Nextar V4-TV Assembly Instructions

Introduction

Congratulations on purchasing your Nextar GPS Navigator. Your

mobile navigation system assures that your days of getting lost are

over! Finding an address or any of millions of different points of

interest such as the nearest gas station or restaurant is a snap

anywhere. Just enter information using the touch screen and let the

voice prompt and detailed map guide you to your destination.

Important Safety Information

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude to

constitute a risk of electric to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

Important Safety Information

Read and keep these instructions

Failure to heed the following warnings could result in an

accident or collision resulting in serious injury or death

 When installing the unit in a vehicle, place the unit so that

it does not obstruct the driver’s view of the road or

interfere with vehicle operating controls.

 This GPS unit is designed to provide you with route

suggestions. It does not reflect road closures or road

conditions, traffic congestion, weather conditions, or other

factors that may affect safety or timing while driving.

 Always operate the vehicle in a safe manner. Do not

become distracted by the unit while driving. The

directions provided by the navigation unit are not

guaranteed to be accurate in every situation. Before

following suggestions from the unit, use your best

judgment regarding the safety and legality of any action

you take with your vehicle.

 Use this GPS unit only as a navigational aid. Do not

attempt to use the unit for any purpose requiring precise

measurement of direction, distance, location, or

topography. This product should not be used to determine

ground proximity for aircraft navigation.

 Do not access the GPS functions while driving. Pull over

in a safe and legal manner before changing settings,

entering destinations, or to access any other operational

functions.

Important Safety Information

 Never store your GPS in temperatures less than -5°F or

greater than 120°F.

 This unit contains a non-user-replaceable lithium-ion

battery. Do not dispose of your GPS by fire or with

hazardous or flammable materials. Contact your local

waste disposal department for information regarding

proper disposal of lithium-ion batteries.

 When in a car, do not mount your GPS on or near an air

bag. If the air bag is deployed, you may be seriously

injured.

 Only use a power cord provided by NEXTAR.

Use of products provided by other suppliers may void the

warranty.

 Caution: To reduce the risk of electric shock, do not

remove cover or back. No user serviceable parts inside.

Refer servicing to qualified service personnel.

 Do not use harsh chemicals (such as alcohol, benzene,

thinners, etc.) or detergents to clean your GPS. This

could damage the unit or cause a fire.

 Do not drop, strike, or shake your GPS severely. It may

harm the internal electronics of the unit.

 Warning: To reduce the risk of fire, electric shock or

damage, do not expose this product to rain or moisture.

Do not use your GPS in high explosive areas as the unit

may generate sparks.

Important Safety Information

 Do not damage the power cord by bending, twisting,

pulling, or heating. Do not use the plug if it is loose as it

may cause a fire or electric shock. Do not place any

heavy items on the power cord. Do not allow the power

cord to be crimped as it may cause electric shock or fire.

 Do not handle the GPS with wet hands while it is being

charged. It may cause an electric shock or seriously

damage your GPS.

 Spilled beverages are a common problem in moving

vehicles. Do not locate liquid containers, or items that can

accumulate condensation such as cold beverages, in a

position where liquid can spill or drip on the GPS device.

 Only use attachments / accessories specified by the

manufacturer.

 Unplug the unit from the DC car adaptor when not in use.

 Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug

is damaged, liquid has been spilled or objects have fallen

into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been

dropped.

 Caution: Dashboard temperatures can reach 180°F in a

closed vehicle! To prevent the GPS from being damaged

by excess heat, always remove your GPS unit from the

dash area when the car is parked.

Important Safety Information

Important: Some states have restrictions on locating your GPS

unit on the windshield. Included with your Nextar unit is an

adhesive backed Dashboard Mount Disk that can be used if

attaching the mounting bracket to the windshield is

inconvenient or not allowed.

See Page 17 for details.

FCC & UL Compliance

FCC COMPLIANCE:

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

 This device may not cause harmful interference.

 This device must accept any interference received,

including interference that may cause undesired

operation.

This equipment has been tested and found to comply with limits for

Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and

the receiver. Connect the equipment into an outlet on

a circuit different from that to which the receiver is

connected.

 Consult the dealer or an experienced radio/TV

technician for help.

FCC & UL Compliance

This Class B digital apparatus complies with Canadian

ICES-003.

CAUTION:

Underwriters Laboratories Inc. (“UL”) has not tested the

performance or reliability of the Global Positioning System

(“GPS”) hardware, operating software or other aspects of this

product. UL has only tested for fire, shock or casualty hazards

as outlined in UL’s Standard(s) for Safety.

UL Certification does not cover the performance or reliability of

the GPS hardware and GPS operating software.

UL MAKES NO REPRESENTATIONS, WARRANTIES OR

CERTIFICATIONS WHATSOEVER REGARDING THE

PERFORMANCE OR RELIABILITY OF ANY GPS RELATED

FUNCTIONS OF THIS PRODUCT.

Table of Contents

Introduction

Important Safety Information ....................................1

FCC & UL Compliance .............................................6

Getting Familiar With Your Hardware

Main Unit ..................................................................9

Accessories.............................................................11

Power Adaptor.........................................................12

System Connections ...............................................15

Using the Mounting Bracket ....................................17

Using Your Navigator

General Setup .........................................................19

TV Function.............................................................26

Playing Music ..........................................................33

Photo Viewer...........................................................36

Service & Support

Troubleshooting.......................................................40

Specifications ..........................................................43

Main Unit

1. Build-in TV Antenna

Extend the antenna to receive the TV signal.

2. TV Antenna Jack

Connect the external TV antenna.

Note: This unit comes without extra external TV antenna.

Please purchase external antenna separately.

3. POWER Button

Press and hold for 2 seconds to enter or exit standby mode.

4. Micro SD Card Slot

InserttheMicroSDcardintotheslot.

Used for user’s music or photo SD card

5. USB Port

Connect to the Power Adaptor to charge the unit.
