05V042-032X 0603246041>>00053070410252097041

yerG8152509zH06/05V042-032X 020324604100053070410252097041

yerG9152509zH06/05V042-032X 070324604100053070410252097041

yerG0252509ZH06/05V042-022X 060324604100053070410252097041

yerG1252509zH06/05V042-032X 000676604100053070410252097041

yerG2252509zH06V042-032X 040324604101072013900252097041

yerG3252509zH06/05V042-032X 040324604101072013900252097041

eulB4252509zH06/05v511X 02332460410005307041

yerG0452509

ikasamaY.f.dorp zH06/05V001X 040324604101072013900352097041

yerG1452509>>zH06/05V721X 040324604101072013900452097041

yerG2452509>>Zh06/05v042-032X 090324604100053070410252097041

yerG3452509>>zH06/05v511X 023324604100053070410152097041

PARTS LIST

CORD SET, FAN UNITS 5

140 7902 510

BOOK B

B0.6.1

00-12

01-06

UZ 934 NOZZLE, HOSE & TUBE

PARTS LIST

11 12

13A

13B

BOOK B

B0.6.1

00-12

01-06

Item.No. Qty. Part No Description

1 1 140 6430 000 Hose complete

2 1 140 7584 000 Bent end cpl.

3 1 140 3304 020 Inlet sleeve

4 2 011 6431 040 Extension tube 50 cm, aluminium

2 11112401 Extension tube 56 cm, steel

4B 1 011 8130 040 Telescopic extension tube, min 630 mm max 950 mm.

5 1 140 8741 010 Brush strip, rear

6 2 140 8743 000 Wheel

7 2 140 8744 000 Shaft

8 1 140 8741 000 Brush strip, front

9 1 140 8740 000 Top

10 1 140 6700 010 Multi surface nozzle compl.

11 1 010 3098 250 Crevice nozzle

12 1 011 3104 230 Small combi nozzle

13A 1 140 8245 000 Combination nozzle black

13B 1 11980300 Combination nozzle grey w. Nilfisk brandname

14 1 012 5475 000 Rubber packing

15 1 011 8136 020 Regulator

UZ 934 NOZZLE, HOSE & TUBE

PARTS LIST

>> Means: New or changed ref. number or/and changed/new specifications

ELECTRICAL DIAGRAM BOOK B

00-02 B0.6.2

99-02

UZ 934 DOUBLE INSULATED

Switch ON-OFF

Motor

Aut. thermal protector

Suppressor

Note: Wiring diagram only for Domel fan units p/n 140 7902 xxx.

ELECTRICAL DIAGRAM BOOK B

00-02 B0.6.2

99-02

Motor

Aut. thermal

protector

Switch ON-OFF

UZ 934 GROUNDED 2

Suppressor *

* Not for US versions

Note: Wiring diagram only for Domel fan units p/n 140 7902 xxx.
